Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Bcom
-
Model Number:
-
95223
-
Resolution:
-
3MP
-
Image Sensor:
-
1/2.7'' 3Megapixel CMOS
-
Effective Pixels:
-
2304(H) x 1296(V)
-
Alarm Trigger:
-
PIR human-body detection
-
Wireless:
-
2.4G WIFI (IEEE802.11b/g/n)
-
Capacity:
-
9000mAh rechargeable Li batteries
-
Working Time:
-
1.5-2 months
-
Storage:
-
SD card(Max.128GB), Cloud storage
-
Dimensions:
-
133 x 130 x 127 mm
-
Operating Temperature:
-
-20 °C to 50 °C
Quick Details
-
Special Features:
-
Human Motion Tracking, Face detection, Motion Detection, Waterproof / Weatherproof, Two-way Audio, Low Power
-
Function:
-
Two-way Audio, NIGHT VISION, Waterproof / Weatherproof, Wide Angle
-
Customized support:
-
Online technical support, Customized logo, Software reengineering, OEM, ODM
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Bcom
-
Model Number:
-
95223
-
Resolution:
-
3MP
-
Image Sensor:
-
1/2.7'' 3Megapixel CMOS
-
Effective Pixels:
-
2304(H) x 1296(V)
-
Alarm Trigger:
-
PIR human-body detection
-
Wireless:
-
2.4G WIFI (IEEE802.11b/g/n)
-
Capacity:
-
9000mAh rechargeable Li batteries
-
Working Time:
-
1.5-2 months
-
Storage:
-
SD card(Max.128GB), Cloud storage
-
Dimensions:
-
133 x 130 x 127 mm
-
Operating Temperature:
-
-20 °C to 50 °C
wireless video doorbell
|
Camera
|
|
|
|
|||
|
Image Sensor
|
|
1/2.7'' 3Megapixel CMOS
|
|
|||
|
Effective Pixels
|
|
2304(H) x 1296(V)
|
|
|||
|
Shutter
|
|
1/15~1/10,000s
|
|
|||
|
Min. Illumination
|
|
Color 0.1Lux@F2.0,
Black/White 0.01Lux@F2.0 |
|
|||
|
IR Distance
|
|
Night visibility up to 10m
|
|
|||
|
Day/Night
|
|
Auto(ICR)/Color/B&W
|
|
|||
|
WDR
|
|
DWDR
|
|
|||
|
Lens&FOV(H/V/D)
|
|
4.0mm@F1.95, 116°/83°/109°
|
|
|||
|
|
|
|
|
|||
|
Video&Audio
|
|
|
|
|||
|
Compression
|
|
H.264
|
|
|||
|
Bit Rate
|
|
32Kbps~2Mbps
|
|
|||
|
Frame Rate
|
|
1~25fps
|
|
|||
|
Dual Stream
|
|
Yes
|
|
|||
|
Audio Input/Output
|
|
Built-in mic/speaker
|
|
|||
|
|
|
|
|
|||
|
Network
|
|
|
|
|||
|
Alarm Trigger
|
|
PIR human-body detection
|
|
|||
|
Wireless Security
|
|
64/128-bit WPA/WPA2, WPA-PSK/WPA2-PSK, WPS
|
|
|||
|
Communication Protocol
|
|
HTTP, DHCP, DNS, TCP/IP
|
|
|||
|
Interface Protocol
|
|
Private
|
|
|||
|
Wireless
|
|
2.4G WIFI (IEEE802.11b/g/n)
|
|
|||
|
Mobile Phone OS
|
|
iOS 9 or later, Android 5 or later
|
|
|||
|
Security
|
|
AES128
|
|
|||
|
Max. User Access
|
|
4
|
|
|||
|
|
|
|
|
|||
|
Battery&PIR
|
|
|
|
|||
|
Capacity
|
|
9000mAh rechargeable Li batteries
|
|
|||
|
Stand-by Current
|
|
200-800 µA (average)
|
|
|||
|
Working Current
|
|
150-200 mA (IR off)
|
|
|||
|
Stand-by Time
|
|
6 months
|
|
|||
|
Working Time
|
|
1.5-2 months (varies based on settings, usage & temperature)
|
|
|||
|
PIR Detection Range
|
|
Max. 9m
|
|
|||
|
PIR Angle
|
|
120°
|
|
|||
|
|
|
|
|
|||
|
General
|
|
|
|
|||
|
Operating Temperature
|
|
-20 °C to 50 °C
|
|
|||
|
IP Rating
|
|
IP65
|
|
|||
|
Power Supply
|
|
DC 5V/1A
|
|
|||
|
Power Consumption
|
|
Max. 2W
|
|
|||
|
Optional Accessory
|
|
Solar panel
|
|
|||
|
Storage
|
|
SD card(Max.128GB), Cloud storage
|
|
|||
|
Dimensions
|
|
133 x 130 x 127 mm
|
|
|||
|
Net Weight
|
|
2KG
|
|
|||
