Popular Mini round hay baler for sale

FOB Reference Price: Get Latest Price

≥1 Sets

US $4000

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Dimension(L*W*H):: 1150x1300x1200mm

Weight:: 390 KG

After-sales Service Provided:: Engineers available to service machinery overseas

Spare Parts:: Provided

Bale Size:: 50x70 CM

Match Power:: 25-50 HP

Color:: As your request

Certification:: ISO

Quick Details

Place of Origin:: Henan, China

Brand Name:: ORANGEMECH

Application:: Bale hay rice wheat straw

Dimension(L*W*H):: 1150x1300x1200mm

Weight:: 390 KG

After-sales Service Provided:: Engineers available to service machinery overseas

Spare Parts:: Provided

Bale Size:: 50x70 CM

Match Power:: 25-50 HP

Color:: As your request

Certification:: ISO

Popular Mini round hay baler for sale!

Product Description

Specifications:

1. Hay ,grass, straw Bundling Machine

2. Round hay bale wrapper, match with tractor
3. ISO certification

Introduction:

mini round hay baler machine a pplications

This straw collecting and baling machine is widely used in collecting and bundling dry and green grass,

straw, wheat stalk, corn stalk. It is convenient for transportation, reserve and deep processing, and it

is match with envelop machine to achieve the enveloping of ensile.

mini round hay baler machine w orking theory

This mini hay baler machine is suitable for the tractor with more than 18-45 horse power. This machine

is composed of the picking system, rolling pressing system, threading system and bale locating system

which bales the soft culm and grasses (rice straw, wheat straw, grass etc) fully automatic. The finished

density of the bale is about 90kg/m³.

mini round hay baler machine w orking procedure

The Power conveyor driven shaft releases the power to bundling machine's power-input shaft through

universal drive shaft, chain sprocket, and rotary platen system and picking system. Hydraulic power

driving joint controls the cylinder piston to enable the bale putting. The baling machine is already adjusted

into the suitable height. When the machine is going along with the tractor, the hay is picked into rotary

platen chamber and rotating bigger and bigger, then get into very tight round bale. When the density of the

bale is OK, the alarming system will start to sound, driver should stop forwarding, push the threading clutch.

When find the speed of threading is faster, looses clutch, keeps the power conveyor driven shaft working to

start thread. Driver should pull the hydraulic controlling stick to change the direction of the hydraulic valve,

and then the cylinder will work and throw the bale out. After throwing the bale out, correct the hydraulic

valve, open rear rack to forwarding again for the second cycle.

mini round hay baler machine parameters

Pickup Width ( mm )	800mm
*Size of bale HW** ( cm )	Dia610*700mm
Length of bale ( cm )	700mm
Density of bale ( kg/m³ )	Adjustable
Efficiency ( bales/hour )	2-5km/h
Weight ( kg )	440kg
Power ( HP )	25~50HP
Bale release	Alert, discontinuous bale and release, hand hydraulic release

Packaging & Delivery:

Packaging Detail:	Export Standard
Delivery Detail:	15 working days

Picture:

FAQ

Q1: What are the payment terms?

A: We usually accept payment by T/T, L/C, Western Union or Escrow.

Q2 : Can any of the products be custom imprinted?

A: If you need to print your company logo on the products and that is available to be custom. Or if you have your own designed idea and that will be our honor to customize for you.

Q3: This is my first time to import, how can I trust your company and ensure to get the goods if I order from you?

A: We are alibaba legitimate certification company (VIP), and we support payment terms like L/C, Escrow, to ensure your safety.

Q4: How to ensure that I received the machine undamaged?

A: At first , our package is standard for shipping, before packing, we will confirm product undamaged, otherwise, please contact within 2days. Because we've bought insurance for you, we or shipping company will be responsible!

Q6 : Where will the orders be shipped from?

A: It will ship from the main ports China. And We will find the shipping company which will offer the best and most economical freight for our customers.
