Quick Details
-
Mold Height(mm):
-
450 - 1200 mm
-
Ejector Stroke(mm):
-
350 mm
-
Ejector Force(kN):
-
245 kN
-
Theoretical Shot Volume(cm³):
-
5880 cm³
-
Injection Rate (g/s):
-
1001 g/s
-
Injection Weight (g):
-
5350 g
-
Screw Speed (rpm):
-
0 - 110 rpm
-
Screw diameter (mm):
-
120 mm
-
Screw L/D Ratio:
-
22
-
Distance between Tie Bars:
-
1110x1110 mm
-
Weight (KG):
-
60000 kg
-
Place of Origin:
-
Jiangsu, China
-
Open Stroke(mm):
-
1160 mm
-
Model Number:
-
SZ-10000A
-
Brand Name:
-
SZ
-
Power (kW):
-
90 kW
-
Product name:
-
Solid reputation cheap plastic injection molding machines sale for
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Keyword:
-
cheap injection molding machines
-
Plastic Type:
-
Thermoplastic
-
Automatic:
-
yes
-
Advantages:
-
Energy saving and high efficiency
-
Machine dimension(L*W*H):
-
12.38*2.8*3.5m
-
Function:
-
Multifunctional plastic Products Making
-
category:
-
plastic injection machinery
-
Oil Tank Capacity:
-
1700L
Quick Details
-
Distance between Tie Bars(Width)(mm):
-
1110mm
-
Distance between Tie Bars(Height)(mm):
-
1110mm
-
Plasticizing Capacity(g/s):
-
1001
-
Mold Height(mm):
-
450 - 1200 mm
-
Ejector Stroke(mm):
-
350 mm
-
Ejector Force(kN):
-
245 kN
-
Theoretical Shot Volume(cm³):
-
5880 cm³
-
Injection Rate (g/s):
-
1001 g/s
-
Injection Weight (g):
-
5350 g
-
Screw Speed (rpm):
-
0 - 110 rpm
-
Screw diameter (mm):
-
120 mm
-
Screw L/D Ratio:
-
22
-
Distance between Tie Bars:
-
1110x1110 mm
-
Weight (KG):
-
60000 kg
-
Place of Origin:
-
Jiangsu, China
-
Open Stroke(mm):
-
1160 mm
-
Model Number:
-
SZ-10000A
-
Brand Name:
-
SZ
-
Power (kW):
-
90 kW
-
Product name:
-
Solid reputation cheap plastic injection molding machines sale for
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Keyword:
-
cheap injection molding machines
-
Plastic Type:
-
Thermoplastic
-
Automatic:
-
yes
-
Advantages:
-
Energy saving and high efficiency
-
Machine dimension(L*W*H):
-
12.38*2.8*3.5m
-
Function:
-
Multifunctional plastic Products Making
-
category:
-
plastic injection machinery
-
Oil Tank Capacity:
-
1700L
3D SHOW ROOM
Product Description
Technical Parameter
|
Screw diameter
|
mm
|
100
|
110
|
120
|
130
|
|||
|
Screw L/D ratio
|
L/D
|
24.2
|
22
|
20.2
|
18.6
|
|||
|
Shot weight
|
gram
|
3715
|
4496
|
5350
|
6280
|
|||
|
Injection capacity
|
cm3
|
4083
|
4941
|
5880
|
6901
|
|||
|
Injection pressure
|
Mpa
|
206
|
171
|
143
|
122
|
|||
|
Theoretical injection rate
|
g/s
|
695
|
841
|
1001
|
1175
|
|||
|
Plastic capacity
|
g/s
|
96
|
116
|
130
|
148
|
|||
|
Injection stroke
|
mm
|
520
|
|
|
|
|||
|
Screw torque
|
N.m
|
8690
|
|
|
|
|||
|
Max screw rotate speed
|
r/min
|
110
|
|
|
|
|||
|
Clamping force
|
Ton
|
10000
|
|
|
|
|||
|
Opening stroke
|
mm
|
1160
|
|
|
|
|||
|
Space between tie bars
|
mm
|
1110*1110
|
|
|
|
|||
|
Mould height
|
mm
|
450~1200
|
|
|
|
|||
|
Max daylight
|
mm
|
2360
|
|
|
|
|||
|
Ejector force
|
KN
|
245
|
|
|
|
|||
|
Ejector stroke
|
mm
|
350
|
|
|
|
|||
|
Ejector quantity
|
|
21
|
|
|
|
|||
|
Oil pump motor
|
kw
|
90
|
|
|
|
|||
|
Pump pressure
|
Mpa
|
16
|
|
|
|
|||
|
Heating power
|
kw
|
68.45
|
|
|
|
|||
|
Machine size
|
M
|
12.38*2.8*3.5
|
|
|
|
|||
|
Machine weight
|
ton
|
60
|
|
|
|
|||
|
Oil tank capacity
|
L
|
1700
|
|
|
|
|||
|
International designation
|
|
10000—8410
|
|
|
|
|||
Details Images
WHAT CAN WE DO？
About Components
Hydraulic pump
ECKERLE—GERMANY
Proportional Valve
YUKEN-JAPAN
Reversing Valve
YUKEN-JAPAN
Hydraulic Motor
ZY—ITALY
Oil Hose
KIMBERLER —GERMANY
Computer
TECHMATION —TAIWAN
Limit Switch
OMRON-JAPAN
Proximity Swith
FORTEK—TAIWAN
Soilid State Relay
RORTEK —TAIWAN
Contactor
SCHNEIDER—FRENCE
Air—break Switch
SCHNEIDER—FRENCE
Servo Motor
PHASE—ITALY
