Quick Details
-
Brand Name:
-
Runshine
-
Model Number:
-
RXDWC-40
-
Dimension(L*W*H):
-
1.8x1.2x1.15m(packing)
-
Weight:
-
880kg
-
Warranty:
-
14 months
-
Certification:
-
CE certification
-
chip diameter:
-
8 inch
-
diesel engine:
-
Changchai
-
power:
-
18hp,22hp and 40hp
-
blades:
-
1 stational,2 rotary
-
flywheel house:
-
round or square
-
feeding hoper:
-
design as your request
-
feeding roller:
-
single or double
-
feeding system:
-
hydraulic or mechanical
Quick Details
-
Use:
-
wood,branches,leaves
-
Production Capacity:
-
9-13cbm/h
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Runshine
-
Model Number:
-
RXDWC-40
-
Dimension(L*W*H):
-
1.8x1.2x1.15m(packing)
-
Weight:
-
880kg
-
Warranty:
-
14 months
-
Certification:
-
CE certification
-
chip diameter:
-
8 inch
-
diesel engine:
-
Changchai
-
power:
-
18hp,22hp and 40hp
-
blades:
-
1 stational,2 rotary
-
flywheel house:
-
round or square
-
feeding hoper:
-
design as your request
-
feeding roller:
-
single or double
-
feeding system:
-
hydraulic or mechanical
Manufacturer factory 40hp diesel wood chipper in forestry machinery:
Weifang Runsing RXDWC-40 40hp wood chiper :
1- RXDWC-40 Changchai diesel engine.
2- Hydrualic feeding system .
3- 360 degrees rotates discharge hood.
4- 3 blades: 1 stationary,2 rotary
5- Round flywheel house and square flywheel house,easy to change knifes.
6- We have 18hp,22hp,40hp models to choose.
Features:
.CE approved,easy to operate
.3 blades,easy to change
.9-13cbm/h capacity.
.10-80cm chips size.
.8 inch chip diameter.
Useage:
.This diesel wood chipper is used for cutting wood, branches and leaves into smaller wood chips,pieces,for covering crops or mulching, specially for using granulated fuels.
.This wood chipper employs steel disc with rectangular blades mounted upon it and fans upon the
other side. W hile the disc rotates, powered by PTO shaft or engines, the blades cut the wood ,branch or leaves into pieces and the fans blow the chips out from discharge chute.
Parameters:
|
Modle |
DWC-18/DWC-22 |
DWC-40 |
|
|
Engine |
model |
professional or Changchai CY1105or1115 diesel engine |
Laidong 4L22Bdiesel engine |
|
type |
Singlec ylinder, Horizontal,four-stroke |
Four cylinders, Horizontal,four-stroke |
|
|
Rated power |
16.2KW/2200rpm |
25.7KW/2350rpm |
|
|
Fule consumption rate |
<245g/KW.h |
<238g/KW.h |
|
|
Engine oil consumption |
<1.5g/KW.h |
<1.5g/KW.h |
|
|
Cooled style |
Water-cooled (evaporation) |
Water-cooled |
|
|
start |
Electric start |
Electric start |
|
|
Feeding system |
Mechanical or hydraulic |
hydraulic |
|
|
Chipper capability |
150mm(Max.To 200mm) |
200mm |
|
|
Flywheel diameter |
640mm |
640mm |
|
|
Flywheel weight |
85kgs |
85kgs |
|
|
Blades numbers |
1stationary blade,2 rotary blades |
1 stationary blade,2 rotary blades |
|
|
Feed Hopper inner Opening |
200*220mm |
200*220mm |
|
|
Discharge Hood Height |
2000mm |
2000mm |
|
|
Rated RPM |
1080 |
1280 |
|
|
Weight |
650kgs |
800kgs |
|
|
Working efficiency |
7-11cbm/h |
9-13cbm/h |
|
Photos:
