Thermal Transfer Products Copper Tube and Fin Mobile Hydraulic Oil Coolers / API HEAT TRANSFER / TTP AOHM/AOVHM

Thermal Transfer Products Copper Tube and Fin Mobile Hydraulic Oil Coolers

API Heat Transfer's full line of Thermal Transfer Products standard mobile oil coolers is proven to stand-up in some of the toughest off-road environments. Our oil coolers are available with a wide variety of standard options to best suit each application and offer maximum performance.

COPPER TUBE AND FIN PRODUCT HIGHLIGHTS

• Aluminum or Steel fins available
• Up to +100 HP of heat removal from hydraulic oil
• Cost effective, industry proven designs
• Large range of standard sizes

STANDARD PRODUCT OPTIONS

• 12 or 24 volt DC fans
• Hydraulic fan motor drive
• Built-in pressure bypass (30 or 60 psi for cold start-up)
• Heresite coating for offshore or corrosive environment operation

CUSTOMER FOCUSED AND DRIVEN

• All catalog product is available with short lead-times
• Expert application engineers available to select and size the right product for your application
• Custom designs are available

INDUSTRY APPLICATIONS

Our oil coolers are used in a wide variety of mobile applications across the globe.

• Commercial duty lawnmowers
• Municipal street cleaners
• Hydrostatic drives
• Tow-behind compressor lube cooling
• Construction equipment
• Underground mining
• Engine oil cooling

Thermal Transfer Products Brazed Aluminum Mobile Hydraulic Oil Coolers

Made with 100% brazed aluminum bar and plate construction, API Heat Transfer's full line of Thermal Transfer Products standard mobile oil coolers is proven to stand-up in some of the toughest off-road environments. Our oil coolers are available with a wide variety of standard options to best suit each application and offer maximum performance.

BRAZED ALUMINUM (P-BAR) HIGHLIGHTS

• 100% rugged bar and plate construction
• Up to +400 HP of heat removal from hydraulic oil
• Highest performing internal turbulator for maximum performance
• Low-clogging / easy maintenance air side cooling fins

STANDARD PRODUCT OPTIONS

• 12 or 24 volt DC fans
• Hydraulic fan motor drive
• Built-in pressure bypass (30 or 60 psi for cold start-up)
• Heresite coating for offshore or corrosive environment operation

CUSTOMER FOCUSED AND DRIVEN

• All catalog product is available with short lead-times
• Expert application engineers available to select and size the right product for your application
• Custom designs are available

INDUSTRY APPLICATIONS

Our oil coolers are used in a wide variety of mobile applications across the globe.

• Commercial duty lawnmowers
• Municipal street cleaners
• Hydrostatic drives
• Tow-behind compressor lube cooling
• Construction equipment
• Underground mining
• Engine oil cooling

Thermal Transfer Products Copper Tube and Fin Mobile Hydraulic Oil Coolers

API Heat Transfer's full line of Thermal Transfer Products standard mobile oil coolers is proven to stand-up in some of the toughest off-road environments. Our oil coolers are available with a wide variety of standard options to best suit each application and offer maximum performance.

COPPER TUBE AND FIN PRODUCT HIGHLIGHTS

• Aluminum or Steel fins available
• Up to +100 HP of heat removal from hydraulic oil
• Cost effective, industry proven designs
• Large range of standard sizes

STANDARD PRODUCT OPTIONS

• 12 or 24 volt DC fans
• Hydraulic fan motor drive
• Built-in pressure bypass (30 or 60 psi for cold start-up)
• Heresite coating for offshore or corrosive environment operation

CUSTOMER FOCUSED AND DRIVEN

• All catalog product is available with short lead-times
• Expert application engineers available to select and size the right product for your application
• Custom designs are available

INDUSTRY APPLICATIONS

Our oil coolers are used in a wide variety of mobile applications across the globe.

• Commercial duty lawnmowers
• Municipal street cleaners
• Hydrostatic drives
• Tow-behind compressor lube cooling
• Construction equipment
• Underground mining
• Engine oil cooling

TTP Engine Cooling Modules

API Heat Transfer offers Thermal Transfer Products manufactured custom OE engine cooling modules for small gasoline engines to large-horsepower turbo diesel applications. Your choice of a variety of materials and core types (S-BAR, T-BAR, or P-BAR) offers design flexibility for high-performing radiators, CAC’s, or oil cooling. Full system modeling and validation of cooling modules is provided.

Core types

EXTRUDED TUBULAR BAR | RUGGED & REFINED

T-BAR™ (tubular micro-channel extrusion) brings you the most refined cooling technology on the market today.

• Engineered with minimal components in an ideally simplified configuration
• Unrivaled strength and rigidity to ensure durable performance
• A flexible design using an extruded flow path
• A high-performing, cost-effective domestic aluminum solution

PLATE & BAR | HIGH VOLUME & LOW VARIETY APPLICATIONS

P-BAR™ (custom plate & bar) is your best heat-transfer solution for higher volume (qty.) applications, and when competitive costs are key.

• Custom-engineered engine cooling with remarkable heat rejection
• High performance for mobile or industrial applications
• A flexible design
• A cost-effective LCC aluminum solution

SEAM WELDED TUBE | RUGGED & REFINED

S-BAR™ is the most affordable, high-flow cooling technology on the market today.

• A high-strength automotive style core design
• Durable, multi-row tube to header plate design
• Engineered for use in applications with higher temperatures and heat loads
• A lightweight, reliable and cost-effective aluminum solution

Bar and Plate Heat Exchangers

API Heat Transfer's line of Airtech and Covrad air cooled all-aluminum brazed bar and plate heat exchangers are supplied as a vital component to our mobile and industrial OEMs' products. Our flexible bar and plate construction allows countless core combinations and sizes, custom designed to your exact requirements with minimal or no tooling costs. Combi-cooler designs are available to cool multiple fluids in a single brazed unit.

PRODUCT TYPES AVAILABLE.

• Engine cooling systems
• PCR (pre-cooler, cooler, reheater) for refrigerated air dryers
• Charge air coolers
• Radiators
• Oil coolers
• Aftercoolers
• Combination coolers

Our bar and plate coolers feature a wide variety of thermally efficient internal and external fin patterns. Fins are laid between aluminum braze sheets and fitted with header and face bars. The assembled unit is placed into one of our modern brazing furnaces where precise control of time and temperature produces a unified core. Manifolds designed to meet each customer's particular piping requirements are welded into place to complete the cooler. We can also supply cores when manifolds already exist or must be fitted in the field.

These rugged, compact, light-weight units are ideal for both on- and off- highway markets. API Heat Transfer can also add value beyond the component cooler by packaging a complete cooling system consisting of multiple coolers (e.g., radiator, charge air cooler, hydraulic oil cooler).

From small individual coolers to large complex engine cooling systems, API Heat Transfer will design and manufacture the heat transfer solution that's right for you. Our engineering team is continually developing additional fin geometries to improve heat transfer efficiency so we can meet or exceed your expectations.

Our products perform-AIRTECH

Whether you're looking for a custom heat transfer solution (our specialty) or a more standard product, you’ll find what you need right here. That's because we offer the broadest range of heat transfer products available. And if you don’t find the solution you’re looking for, let's talk so our team of experts can create it.

Engine Cooling Systems

API Heat Transfer is your global source for engine cooling solutions. We’re equipped to offer unparalleled engine cooling performance to meet the rigorous requirements of mobile and industrial customers worldwide.

We offer an array of internal and external fin configurations that produce some of the most efficient air-cooled heat exchange cores in the industry, so your engine has more power to perform, even under the harshest conditions.

We focus our engineering expertise on the markets you serve. By understanding your customer applications, we’re able to offer a broad spectrum of components and complete engine cooling systems designed to fit the needs of engine markets across the world.

OUR TECHNOLOGIES.

API Heat Transfer offers the broadest, most complete air-cooled product lines available.

• CAB or vacuum-brazed aluminum
• Bar-plate
• Micro-channel
• Tube and header
• TBAR
• Copper-brass
• Mechanical-bond
• Soldered
• Bolted tank

API heat transfer

Five brands.
One answer for heat transfer.

With a legacy of innovation dating back to 1879, our brands are known the world over as leaders in their respective fields. They provide our customers with the technologies and product portfolio needed to handle any heat transfer project. From custom to pre-engineered designs, API Heat Transfer offers comprehensive solutions – all from one company.

Airtech:

Industrial air cooled heat exchangers

Airtech heat exchangers are available in bar and plate, tube and header, and micro-channel constructions. Airtech coolers offer unparalleled performance in a rugged yet compact and lightweight package for industrial applications.

Basco:

Shell and tube heat exchangers

Basco heat exchangers include a full range of custom-engineered and commercial standards. Available in a wide variety of materials, custom solutions are made to meet the most stringent specifications as well as all international pressure codes. Designs include TEMA types, extended surface, hairpins, surface condensers, and a full line of on-engine water-cooled charge-air-coolers and heat exchangers.

Covrad:

Engine cooling systems

Established in 1884, Covrad products employ the latest aluminum and copper-brass air cooled technologies to produce custom engine cooling systems for the full range of diesel-powered equipment.

Schmidt:

Plate heat exchangers and thermal systems

Introduced in 1879, Schmidt plate heat exchangers include industry-leading gasketed (special and standard gaskets), all-welded, semi-welded, double-wall, and brazed products for most industrial markets.

Thermal process systems include evaporation systems, dealcoholization plants, and pasteurizers used for thermal treatment of various liquids in all industries.

TTP:

Heat exchangers sold through distribution

TTP offers a complete portfolio of pre-engineered products available from API Heat Transfer, sold through a global network of distribution partners . This includes a broad range of fluid power related heat exchangers (oil-water, oil-air, air-air) utilized in mobile and industrial applications, along with custom engine cooling modules.
