Quick Details
-
Place of Origin:
-
Henan, China
-
Material:
-
Aluminum Alloy/Carbon fiber
-
Telescopic range:
-
3-30m Can be customized
-
Wind strength:
-
140Kph
-
Anti-corrosion process:
-
Antioxidant layer/paint
-
Maximum load:
-
66 lbs
-
Accessories:
-
Ground peg/line/line reel/tripod/box
-
Braking method:
-
Manual winch & electric remote control
-
Mounting Accessories:
-
Flange can be customized
-
Colour:
-
customized
-
Freight:
-
Buyer
Quick Details
-
Brand Name:
-
YANG BO
-
Model Number:
-
YBK-S
-
Type:
-
Antenna Mast
-
Place of Origin:
-
Henan, China
-
Material:
-
Aluminum Alloy/Carbon fiber
-
Telescopic range:
-
3-30m Can be customized
-
Wind strength:
-
140Kph
-
Anti-corrosion process:
-
Antioxidant layer/paint
-
Maximum load:
-
66 lbs
-
Accessories:
-
Ground peg/line/line reel/tripod/box
-
Braking method:
-
Manual winch & electric remote control
-
Mounting Accessories:
-
Flange can be customized
-
Colour:
-
customized
-
Freight:
-
Buyer
|
Type
|
Retracted
Height(M) |
Raised
Height(M) |
Diameter(mm)
|
|
Weight of Hand Crank(kg)
|
|
Weight of Motorized(kg)
|
|
||||||||
|
|
|
|
Min
|
Max
|
Al.Alloy
|
Carbon Fiber
|
Al.Alloy
|
Carbon Fiber
|
||||||||
|
YBK-5S
|
1.60
|
5
|
50
|
80
|
23
|
18
|
35
|
30
|
||||||||
|
YBK-6S
|
1.60
|
6
|
60
|
105
|
24
|
20
|
38
|
34
|
||||||||
|
YBK-8S
|
2.20
|
8
|
60
|
105
|
26
|
22
|
45
|
41
|
||||||||
|
YBK-10S
|
2.20
|
10
|
50
|
105
|
28
|
24
|
55
|
50
|
||||||||
|
YBK-12S
|
2.25
|
12
|
40
|
105
|
30
|
30
|
62
|
56
|
||||||||
|
YBK-14S
|
2.30
|
14
|
40
|
120
|
42
|
40
|
75
|
67
|
||||||||
|
YBK-15S
|
2.40
|
15
|
40
|
140
|
47
|
44
|
80
|
71
|
||||||||
|
YBK-16S
|
2.45
|
16
|
40
|
160
|
51
|
47
|
84
|
74
|
||||||||
|
YBK-18S
|
2.70
|
18
|
50
|
160
|
54
|
49
|
90
|
79
|
||||||||
|
YBK-20S
|
2.70
|
20
|
40
|
160
|
57
|
52
|
96
|
84
|
||||||||
|
YBK-30S
|
2.90
|
30
|
40
|
220
|
130
|
125
|
220
|
210
|
||||||||
|
Note: 1) Top loading: 3kg or Customized. 2) Materials: Al Alloy or Carbon Fiber.
3) Wind Resistance: 27m/s or Customized. 4) Driven Method: Hand Crank or Motorized by Electricity |
|
|
|
|
|
|
|
|
||||||||
Specification
Application
Emergency lightning protection for electric power, communications, buildings, military, etc., direct lightning protection, etc.
Main functions and features
1. The mobile lifting type lightning rod has a direct lightning strike, which can lead the lightning current into the earth, and play the role of direct lightning protection.
2. High-strength aluminum-magnesium alloy profiles are used, which are highly corrosion-resistant; the inner wall of the cylinder is sealed and connected by high-pressure wear-resistant porcelain treatment.
3. It has a strong anti-rotation function.
4. With self-installation function, it is convenient to move and transport. It can detect and maintain the tip device to make it work normally.
5. Strong wind resistance, capable of resisting wind of 60m/s.
6. The lightning protection radius is calculated according to the rolling ball method
7. It has the structural characteristics of high anti-corrosion, waterproof and dustproof, and long service life.
8. The lifting mode can be manual or electric alone, or integrated manual and electric.
9. Mechatronics controls the lifting, limiting, locking and sealing of the lightning rod. It can be controlled by electric cabinet or handle button.
