Quick Details
-
Engine Brand:
-
OPTIONAL
-
Place of Origin:
-
Anhui, China
-
Brand Name:
-
H&L
-
Dimension(L*W*H):
-
5050*2300*3170 mm
-
Drum diameter:
-
1300 mm
-
Exciting Force:
-
169/108 KN
-
Marketing Type:
-
New Product 2022
-
Product name:
-
Liugong Double-Drum Road Roller
-
Model:
-
6214e
-
Keywords:
-
road machinery cheap
-
Delivery time:
-
5-7day
-
Excavator:
-
Chinese brand new road roller
-
Feature:
-
high operating efficiency
-
Brand:
-
HL
-
Origin:
-
China Original
Quick Details
-
Type:
-
Impact Roller
-
Power:
-
119 kw
-
Weight:
-
13 TON
-
Engine Brand:
-
OPTIONAL
-
Place of Origin:
-
Anhui, China
-
Brand Name:
-
H&L
-
Dimension(L*W*H):
-
5050*2300*3170 mm
-
Drum diameter:
-
1300 mm
-
Exciting Force:
-
169/108 KN
-
Marketing Type:
-
New Product 2022
-
Product name:
-
Liugong Double-Drum Road Roller
-
Model:
-
6214e
-
Keywords:
-
road machinery cheap
-
Delivery time:
-
5-7day
-
Excavator:
-
Chinese brand new road roller
-
Feature:
-
high operating efficiency
-
Brand:
-
HL
-
Origin:
-
China Original
Products Description
13Ton Double Drum Road Roller 6213E With 119kW/2200rpm High Efficiency
Product-Features:
* Flexible and non-impact technology on our vibratory rollers extends the vibratory bearing's working life to beyond 10,000 hours
increasing productivity and reducing part wear.
* LiuGong's innovative auto throttle reduces fuel consumption by automatically switching the engine to idling mode during periods
of inactivity.
* Soft starting and braking technology significantly improves the operator's experience helping to reduce pavement damage and
ensure a high quality finish to every job.
Specifications 6213E:
Operating Mass
13000 kg
Mass On Front Drum
6500 kg
Mass On Rear Axle
6500 kg
Front Drum Static Linear Load
305 N/cm
Rear Drum Static Linear Load
305 N/cm
Model
Cummins QSB4.5
Emission Regulation
Stage III
Rated Power
119 kW (162 hp) @ 2200 rpm
Vibration Frequency Low
45/50 Hz
Nominal Amplitude Low
0.75/0.4 mm
Centrifugal Force Low
150/90 kN
Vibration Frequency High
50/67 Hz
Nominal Amplitude High
0.8/0.3 mm
Centrifugal Force High
169/108 kN
Drum Diameter
1300 mm
Drum Width
2130 mm
1st Maximum Speed, fwd
0-6 km/h
2nd Maximum Speed, fwd
0-8 km/h
3rd Maximum Speed, fwd
0-12 km/h
Theoretical Gradeability
40%
Min. Ground Clearance
320 mm
Wheelbase
3585 mm
Min. Outside Turning Radius
6770 mm
Overall Length
5050 mm
Overall Width
2300 mm
Overall Height
3170 mm
