The addition of a blowing flame-retardant device is flammable during cutting and has a flame-retardant effect.
- Product Details
- {{item.text}}
Quick Details
-
Graphic Format Supported:
-
AI, PLT, DXF, BMP, Dst, DXP
-
Cooling Mode:
-
WATER COOLING
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Laser AE
-
Dimension(L*W*H):
-
3200*2010*1190MM
-
Weight (KG):
-
100 KG
-
Mode of Operation:
-
CO2 Laser
-
Configuration:
-
CO2 Laser tube
-
Product name:
-
C02 Laser Engraving Cutting Machine
-
Laser power:
-
80W/100W/130W/150W
-
Function:
-
Cutting Engraving Non-metal Materials
-
Cutting material:
-
Acrylic Wood Mdf Plywood Plactical
-
Laser tube:
-
RECI EFR
-
After-sales Service Provided:
-
Online Support
-
Software:
-
LaserCAD support CAD output
-
Working area:
-
1300*2500MM
-
Cutting depth:
-
0-18mm
-
Location:
-
0.01mm
Quick Details
-
Engraving Area:
-
1300*2500mm
-
Laser Type:
-
CO2
-
Engraving Speed:
-
0-500mm/s
-
Graphic Format Supported:
-
AI, PLT, DXF, BMP, Dst, DXP
-
Cooling Mode:
-
WATER COOLING
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Laser AE
-
Dimension(L*W*H):
-
3200*2010*1190MM
-
Weight (KG):
-
100 KG
-
Mode of Operation:
-
CO2 Laser
-
Configuration:
-
CO2 Laser tube
-
Product name:
-
C02 Laser Engraving Cutting Machine
-
Laser power:
-
80W/100W/130W/150W
-
Function:
-
Cutting Engraving Non-metal Materials
-
Cutting material:
-
Acrylic Wood Mdf Plywood Plactical
-
Laser tube:
-
RECI EFR
-
After-sales Service Provided:
-
Online Support
-
Software:
-
LaserCAD support CAD output
-
Working area:
-
1300*2500MM
-
Cutting depth:
-
0-18mm
-
Location:
-
0.01mm
Product Description
Function:
Advertising decoration industry
1. Acrylic crystal letter engraving and cutting
2. Trophy/plaque laser engraving
3. Two-color plate laser engraving/cutting
4. Engraving/cutting of non-metallic sheets
Printing and packaging industry
1. Rubber sheet laser engraving
2. Printing stick laser engraving
3. Laser engraving and cutting of paper products
Craft gift industry
1. Bamboo tube/wooden board book laser engraving
2. Mahogany carving
3. Box craft engraving
4. Ceramic carving
Leather garment industry
1. Leather punching and surface pattern engraving 2. Garment fabric pattern cutting
model making industry
1. Acrylic model sheet cutting
2. Wood formwork board cutting
Shadow sculpture industry
Carve clear images on bamboo/acrylic and other materials
Laser head
The high-precision laser head has a long service life and is equipped with a red light indicator for easy positioning.
Control Panel
3.5-inch digital display color screen offline, high-speed data transmission, can be previewed in the software coating, support
stratified color separation output power off continued engraving + cutting synchronization, can plug U disk work and link computer
work.
stratified color separation output power off continued engraving + cutting synchronization, can plug U disk work and link computer
work.
Laser tube
High-quality laser tube, high quality, high output power, small spot, strong penetration, high power, more stable output, good heat resistance, and high temperature resistance.
Motor
Special motor for equipment, long life, high torque, 57 stepper motor, low noise, corrosion resistance, stable torque, long life, superior performance, manufacturer's warranty
Specification
|
MODEL
|
LD1325
|
LD1390
|
LD 1610
|
LD1325
|
|||
|
Laser power
|
60W/80W/100W/130W/150W/200W/300W/500W
|
|
|
|
|||
|
Working size
|
1300*2500MM
|
900*1300MM
|
1000*1600mm
|
1300x 2500mm
|
|||
|
Working speed
|
0-1000mm/s (Adjustable)
|
|
|
|
|||
|
Cutting depth
|
0-18mm (According to material)
|
|
|
|
|||
|
Location precision
|
0.01mm
|
|
|
|
|||
|
Power supply
|
AC220V/110V 50/60HZ
|
|
|
|
|||
|
Min Carving Character
|
Words2*2mm/Number1*1mm
|
|
|
|
|||
|
Work environment
|
5-40°C 5-95%(RH)
|
|
|
|
|||
|
Cooling way
|
Water cooling
|
|
|
|
|||
|
Machine size
|
3200*2010*1190mm
|
|
|
|
|||
|
N.W.
|
560
|
|
|
|
|||
|
more
|
Can be customized, such as working size, motor,laser power,etc
|
|
|
|
|||
Cutting Sample
Machinable materials:
Acrylic, plastic products, wood boards, MDF, wood products, plywood, leather, cloth, non-woven fabrics, non-woven fabrics, felt, sandpaper, paper, cardboard, bamboo products, PVC, KT board, two-color board, rubber, non-woven Non-metal items such as dry glue stickers can be used for engraving such as engraving, cutting and hollowing out.
Bone products, crystal, glass, quartz, marble, stone, ceramics and other non-metallic and painted metal surface carvings, metal laminated plates, aluminum oxide, can be carved without depth.
