Quick Details
-
Coating head:
-
Combinations for Comma coating and Gravure coating
-
Processing mode:
-
roll to roll
-
Double layers cycle drying oven:
-
Optional
-
Main Motor Brand:
-
ABB
-
Touch screen:
-
Simens
-
Web guide System:
-
Re /Italy
-
Tension Control System:
-
Mitsubishi
Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Heating type:
-
Electric/Thermo oil / Steam Gas (based on users)
-
Glue Type:
-
Water based/solvent based
-
Coating head:
-
Combinations for Comma coating and Gravure coating
-
Processing mode:
-
roll to roll
-
Double layers cycle drying oven:
-
Optional
-
Main Motor Brand:
-
ABB
-
Touch screen:
-
Simens
-
Web guide System:
-
Re /Italy
-
Tension Control System:
-
Mitsubishi
DATB-500/1800 Multi-Functional Adhesive Label paper Coating Machine
Application:
Our DATB-500/1800 Multi-Functional Adhesive Label paper Coating Machine is widly used for making Adhesive paper, Label paper ,adhsevie tape ,release paper ,Glassine paper, Wet Laminating reels ETC.There are two coating type, Doctor blade coating and rotogravure coating fixed on the coating head .
Suitable Material:
The DATB-500/1800 Multi-Functional Adhesive Label paper Coating Machine is mainly suitable for reel -type substrate coating production.The material such as :
Paper ,Opp ,Alumium,CPP ,PET ,Bopp ,Fabric ,ETC .
Characteristics:
1. Heating oven could be opened by hydraulic,The guide roller in the oven was driving synchronous with host machine
2. HMI ,Man and machine face to face interface touch screen.
3. High precision auto edge position correction system,Rewing roll will have high precision edge neat
4. With inflammable gas detecting alarm (select for solvent glue );
5. NON-Stop Machine station(Optional)
6. Double layers cycle drying oven, Both sides coating could be finished in One step. (Optional)
7. Each heating section is controlled independent. .
7. Current output type temperature control system makes heating quicker and electricity saving
8. Rewinding controlled by auto diminishing taper tension,it could avoid the materials damaged
9 . Machine should be installed on firmly cement ground, need no special foundation, fix expansion bolt on key parts
Main Specification
|
Common matters |
Raw material |
PET, BOPP, PVC, PE, PI,Fabric ,Copper foil,Aluminum foil, etc., (User Advice) |
|
Machine speed |
100-150m/min below (User Advice) |
|
|
Tasks speed |
80-120m/min below (User Advice) |
|
|
Raw material width |
500~1800mm (User Advice) |
|
|
Guide Roll |
Φ100~120mm Anodizing or hard chrome surface treatment (User Advice) |
|
|
Control motor |
AC Vector Motor, AC Servo Motor (User Advice) |
|
|
Machine color |
MUNCELL NO. F-299002 (User Advice) |
|
|
WINDER |
Unwinding & rewinding part |
2-axis turrent type or 1-axis center type (User Advice) |
|
Reel outer Dia |
Φ600, Φ800, Φ1000, Φ1200mm (User Advice) |
|
|
How to connect raw material |
Automatic or manual connection (User Advice) |
|
|
Splicing type and direction |
Flying Arm(T/B), Tapeless(T/B) (User Advice) |
|
|
Air-Shaft fixing type |
3" Shaft + Adapter (AL or MC nylon) (User Advice) |
|
|
|
||
|
Dryer |
Chamber inner temperature |
Max. 200 °C (User Advice) |
|
Hot blow injection type |
Z-Nozzle |
|
|
Heating source |
Electric heater, gas burner, Thermal Oil, Strea heating (User Advice) |
|
|
Unit Dryer length |
1.8m , 2.2m, 3m, 4m (User Advice) |
|
|
|
||
|
Coating Head |
Developed unit |
There are Comma, Gravure coating method .(Mayer bar could be fixed follow Users) |
MACHINE PICTURES:
1. DATB-500/1800 Multi-Functional Adhesive Label paper Coating Machine
2. DATB-500/1800 Multi-Functional Adhesive Label paper Coating Machine PRODUCTS SAMPLES
OUR SERVICE FOR DATB-500/1800 Multi-Functional Adhesive Label paper Coating Machine
1. Purchase Service
DABA COMPANY have a specialize and efficiency working team.If you are new on the printing and packing area ,Some samples of your products could be shew to us will be appreicate ,we will give you specialized suggestion of whole work .
2. Shipping Service
DABA COMPANY have a spcialized and independent department which just for shipping the buyer's goods .The workers are knowing T/T,L/C Items well.all Exported documents could be made perfectly .
DABA COMPNAY copperate with the most famous shipping company in China also.They could provide the best and economic shipping ways to the buyer's port.
3 . Installation Services
Installation Services are available with all DABA Company machines.DABA Comapny will dispatch technician to The Buyer's factory to installation and preoperation of machines . But the buyer need to surpply the round trip tickets ,food ,hotel cost.
4.Clients Training Services
DABA Company advise The buyer could send own technican come to DABA factory to learn how to operate machines.DABA Company technician will teach and train the lerners hand by hand till he can operate machine by himself.
Obviouslly, Traning within Installation period is acceptable.
5.After Sales Service
DABA Company machines guarantee time is one year.
Many easy broken spare parts will be prepared in the tool box together with machines.
Any parts broken ,Just a pictures or a videos.
The new free parts will reach within 3-7 Express working days .
