Quick Details
-
Brand Name:
-
Bosean
-
Model Number:
-
K-100
-
Product name:
-
gas level detector
-
Detecting Gas:
-
CH4 O2 CO CO2 H2S NH3 HCN CL2...
-
Measure Range:
-
Optioanl according to gas
-
Color:
-
Red + black
-
Power supply:
-
Rechargeable lithium battery
-
Sampling method:
-
Diffusion
-
Safe degree:
-
Intrinsically safe
-
Response time:
-
<30s
-
Display:
-
LCD indicates
Quick Details
-
Type:
-
single gas detector
-
Warranty:
-
12 months, 2 years
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
Bosean
-
Model Number:
-
K-100
-
Product name:
-
gas level detector
-
Detecting Gas:
-
CH4 O2 CO CO2 H2S NH3 HCN CL2...
-
Measure Range:
-
Optioanl according to gas
-
Color:
-
Red + black
-
Power supply:
-
Rechargeable lithium battery
-
Sampling method:
-
Diffusion
-
Safe degree:
-
Intrinsically safe
-
Response time:
-
<30s
-
Display:
-
LCD indicates
K-100 portable single gas detector can make continuous detection to combustible and toxic gases. It is suitable for combustible and toxic gas leakage detection in underground pipe or mines, and keeps the workers safe, prevents the facilities from being destroyed.
The detector, adopting excellent-quality sensor, makes detection in the way of natural diffusion. It has good sensitivity and reproducibility. The detector adopts embedded MCU controller, easy to operate.
The shell adopts special high strength material and anti-smooth rubber, with the characters of water-proof and dust-proof.
Main Features
1) Advanced MCU control with low power consumption
2) Adjustable low and high alarm level
3) Adjustable calibrating level
4) High concentration protection for combustible gas
5)
Self test for the combustible gas sensor
6) Low battery indication
7)
Replaceable sensor module
8) Self-adjustment function
9) Visual and audible alarm with vibration
10) STEL and TWA alarming for toxic gases
11) Advanced self-examination and self-renovation function
12) Password management to avoid wrong operation
13) Explosive proof housing
Orignal Structure
Bosean has been committed to the development of the gas detection industry with strong economic strength and strong technical strength , specializing in the research, development, manufacturing and sales of gas detectors.We have continuously developed new products with international advanced technology.
Simple Operation
The body of the detector is small and easy to carry. The interface is simple and easy to operate. The shell is made of high strength ABS material, IP65 protection grade, dustproof, waterproof, explosion-proof, and can withstand the test of harsh environment.
Four Alarm
Two-level triple alarm, not easy to ignore, high and low alarm value can be set.
Standard Packaging
Metal aluminum box, machine, manual, certificate, lanyard, data cable, charger, calibration cover.
|
Product type
|
K-100
|
|
|
||
|
Sampling method
|
Diffusion type(Sampling pump optional)
|
|
|
||
|
Display
|
Large LCD
|
|
|
||
|
Alarm method
|
Audio, Visual LED and Vibratory
|
|
|
||
|
Working environment
|
-20℃~50℃
|
|
|
||
|
Power Supply
|
3.7V Rechargeable lithium battery
|
|
|
||
|
Gas Sensor Life
|
2 years
|
|
|
||
|
Charging time
|
Less than 5 hours
|
|
|
||
|
Data record
|
1000pcs data storage
|
|
|
||
|
Working time
|
8h continuously
|
|
|
||
|
Password protection
|
Password protection and password modification
|
|
|
||
|
Explosion-proof grade
|
Exib IIB T3 Gb
|
|
|
||
|
Principle
|
Electrochemical and Catalytic sensor
|
|
|
||
|
Additional function
|
Flashlight
|
|
|
||
|
Humidity
|
0-95%RH (no dew)
|
|
|
||
|
Shell materia
|
ABS
|
|
|
||
|
Dimensions
|
100*60*30mm(L*W*H)
|
|
|
||
The detector is suitable for explosion-proof, toxic gas leakage and rescue, underground pipelines, mines, metallurgy, power plants, chemicals, tunnels, etc., effectively avoiding the occurrence of poisoning accidents, ensuring the safety of workers and avoiding losses of production equipment.
|
No.
|
Detected
Gas
|
Detecting Scope
|
Resolution
|
Low/High
Alarm Point
|
Response
Time
|
Detection
Accuracy
|
|
1
|
PH3
|
0-20ppm
|
0.1ppm
|
5ppm/10ppm
|
≤25s
|
±5%(F.S)
|
|
2
|
O2
|
0-30%vol
|
0.1%vol
|
19.5%vol/23.0%vol
|
≤15s
|
±5%(F.S)
|
|
3
|
EX
|
0-100%LEL
|
1%LEL
|
25%LEL/50%LEL
|
≤5s
|
±5%(F.S)
|
|
4
|
CO
|
0-1000ppm
|
1ppm
|
50ppm/100ppm
|
≤25s
|
±5%(F.S)
|
|
5
|
H2S
|
0-100ppm
|
1ppm
|
10ppm/20ppm
|
≤30s
|
±5%(F.S)
|
|
6
|
NO2
|
0-20ppm
|
0.1ppm
|
3ppm/10ppm
|
≤25s
|
±5%(F.S)
|
|
7
|
NO
|
0-250ppm
|
1ppm
|
25ppm/50ppm
|
≤60s
|
±5%(F.S)
|
|
8
|
SO2
|
0-20ppm
|
0.1ppm
|
5ppm/10ppm
|
≤30s
|
±5%(F.S)
|
|
9
|
CL2
|
0-20ppm
|
0.1ppm
|
1ppm/10ppm
|
≤30s
|
±5%(F.S)
|
|
10
|
NH3
|
0-100ppm
|
1ppm
|
25ppm/50ppm
|
≤50s
|
±5%(F.S)
|
|
11
|
H2
|
0-1000ppm
|
1ppm
|
50ppm/100ppm
|
≤60s
|
±5%(F.S)
|
|
12
|
HCN
|
0-10ppm
|
0.1ppm
|
1ppm/5ppm
|
≤200s
|
±5%(F.S)
|
|
13
|
HCL
|
0-10ppm
|
0.1ppm
|
1ppm/5ppm
|
≤60s
|
±5%(F.S)
|
|
14
|
CH4
|
0-100%LEL
|
1%LEL
|
25%LEL/50%LEL
|
≤5s
|
±5%(F.S)
|
Note: The above table is a general parameter. If you need other gas and range, please contact our online customer service.
