Quick Details
-
Controller Type:
-
MPPT
-
Mounting Type:
-
Ground Mounting
-
Certificate:
-
CE RoHs
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Solarthon
-
Model Number:
-
STE
-
Load Power (W):
-
3600W, 6200W
-
Output Voltage (V):
-
6
-
Output Frequency:
-
50-60Hz
-
Product name:
-
Grid Solar Inverter
-
Power:
-
3.6kw 6.2kw
-
Nominal Operating Voltage:
-
360VDC
-
Maximum PV Array Open Circuit Voltage:
-
500VDC
-
Full Load MPPT Operating Voltage:
-
240~450VDC
-
Number Of MPPT/Maximum Input Current:
-
1/23A
-
Main Load Cut Off/Return Voltage:
-
22V/26VDC
-
Nominal Input Voltage:
-
120VAC, 50/60Hz
-
Battery Voltage:
-
24VDC
-
Communication Port:
-
RS232/GPRS/WIFI/LITHIUM BATTERY
Quick Details
-
Application:
-
Home
-
Solar Panel Type:
-
Monocrystalline Silicon, Polycrystalline Silicon
-
Battery Type:
-
Lithium Ion
-
Controller Type:
-
MPPT
-
Mounting Type:
-
Ground Mounting
-
Certificate:
-
CE RoHs
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Solarthon
-
Model Number:
-
STE
-
Load Power (W):
-
3600W, 6200W
-
Output Voltage (V):
-
6
-
Output Frequency:
-
50-60Hz
-
Product name:
-
Grid Solar Inverter
-
Power:
-
3.6kw 6.2kw
-
Nominal Operating Voltage:
-
360VDC
-
Maximum PV Array Open Circuit Voltage:
-
500VDC
-
Full Load MPPT Operating Voltage:
-
240~450VDC
-
Number Of MPPT/Maximum Input Current:
-
1/23A
-
Main Load Cut Off/Return Voltage:
-
22V/26VDC
-
Nominal Input Voltage:
-
120VAC, 50/60Hz
-
Battery Voltage:
-
24VDC
-
Communication Port:
-
RS232/GPRS/WIFI/LITHIUM BATTERY
Recommend Products
Product Paramenters
|
Item No.
|
STE36224
|
STE62248
|
|
Rated Output Power
|
3600W
|
6200W
|
|
Nominal PV Operating Voltage
|
360VDC
|
360VDC
|
|
Maximum PV Array Open Circuit Voltage
|
500VDC
|
500VDC
|
|
MPPT Operating Voltage
|
60~450VDC
|
60~450VDC
|
|
Maximum PV Charging Current
|
120A
|
120A
|
|
Nominal Output Voltage
|
220/230/240VAC 50/60Hz
|
220/230/240VAC 50/60Hz
|
|
Nominal Output Current
|
15.7A
|
27A
|
|
Power Factor Range
|
＞0.99
|
＞0.99
|
|
Maximum Conversion Efficiency(DC/AC)
|
98%
|
98%
|
|
Nominal Input Operating Voltage
|
230VAC 50/60Hz
|
230VAC 50/60Hz
|
|
Maximum Input Current
|
40A
|
50A
|
|
Surge Power
|
7200W
|
10000W
|
|
Maximum AC Charging Current
|
100A
|
100A
|
|
Battery Voltage
|
24VDC
|
48VDC
|
|
Maximum Battery Current
|
150A
|
125A
|
|
Communication Port
|
RS232/GPRS/WIFI/LITHIUM BATTERY
|
RS232/GPRS/WIFI/LITHIUM BATTERY
|
|
Product Size
|
310x420x110mm
|
310x420x110mm
|
|
Package Size
|
420x500x180mm
|
420x500x180mm
|
|
Net Weight
|
8.0kg
|
8.7kg
|
|
Warranty
|
3 years
|
3 years
|
