Quick Details
-
Brand Name:
-
HANG CHA
-
Fork Length:
-
1070mm
-
Fork Width:
-
122mm
-
Overall Dimensions:
-
2780*1225*2150mm
-
Load center:
-
500 MM
-
Turning radius:
-
2400 MM
-
Certification:
-
CE/IOS
Quick Details
-
Min. Lifting Height:
-
145 mm
-
Warranty:
-
1 Year
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
HANG CHA
-
Fork Length:
-
1070mm
-
Fork Width:
-
122mm
-
Overall Dimensions:
-
2780*1225*2150mm
-
Load center:
-
500 MM
-
Turning radius:
-
2400 MM
-
Certification:
-
CE/IOS
New 3 Ton Diesel Forklift CPCD30
OUTLINE
Applied the advanced outline designing method, the truck is designed with stream, sporty outline, and thanks to the new design, all the exposed parts are metal made, which is firm and reliable.
SAFETY
Thanks to the long wheelbase design, the longitudinal stability of whole truck is improved, the residual load capacity at same height is improved greatly. At the same time, it prolongs the working life time of steering tyre by reducing the rear axle load.
COMFORTABLE
The smaller steering wheel, extra space for foot and operator space, wider forward visibility, all these improve operator’s comfort and release operator’s fatigue.
The applied integral engine cover strengthens the rigidity of the cover and reduces the noise at the same time.
MAINTENANCE
Easy access to engine and transmission due to applied bolt type fastened front plate, greatly improving the convenience of daily maintenance and repair.
RELIABILITY
Enlarged cross section of rear OHG improves the air intake capacity, and reduces air intake resistance, which makes internal combustion more complete and prolongs engine life.
| Brand | HANG CHA | ||||||
| Model | CPCD30 | CPCD35 | CPCD30 | CPCD35 | CPCD30 | CPCD35 | |
| Power Type | Diesel | ||||||
| Rated Load Capacity | Q(kg) | 3000 | 3500 | 3000 | 3500 | 3000 | 3500 |
| Load Centre | C(mm) | 500 | |||||
| Rated Lift Height | H3(mm) | 3000 | |||||
| Free Lift Height | H2(mm) | 100 | |||||
| Fork Size (L×W×T) | mm | 1070×125*45 | |||||
| Mast Tilt Angle (F/R, α°/β°) | deg | 6°/12° | |||||
| Tyre (Front x 2) | mm | 28*9-15-12PR | |||||
| Tyre (Rear x 2) | mm | 6.5-10-10PR | |||||
| Battery | V/Ah | 12/90 | |||||
| Engine Model | C490BPG -37(EUⅢ) | C240NKFC-01 (EUⅢ) | S4S (EUIII) | ||||
| Engine Manufacturer | XINCHAI | ISUZU | |||||
| Rated Output / r.p.m. | kw | 36.8/2650 | 34.5/3500 | 35.4/2250 | |||
| Rated Torque / r.p.m. | N·m | 156/1800 | 139/1800 | 177/1700 | |||
| No.of Cylinder | 4 | ||||||
| Bore x Stroke | mm | 90×105 | 86×102 | 94*120 | |||
| Displacement | cc | 2670 | 2369 | 3331 | |||
| Transmission Type | Powershift ( Manual) | ||||||
