Quick Details
-
HEPA Filters:
-
99.999% efficiency at 0.3
-
Clean Level:
-
Class A
-
Control System:
-
Microprocessor control system
-
Rectangular Tube Material:
-
Aluminium alloy
-
Wall Material:
-
Anti-static dustproof curtain
-
Blower:
-
Built-in centrifugal blower speed adjustable
-
UV Lamp:
-
Emission of 253.7nanometers with UV timer
-
Illuminating Lamp:
-
LED Lamp Illumination :≥500
-
Air Velocity:
-
0.1~0.6m/s average 0.45m/s
-
Noise:
-
≤75db
Quick Details
-
Weight (KG):
-
250
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
BIOBASE
-
HEPA Filters:
-
99.999% efficiency at 0.3
-
Clean Level:
-
Class A
-
Control System:
-
Microprocessor control system
-
Rectangular Tube Material:
-
Aluminium alloy
-
Wall Material:
-
Anti-static dustproof curtain
-
Blower:
-
Built-in centrifugal blower speed adjustable
-
UV Lamp:
-
Emission of 253.7nanometers with UV timer
-
Illuminating Lamp:
-
LED Lamp Illumination :≥500
-
Air Velocity:
-
0.1~0.6m/s average 0.45m/s
-
Noise:
-
≤75db
Product Description
Parameters
|
Model
|
BKCB-1500
|
BKCB-2000
|
|
BKCB-3000
|
BKCB-5000
|
|||||
|
External Size (W*D*H)
|
1500*2000*2530mm
|
2000*3000*2530mm
|
|
3000*4000*2530mm
|
5000*5000*2530mm
|
|||||
|
HEPA Filters
|
99.999% efficiency at 0.3
|
|
|
|
|
|||||
|
Consumption
|
800W
|
|
1500W
|
2800W
|
5000W
|
|||||
|
FFU Nos.
|
4 pcs
|
|
6 pcs
|
12 pcs
|
25 pcs
|
|||||
|
Clean Level
|
Class A
|
|
|
|
|
|||||
|
Control System
|
Microprocessor control system
|
|
|
|
|
|||||
|
Rectangular Tube Material
|
Aluminium alloy
|
|
|
|
|
|||||
|
Wall Material
|
Anti-static dustproof curtain
|
|
|
|
|
|||||
|
Blower
|
Built-in centrifugal blower; speed adjustable
|
|
|
|
|
|||||
|
UV Lamp
|
40W*2
|
|
40W*2
|
40W*3
|
40W*5
|
|||||
|
|
Emission of 253.7nanometers, with UV timer
|
|
|
|
|
|||||
|
Illuminating Lamp
|
16W*1
|
|
16W*2
|
16W*3
|
16W*5
|
|||||
|
|
LED Lamp,Illumination :≥500lux
|
|
|
|
|
|||||
|
Air Velocity
|
0.1~0.6m/s, average 0.45m/s
|
|
|
|
|
|||||
|
Noise
|
≤75db
|
|
|
|
|
|||||
|
Power Supply
|
AC220V±10%, 50/60Hz; 110V±10%, 60Hz
|
|
|
|
|
|||||
|
Gross Weight
|
390Kg
|
|
670Kg
|
1100Kg
|
2900Kg
|
|||||
|
Package Size (W*D*H)
|
2110*930*920mm
2280*660*500mm |
|
3080*980*1280mm
3080*660*550mm |
3080*980*1280mm
3080*980*1280mm 4080*660*550mm |
4080*980*1280mm
4080*980*1280mm 4080*980*1280mm 1260*660*1280mm 5080*460*500mm |
|||||
|
Customized design for clean level, size or material is available
|
|
|
|
|
|
|||||
Features
FEATURES:
1. Customized design is welcomed.
2. It can be used singly or combined.
3. Compared with civil type and fabricated type clean room of hundred clean level, it has low running cost and fast effect and can be easily installed.
4. Modular construction, easy to increase clean level, good expansion and reusable, convenient movement (Universal wheel can be installed).
1. Customized design is welcomed.
2. It can be used singly or combined.
3. Compared with civil type and fabricated type clean room of hundred clean level, it has low running cost and fast effect and can be easily installed.
4. Modular construction, easy to increase clean level, good expansion and reusable, convenient movement (Universal wheel can be installed).
