- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Megarevo
-
Model Number:
-
R10KH3
-
Input Voltage:
-
125-600V
-
Output Voltage:
-
380V AC
-
Output Current:
-
12.7A/15.9A/19.1A
-
Output Frequency:
-
50Hz/60Hz
-
Size:
-
530*200*600mm
-
Certificate:
-
CE Rohs
-
Warranty:
-
2 years
-
Weight:
-
29KG
-
Product Name:
-
Megarevo Inverter 3 phase 10KW Hybrid Solar System
-
Rated power:
-
8KW/10KW/12KW
-
Inverter type:
-
Three Phase Hybrid Inverter
-
Display:
-
LCD Display
-
Waveform:
-
Pure Sine Wave
-
MPPT voltage range:
-
180~850V
-
Grid voltage/range:
-
400/360~440V
-
Communication interface:
-
CAN/RS485
Quick Details
-
Output Type:
-
Three Phase
-
Type:
-
DC/AC Inverters, High Frequency
-
Inverter Efficiency:
-
99.9%
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Megarevo
-
Model Number:
-
R10KH3
-
Input Voltage:
-
125-600V
-
Output Voltage:
-
380V AC
-
Output Current:
-
12.7A/15.9A/19.1A
-
Output Frequency:
-
50Hz/60Hz
-
Size:
-
530*200*600mm
-
Certificate:
-
CE Rohs
-
Warranty:
-
2 years
-
Weight:
-
29KG
-
Product Name:
-
Megarevo Inverter 3 phase 10KW Hybrid Solar System
-
Rated power:
-
8KW/10KW/12KW
-
Inverter type:
-
Three Phase Hybrid Inverter
-
Display:
-
LCD Display
-
Waveform:
-
Pure Sine Wave
-
MPPT voltage range:
-
180~850V
-
Grid voltage/range:
-
400/360~440V
-
Communication interface:
-
CAN/RS485
Product Description
Features
1. Revo Hybrid Inverter is a high-quality inverter which can convert solar energy to AC energy and store energy into battery.
2. The inverter can be used to optimize self-consumption, store in the battery for future use or feed in to public grid. Work mode depends on PV energy and user’s preference. It can provide power for emergency use during the grid lost by using the energy from battery and inverter generated from PV.
2. The inverter can be used to optimize self-consumption, store in the battery for future use or feed in to public grid. Work mode depends on PV energy and user’s preference. It can provide power for emergency use during the grid lost by using the energy from battery and inverter generated from PV.
|
MODEL
|
R8KH3
|
R10KH3
|
R12KH3
|
|||
|
Input (PV)
|
|
|
|
|||
|
Max. power(kW)
|
12
|
15
|
18
|
|||
|
Max. DC voltage (V)
|
1000
|
|
|
|||
|
MPPT voltage range(V)
|
180~850
|
|
|
|||
|
AC output
|
|
|
|
|||
|
Rated output power(kVA)
|
8
|
10
|
12
|
|||
|
Max. output current(A)
|
12.7
|
15.9
|
19.1
|
|||
|
Grid voltage/range(V)
|
400/360~440
|
|
|
|||
|
Frequency (Hz)
|
50/60
|
|
|
|||
|
AC output topology
|
3W+N+PE
|
|
|
|||
|
Battery
|
|
|
|
|||
|
Battery voltage range(V)
|
125~600
|
|
|
|||
|
Max. charging voltage(V)
|
600
|
|
|
|||
|
Full battery voltage(V)
|
250
|
300
|
350
|
|||
|
Rated charge/discharge current(A)
|
40
|
40
|
40
|
|||
|
Battery type
|
lithium /Lead-acid
|
|
|
|||
|
Communication interface
|
CAN/RS485
|
|
|
|||
|
General Data
|
|
|
|
|||
|
Max. efficiency
|
99.5%
|
|
|
|||
|
Ingress protection
|
IP65/NEMA 3R
|
|
|
|||
|
Operation temperature
|
-25℃ ~ 60℃
|
|
|
|||
|
Dimensions W *D *H (mm)
|
530*200*600
|
|
|
|||
|
Weight(kg)
|
29
|
|
|
|||
|
Display
|
LCD, touch screen
|
|
|
|||
|
Interface:RS485/Wifi /4G/CAN/DRM
|
Yes/ Opt/ Opt/ Yes/ Yes
|
|
|
|||
|
Safety standard
|
IEC/EN62109-1/-2, IEC/EN62477-1
|
|
|
|||
Details Images
