* No damage to
substrates
* Perfect surface
cleanliness
* No carried over
blasting material or grinding dust
substrates
* Perfect surface
cleanliness
* No carried over
blasting material or grinding dust
- Product Details
- {{item.text}}
Quick Details
-
Marketing Type:
-
New Product 2021
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
dowell
-
Dimension(L*W*H):
-
780mm*460mm*700mm
-
Year:
-
2021
-
Weight (KG):
-
50 KG
-
After-sales Service Provided:
-
Video technical support, Online support,
-
Laser source:
-
MAX Laser
-
Laser Wavelength:
-
1064nm
-
Clean way:
-
Non-touch Laser Cleaning
-
speed:
-
1000-8000mm/s
-
Scan width:
-
10-60mm
-
Product name:
-
Fiber Laser Cleaning Machine
-
Cooling method:
-
Water Cooling
-
laser head:
-
MAx
-
Cleaning materials:
-
Metal Rust Oil Dust Coating
-
Clean Width:
-
0-20mm
Quick Details
-
Power:
-
200W, 100W, 500W, 50W, 3000W, 1500W, 1000W
-
Laser Type:
-
Fiber Laser
-
Laser Source Brand:
-
MAX
-
Marketing Type:
-
New Product 2021
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
dowell
-
Dimension(L*W*H):
-
780mm*460mm*700mm
-
Year:
-
2021
-
Weight (KG):
-
50 KG
-
After-sales Service Provided:
-
Video technical support, Online support,
-
Laser source:
-
MAX Laser
-
Laser Wavelength:
-
1064nm
-
Clean way:
-
Non-touch Laser Cleaning
-
speed:
-
1000-8000mm/s
-
Scan width:
-
10-60mm
-
Product name:
-
Fiber Laser Cleaning Machine
-
Cooling method:
-
Water Cooling
-
laser head:
-
MAx
-
Cleaning materials:
-
Metal Rust Oil Dust Coating
-
Clean Width:
-
0-20mm
If
you want to know the effective of the laser cleaner , you can
click here
to ask the
customer service
for a free cleaning sample
or if you want to know if you can clean the materials you need, you can click here to ask the customer service
or if you want to know if you can clean the materials you need, you can click here to ask the customer service
Laser cleaning application
Tire mold
Best solution
100-2000 W systems
100-2000 W systems
glass mold
Best solution
100-2000 W machines are often needed in the glass industry, just because speed is the determing factor.
100-2000 W machines are often needed in the glass industry, just because speed is the determing factor.
Rubber mold
Best solution
100-2000 W systems
100-2000 W systems
engine
Best solution
Laser Cleaning MotorCycle Engine 100w-500W Auto Restoration of aluminium ,
Laser Cleaning MotorCycle Engine 100w-500W Auto Restoration of aluminium ,
Oil cleaning
Best solution
Laser Cleaning MotorCycle Engine 100w-2000W Auto Restoration of aluminium
Laser Cleaning MotorCycle Engine 100w-2000W Auto Restoration of aluminium
repair
Best solutions
20-200 W machines (inline or portable) for small, fragile restorations
500-2000 W machines (inline or trolley) for large restorations
20-200 W machines (inline or portable) for small, fragile restorations
500-2000 W machines (inline or trolley) for large restorations
Paint coating
Best solutions
20-200 W systems are excellent for in-line coating removal
If you want to manually remove coating on a larger surface and at higher speeds, a 500-2000 W machine is the way to go!
20-200 W systems are excellent for in-line coating removal
If you want to manually remove coating on a larger surface and at higher speeds, a 500-2000 W machine is the way to go!
Rust removal
Best Solutions
20-100 W machines (inline or portable) for small surfaces
500-2000 W machines (inline or trolley) for larger surfaces
20-100 W machines (inline or portable) for small surfaces
500-2000 W machines (inline or trolley) for larger surfaces
Steel weld
Best solutions:
Low Power and Mid Power systems.
Low Power and Mid Power systems.
Stainless steel is as suitable for weld preparation and cleaning as aluminium. You can reach
cleaning speeds varying from 1m to 1.5m per minute.
