Quick Details
-
Place of Origin:
-
Jiangxi, China
-
Brand Name:
-
tking
-
Model Number:
-
tk14
-
Size:
-
custom
-
Working temperature:
-
550degree C
-
Light transmission:
-
92%
-
Color:
-
Clear
-
Material:
-
Borofloat33 B270 D263T Pyrex770
Quick Details
-
Type:
-
Clear Quartz Plate
-
Application:
-
Optical Instrument, spotlight
-
Thickness:
-
0.5-30mm, 0.2mm 0.3mm 0.4mm 0.5mm 0.7mm 0.9mm
-
Place of Origin:
-
Jiangxi, China
-
Brand Name:
-
tking
-
Model Number:
-
tk14
-
Size:
-
custom
-
Working temperature:
-
550degree C
-
Light transmission:
-
92%
-
Color:
-
Clear
-
Material:
-
Borofloat33 B270 D263T Pyrex770
I
ntroduction:
A particularly low coefficient of thermal expansion is what makes BOROFLOAT
®
glass
remarkably resistant to high temperature levels. Our borosilicate glass is proven to stand up to high and fluctuating temperatures typical of applications such as high-performance lamps, cinema projectors and inspection panels for chemical reactors. Even with applications where rapid cooling down from higher temperatures is the requirement, BOROFLOAT
®
glass easily passes the test. For example, the temperature difference between a hot panel center and a cold panel edge.
Outstanding thermal resistance
· Very good temperature stability
· Excellent resistance to thermal shock
· Can be thermally toughened
· Can be thermally shaped (3D)
|
Thermal properties |
|
|
Coefficient of Linear Thermal Expansion (C.T.E.) α (20 - 300 °C) |
3.25 x 10-6 K -1 * |
|
Specific heat capacity c p (20 - 100 °C) |
0.83 kJ/(kg·K) -1 |
|
Thermal conductivity λ (90 °C) |
1.2 W/(m·K) -1 |
|
|
|
|
Maximum operating temperatures |
|
|
For short-term usage (< 10 h) |
500 °C |
|
For long-term usage (≥ 10 h) |
450 °C |
|
Viscosity of BOROFLOAT ® 33 |
|
|
Working Point (10 4 dPas) |
1270 °C |
|
LITTLETON temperature / Softening Point (10 7,6 dPas) |
820 °C |
|
Annealing Point (10 13 dPas) |
560 °C |
|
Strain Point (10 14,5 dPas) |
518 °C |
|
Transformation temperature (T g ) |
525 °C |
