Quick Details
-
Driving system:
-
pneumatic motor driving
-
rollers:
-
3 rollers
-
Spine Binding Length:
-
Max 320mm
-
Key parts made in Korea:
-
Yes
-
Clamp material:
-
Aluminum
-
Binding speed:
-
280/hour
-
Binding thickness:
-
max 50mm (special made into 70mm)
-
Warm-up Time:
-
30-40minutes
Quick Details
-
Type:
-
perfect binding machine
-
Place of Origin:
-
China
-
Operating System:
-
Digital Control
-
Driving system:
-
pneumatic motor driving
-
rollers:
-
3 rollers
-
Spine Binding Length:
-
Max 320mm
-
Key parts made in Korea:
-
Yes
-
Clamp material:
-
Aluminum
-
Binding speed:
-
280/hour
-
Binding thickness:
-
max 50mm (special made into 70mm)
-
Warm-up Time:
-
30-40minutes
——— Technical Parameter
|
Product / Model |
Digital Binder |
|
System |
Digital Pneumatic |
|
Book Block Size |
320x320mm |
|
Cover Size |
330x680mm |
|
Cycle Speed |
360cycle/hr |
|
Book Binding Speed |
Max 300books/hr |
|
Book Block Clamp |
Aluminum cast + CNC machining Very smooth, can even clamp 2 sheets |
|
Cover Clamp |
Aluminum cast+ CNC machining Covered by Teflon, non-stick |
|
Max Book Thickness |
50mm (special made into 70mm ) |
|
Warm up Time |
30~40min |
|
Adhesive(Glue) |
EVA Hot Melt |
|
Side Glue |
Side Glue Roller( pneumatic auto ) |
|
Cutting |
Notching + Milling |
|
Glue Roller |
3 Rollers |
|
Operating mode |
One touch operation |
|
Machine Weight |
200 kg for desktop. 280 kg with Stand |
|
Power Consumption |
3 kw |
|
Voltage/Frequency |
AC 220V/50Hz |
|
Machine Dimensions |
1540(L)x650(W)x1300(H)mm |
1)
We are South Korea branch factory in China, all binder producing are according to South Korea standard. Keyparts are all
made in South Korea
too.
2) This binding machine is also designed and produced in compliance with
European CE, ISO
.
3) One-touch button software enables the scraping, gluing and covering processes implemented in a process.
4) Warranty: 2 years free warranty, lifelong service.
5) Design life: 15 years, 2 million books.
6) Service: 24x7 service for you.
