Quick Details
-
Brand Name:
-
KAMO
-
Weight:
-
10000 kg
-
Product name:
-
Cement Silo
-
Type:
-
100t
-
Tank height:
-
9
-
Cone height:
-
2.6m
-
Diameter:
-
3
-
Section quantity:
-
6
-
Discharging height:
-
≥1.5m
-
Landing leg height:
-
≥4.1m
-
Local Service Location:
-
None
Quick Details
-
Machine Type:
-
Powder silo
-
Core Components:
-
tank,cone
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
KAMO
-
Weight:
-
10000 kg
-
Product name:
-
Cement Silo
-
Type:
-
100t
-
Tank height:
-
9
-
Cone height:
-
2.6m
-
Diameter:
-
3
-
Section quantity:
-
6
-
Discharging height:
-
≥1.5m
-
Landing leg height:
-
≥4.1m
-
Local Service Location:
-
None
CE ISO Certificate 50~1000 Tons Mini Small Bolted Vertical Parts Cement Silo In Concrete Mixing Plant
Cement silos are generally used in the bulk cement storage of concrete mixing plants, suitable for storing various bulk building materials such as cement, fly ash, etc. The silo body is equipped with a material level system that can display the location and stock of materials, and the hole device can avoid material deposition Too long and strong. The cement bin and screw conveyor can be used together to transport materials to various locations. The bin body is easy to install, safe and reliable, and is an ideal bulk storage tank for various mixing stations.
Cement silos generally have two types, integral welding type and bolted segmented type, with an output of 50 tons to 1000 tons. The integrally welded cement silo is suitable for transportation by flatbed trucks, and the bolted segmented cement silo is suitable for container transportation.
| Item | 50t | 80t | 100t | 120t | 150t | 200t | 300t | |
| Tank | Height(m) | 4.5 | 7.5 | 9 | 10.5 | 13.5 | 9 | 8.25 |
| Diameter(m) | 3 | 3 | 3 | 3 | 3 | 4.5 | 5.5 | |
| Section quantity | 3 | 5 | 6 | 7 | 9 | 6 | 5.5 | |
| Each section is divided into three pieces,the height of each section is 1.5 meters. | ||||||||
| Cone | Top cover | Top cover is divided into two pieces. | ||||||
| Height(m) | 2.6 | 2.6 | 2.6 | 2.6 | 2.6 | 3.8 | 4.8 | |
| Pieces | Cone is divided into 5 pieces. | |||||||
| Discharging | Discharging height(m) | ≥1.5 | ≥1.5 | ≥1.5 | ≥1.5 | ≥1.5 | ≥1.5 | ≥1.5 |
| Landing leg height(m) | ≥4.1 | ≥4.1 | ≥4.1 | ≥4.1 | ≥4.1 | ≥5.3 | ≥6.3 | |
| Landing leg height depend on discharging height. | ||||||||
KAMO focus on the packaging of our machinery, we fix the goods in the container in order to make sure our goods can reach customer's site safely. Before we book the shipping, we will check with our customer which port terninal is easier and better to do customs clearance. Our customer's satisfaction is our goal.
KAMO not only provides machinery, but only provides good services to our customers.
We have our own international sales team to guide our customers choose the products.
Established in 1985,
Zhengzhou KAMO Machinery Co.,ltd
(hereinafter referred as KAMO) is a joint-stock enterprise in the field of C
oncrete Batching Plant, Dry Mortar Mixing Plant, Terrazzo Tile Machine, Metal Recycling Plant
.
KAMO team
is located in Zhengzhou machinery industrial park, covering nearly
80,000 m2
, has many advanced processing facilities and technology. KAMO integrated production, research, sales, development together and regards product quality and service as our mission.
KAMO team
exported our machinery to Russia, Kazakhstan,Turkey,Spain,Qatar,South Africa,Zimbabwe,Coted'Ivoire, Vietnam, Thailand, Cambodia, India, Malaysia,Korea,Japan,etc.
