JIULIN
1104
TS tractor is designed for works on middle-scale farms and auxiliary works on large farmland.
• It equips with china famous supercharged diesel engine, produces more power and less fuel consumption, making the work more energy-efficient.
• With independent control,dual -action LUK clutch from Germany, the tractor has a reliable quality, high efficiency of power transmission and comfortable to control.
• Standard with enhanced chassis and 16F+8R synchronizer and shuttle gift gearbox enables you easily shift through gears, features small shocks between gears and long lifetime , rational speeds meet different works.
• With dynamic and fashionable appearance , flat floor, side console and suspension pedal , new design patent luxury cab, with A/C or heater , provide you safe, quite and comfortable driving conditions.
- Product Details
- {{item.text}}
Quick Details
-
Engine Brand:
-
Dongfanghong, Yuchai, Weichai, Laidong
-
Weight:
-
5650 KG
-
Color:
-
Customer Requirements
-
Transmission::
-
Two shafts 16F+8R
-
Clutch:
-
Dry-friction, single disc and single-stage
-
Engine:
-
Six-cylinder Weichai engine
-
PTO Speed:
-
760rpm/850rpm
-
Steering Type:
-
Full Hydraulic power steering
-
Options:
-
Air condition cab
-
Tractor price:
-
CONTACT Wendy
-
More implements:
-
CONTACT Wendy
Quick Details
-
Rated Power (HP):
-
110HP 140 hp
-
Brand Name:
-
JIULIN
-
Place of Origin:
-
Shandong, China
-
Engine Brand:
-
Dongfanghong, Yuchai, Weichai, Laidong
-
Weight:
-
5650 KG
-
Color:
-
Customer Requirements
-
Transmission::
-
Two shafts 16F+8R
-
Clutch:
-
Dry-friction, single disc and single-stage
-
Engine:
-
Six-cylinder Weichai engine
-
PTO Speed:
-
760rpm/850rpm
-
Steering Type:
-
Full Hydraulic power steering
-
Options:
-
Air condition cab
-
Tractor price:
-
CONTACT Wendy
-
More implements:
-
CONTACT Wendy
HOT SALE technical features:
After sales service polices .
1.
JIULIN tractor is offered 14 months of warranty period of the tractor, which start from the 3 month as the shipment date.
2. JIULIN will offer free service parts in warranty period, and there is no charge of related work hours and indirect expenses.
3. Service training
There are over 80 dealers and service channels covering all the market area. We take " satisfy the customers" as our target, provide "3 full" (Full course, Full time, Full hearted) service
.
|
Main parameters
|
|
|
|
1104 FARM TRACTOR
|
|
|
|
Drive type
|
4×4 four-wheel drive
|
|
|
Engine
|
|
|
|
Engine Brand
|
YTO
|
|
|
Engine Type
|
YTO LR4M3Z
4cylinder,water-cooling, 4 stroke, in-line, direct injection |
|
|
Rating power of engine KW/RPM
|
80.2 /2300
|
|
|
Fuel consumption @ nominal power (g/kw.h)
|
contact Wendy
|
|
|
Air Intake Type
|
supercharged diesel engine
|
|
|
Displacement L
|
4.09
|
|
|
Air filter type/size
|
oil bath type
|
|
|
Torque reserve
|
17.5:1
|
|
|
Transmission system
|
|
|
|
Clutch type/size
|
dry type, dual-acting clutch
|
|
|
No. of gears (F+R)
|
16F+8R
|
|
|
Shift method
|
ENGAGEMENT collar shift
|
|
|
Max. speed
|
contact Wendy
|
|
|
Gear position
|
side position
|
|
|
Hydraulic system
|
|
|
|
Hydraulic output flow rate (L / MIN)
|
CB-F325L
|
|
|
Hydraulic output valve
|
Three groups
|
|
|
Hydraulic filter types and capacity
|
CONTACT Wendy
|
|
|
Working device
|
|
|
|
Three-point-linkage
|
II category,three-point rear linkage
|
|
|
PTO Speed & model
|
540/1000 760/850
¢35,6 teeth |
|
|
Lifting Capacity (kn)
|
>22
|
|
|
Tillage depth adjustment
|
CONTACT Wendy
|
|
|
Parameter
|
|
|
|
The whole machine size (dimensions) mm
|
4200×2050 ×2930
|
|
|
Min. operation mass
|
4200/5200
|
|
|
Wheel base (mm)
|
2480
|
|
|
Mini turning Radius (m)
|
CONTACT Wendy
|
|
|
Rated traction force(N)
|
>22
|
|
|
Minimum ground clearance (mm)
|
405
|
|
|
front wheel tread / rear wheel tread
|
1610,1710,1810,1950/1608~1996
|
|
|
tyre size
|
12.4-24/16.9-34
14.9-26/18.4-38 14.9-24/18.4-34 |
|
|
Braking and steering
|
|
|
|
Braking system
|
heavy single-disc, mechanical brake
|
|
|
Steering type
|
hydraulic steering
|
|
|
Steering Angle (4 x4)
|
Front axle Max.Steering angle 45°
|
|
|
(options: all these types can Optional for swing drawbar, front/rear ballast)
|
|
|
Work Shop.
Product Highlights
1.Factory with 20 years experience ensure the products quality.
2.14 months warranty period.
3.For easy-damage parts, we will send you together with the tractor for free.
4.During warranty period, free spare parts for quality-problem spare parts replacement.
5.Multi-selection of configuration.
1.Factory with 20 years experience ensure the products quality.
2.14 months warranty period.
3.For easy-damage parts, we will send you together with the tractor for free.
4.During warranty period, free spare parts for quality-problem spare parts replacement.
5.Multi-selection of configuration.
Delivery
Company profile
JIULIN INDUSTRY is one of the largest professional mechanical industry manufacturer in China, which located in Shandong Province China, the leading products include Tractor & Implements, Excavator and Spare Parts, Micro Cultivator & Forestry machinery, Automobile battery & Vehicle Spare Parts and other products.
JIULIN INDUSTRY has 23 years manufacturing experience, 10 years export experience, covering an area of 100,000 square meters, has 770 stuffs including more than 100 senior engineers and engineering technicians, with advanced parts and equipment of leading Assembly line in china. It's annual production capacity is 50,000 sets tractors and excavators, 20,000 units farm implements and 12,000MT earth-moving spare parts. Perennial products are exported to more than 100 countries in the world.
JIULIN INDUSTRY has a perfect after-sales service system. We have sales agents in many countries, there are over 460 dealers and service channels covering all the market area. We take "satisfy the customers" as our target, provide "3 Full" (Full course, Full time, Full hearted) service. Our products are widely recognized and trusted by users, we welcome new and old customers all over the world to contact us for future business relationships and mutual success.
JIULIN INDUSTRY has 23 years manufacturing experience, 10 years export experience, covering an area of 100,000 square meters, has 770 stuffs including more than 100 senior engineers and engineering technicians, with advanced parts and equipment of leading Assembly line in china. It's annual production capacity is 50,000 sets tractors and excavators, 20,000 units farm implements and 12,000MT earth-moving spare parts. Perennial products are exported to more than 100 countries in the world.
JIULIN INDUSTRY has a perfect after-sales service system. We have sales agents in many countries, there are over 460 dealers and service channels covering all the market area. We take "satisfy the customers" as our target, provide "3 Full" (Full course, Full time, Full hearted) service. Our products are widely recognized and trusted by users, we welcome new and old customers all over the world to contact us for future business relationships and mutual success.
