Quick Details
-
Dimension (L*W*H):
-
547*471*248 mm
-
Weight:
-
89KGS
-
Protection Class:
-
IP20
-
Product name:
-
KMD Power Storge Battery
-
Power Source:
-
Solar Panel
-
Cycle life:
-
6000 Times
-
Warranty:
-
5 Years
-
Hybrid Inverter Compatible:
-
MUST/GOODWE/PYlONTECH/GROWATT/SRNE/Sofar solar/Deye/Sacolai etc.
-
Dimension:
-
547*471*248 mm
-
Communication:
-
RS485/RS232/CAN (Optional)
-
Parallel support:
-
Parallel terminal are supported
-
Application:
-
House,Office,Wind complementary system
-
Certification:
-
CE/UN38.8/ISO9001/ROHS etc
Quick Details
-
Model Number:
-
KMD--PL48200
-
Brand Name:
-
Kamada Power
-
Place of Origin:
-
Guangdong, China
-
Dimension (L*W*H):
-
547*471*248 mm
-
Weight:
-
89KGS
-
Protection Class:
-
IP20
-
Product name:
-
KMD Power Storge Battery
-
Power Source:
-
Solar Panel
-
Cycle life:
-
6000 Times
-
Warranty:
-
5 Years
-
Hybrid Inverter Compatible:
-
MUST/GOODWE/PYlONTECH/GROWATT/SRNE/Sofar solar/Deye/Sacolai etc.
-
Dimension:
-
547*471*248 mm
-
Communication:
-
RS485/RS232/CAN (Optional)
-
Parallel support:
-
Parallel terminal are supported
-
Application:
-
House,Office,Wind complementary system
-
Certification:
-
CE/UN38.8/ISO9001/ROHS etc
Specification
|
battery materials
|
lithium iron phosphate
|
|
battery specifications
|
KMD-PL48200
|
|
series parallel mode(S series, P parallel)
|
13S1P
|
|
nominal voltage
|
48V / 51.2V
|
|
nominal capacity
|
200Ah
|
|
size(mm)
|
547*471*248 mm
|
|
weight
|
89KGS
|
|
color
|
optional
|
|
parallel support
|
Max 15 Batteries In Parallel
|
|
output port mode
|
terminals
|
|
charging way
|
CC/CP/VP
|
|
charge current
|
0.2C(standard)
|
|
max.charging Current
|
Max 90A @25℃
|
|
max.discharge Current
|
Max 120A @25℃
|
|
according to
|
LCD
|
|
communication interface
|
RS485/RS232/CAN (Optional)
|
|
operating temperature range
|
0℃ ~+ 50℃ (Charging) / -20℃ ~+ 60℃ (Discharging)
|
|
storage temperature range
|
-30℃ ~+ 60℃
|
|
cycle life
|
Around 6000 Times
|
|
warranty
|
5 Years Product Warranty
|
|
scope of application
|
hospital, bank data center, wall-mounted home, enterprise energy storage backup power supply, wind complementary system,office , military, base station and other uninterrupted energy storage power supply.
|
Special Advantage
Product Details
Q1. Are you a factory or trading company ?
A:Yes, we are 15 Years+ Professional energy storage battery factory, supplying OEM/ODM
service.
Q2.What products do you offer?
Our main products is Lithium lon Batteries. Now we can offer Home Energy Storage, Telecom Battery, Battery Pack,Lithium Battery 24V 48V etc.
Q3. How can l get a sample to check your quality?
If you need sample to test, please pay for the freight and sample cost. And the sample cost will be returned back to you after you place an bulk order more than our MOQ.
Q4. Can I have the products with my own logo?
Q4. Can I have the products with my own logo?
Yes. We can offer both OEMand ODM service with prototype design and small MOQ.
Q5.How long can I expect to get the sample?
Q5.How long can I expect to get the sample?
The samples will be ready for delivery in 3~5days after we receive the payment.
Q6.Can you give me a discount?
Yes, based on wholesale service, we have better discount for bigger quantities.
Q7. What are the advantages that distinguish from others?
1.Official cooperative supplier of China StateGrid Official
2.With professional product development team
3.Rich experience in wireless computer room
4.With superior energy storage solution.
Q8. How to do if i can't reach your minimum order quantity?
Do not worry about that. If you can't reach MOQ for each item, we suggest you refer to our goods in stock and group sourcing items. We also can send you the latest list of the prompt goods for your reference.
Q9. How to make order?
Send us your purchase order by email , or ask us to send you a proforma invoice for your order, or start an order on
Alibaba Trade Assurance.
Alibaba Trade Assurance.