Products Description
Machine Features：
The traditional industrial cleaning mode mostly uses chemical agents and mechanical methods for cleaning. With the increasing awareness of environmental protection and safety, the types of chemicals that
can
be used in industrial production cleaning will become less and less.
Cleaner and non-destructive cleaning method is a problem we have to consider: dowell laser cleaning machine has the characteristics of no grinding, no contact, no thermal effect and suitable for various materials, which is considered to be the most reliable and effective solution. At the same time, laser cleaning can solve the problems that can not be solved by traditional cleaning methods.
Quality that convinces
The DOWELL LASER removes rust, oils, lacquers and other coatings without damaging the surface of your components.
Machine Details
1. What is the speed of the laser cleaning machine?
Different laser types determine the cleaning speed of the cleaning machine, and the cleaning speed is within the range of
0.5m2/h-15m2/h
Different laser types determine the cleaning speed of the cleaning machine, and the cleaning speed is within the range of
0.5m2/h-15m2/h
2.Is it possible to clean the mold?
Yes，You can give us your mailbox, and we will send the video of the laser cleaning machine cleaning the mold to your mailbox
3.The effect of paint and rust removal
Very good, you can refer to our video below
4.Is there any damage to the cleaning material?
Depends on what type you need, the pulse type has a finer cleaning effect, and the continuous type has a faster cleaning speed,
Relative damage of material, pulse type is less than continuous type.
5.Language interface
Support Chinese and English, and language settings can also be set according to customer needs
6.What kind of objects can be cleaned?
oxide layer/rusty scale/Paint, coating/Dirt, carbon layer/Others
Yes，You can give us your mailbox, and we will send the video of the laser cleaning machine cleaning the mold to your mailbox
3.The effect of paint and rust removal
Very good, you can refer to our video below
4.Is there any damage to the cleaning material?
Depends on what type you need, the pulse type has a finer cleaning effect, and the continuous type has a faster cleaning speed,
Relative damage of material, pulse type is less than continuous type.
5.Language interface
Support Chinese and English, and language settings can also be set according to customer needs
6.What kind of objects can be cleaned?
oxide layer/rusty scale/Paint, coating/Dirt, carbon layer/Others
Product Paramenters
|
Device model
|
DW-100W
|
DW-200W
|
DW-500W
|
DW-1000
|
DW-2000
|
DW-3000
|
|
Power
|
100W
|
200W
|
500W
|
1000W
|
2000W
|
3000W
|
|
Trans-Portable
|
Hand-held Head
|
Hand-held Head
|
Hand-held, Optional Automation
|
Hand-held, Optional Automation
|
Hand-held, Optional Automation
|
Hand-held, Optional Automation
|
|
cooling method
|
Air-cooled
|
Air-cooled
|
* Water-Cooled Integration
|
* Water-Cooled Integration
|
* Water-Cooled Integration
|
* Water-Cooled Integration
|
|
Length of optical fibre
|
5-10m
|
5-10m
|
10-20m
|
10-20m
|
10-20m
|
10-20m
|
|
Weight of cleaning head
|
1.5kg
|
2.0kg
|
2.5kg
|
2.5kg
|
2.5kg
|
2.5kg
|
|
Wavelength
|
1064 nm
|
1064 nm
|
1064 nm
|
1064 nm
|
1064 nm
|
1064 nm
|
|
Power Input
|
220V-380V
|
220V-380V
|
220V-380V
|
220V-380V
|
220V-380V
|
220V-380V
|
Product Configuration
EXHIBITION PHOTOS
Certifications
FAQ
✦What materials can be cleaned by fiber laser?
Various metals, such as stainless steel, carbon steel, low carbon steel, galvanized steel, aluminum, copper, stone, oil, paint, coating, welding rod, wall, wood, etc.
✦How to operate the machine?
We will provide you with English manuals and videos along with the machine. If you still need our help, please contact us.
✦How can I get samples to check your quality?
If you want to mark samples to check the quality, we can help you do that. First of all, you need to provide us with a logo or design, and we can provide free logo samples.
✦Can the machine be customized according to my requirements?
Of course, we have a strong technical team and rich experience. Our goal is to make you satisfied.
✦Can you arrange the delivery for me?
We can arrange sea or air freight for our customers. Trading terms FOB, CIF, EXW are available.
