Quick Details
-
Ice storage capacity:
-
3000kg
-
Applicable Industries:
-
Ice maker
-
Place of Origin:
-
Zhejiang
-
Brand Name:
-
Enfriar
-
Dimension(L*W*H):
-
1834*1550*2250mm
-
Weight:
-
1800 KG
-
Compressor brand:
-
Other
-
Product name:
-
Ice Tube Machine
-
Model:
-
KT-3T with container
-
Refrigerant:
-
R404a
-
L*W*H(mm):
-
1834*1550*2250 mm
-
Daily capacity(KG):
-
3000/24hrs
-
tandard Ambient temperature:
-
30℃
-
Inlet water temperature:
-
20℃
-
Ice tube diameter:
-
Tube Diameter: 22, 28, 35 (tube length can be customized)
-
After-sales Service Provided:
-
Online Technical Support
Quick Details
-
Ice Shape:
-
tube ice
-
Voltage:
-
3P/220V/60hz, 220V/3Ph/60Hz
-
Power:
-
18kW
-
Ice storage capacity:
-
3000kg
-
Applicable Industries:
-
Ice maker
-
Place of Origin:
-
Zhejiang
-
Brand Name:
-
Enfriar
-
Dimension(L*W*H):
-
1834*1550*2250mm
-
Weight:
-
1800 KG
-
Compressor brand:
-
Other
-
Product name:
-
Ice Tube Machine
-
Model:
-
KT-3T with container
-
Refrigerant:
-
R404a
-
L*W*H(mm):
-
1834*1550*2250 mm
-
Daily capacity(KG):
-
3000/24hrs
-
tandard Ambient temperature:
-
30℃
-
Inlet water temperature:
-
20℃
-
Ice tube diameter:
-
Tube Diameter: 22, 28, 35 (tube length can be customized)
-
After-sales Service Provided:
-
Online Technical Support
Specifications
|
NO
|
Name
|
Data
|
Remarks
|
|||
|
1. Designed Working condition
|
|
|
|
|||
|
1.1
|
Standard Ambient temperature
|
30 ℃
|
|
|||
|
1.2
|
Inlet water temperature
|
20 ℃
|
Fresh water
|
|||
|
1.3
|
Power Supply
|
220V, 3Ph, 60Hz
|
|
|||
|
2. General Performance Parameters
|
|
|
|
|||
|
2.1
|
Ice marking capacity(daily)
|
3 ton/day
|
|
|||
|
2.2
|
Ice tube diameter
|
Tube Diameter: ф22, ф28, ф35
(tube length can be customized) |
|
|||
|
2.2
|
Total installed power
|
18kW
|
|
|||
|
2.4
|
Evaporating temperature
|
-15℃
|
|
|||
|
2.5
|
Condensing temperature
|
+40 ℃
|
|
|||
|
2.6
|
Refrigerant
|
R404A/R22
|
|
|||
|
|
Compressor input power
|
13 kw
|
|
|||
|
2.7
|
Ice water pump input power
|
0.37 kW
|
|
|||
|
2.8
|
Ice conveyor input power
|
0.75 kW
|
|
|||
|
|
Cooling tower fan input power
|
0.76kw
|
|
|||
|
2.10
|
Out size
|
1834×1550×2250 mm
|
|
|||
|
2.11
|
Total weight
|
1800kg
|
|
|||
|
2.12
|
Water supply pipe size
|
1/2"
|
|
|||
|
2.13
|
Condensation method
|
Air cooling
|
|
|||
|
|
Water pressure requirement
|
0.1Mpa－0.5Mpa
|
|
|||
PRODUCT DESCRIPION
Product Detalis
3T Spare parts
|
Item/ Description
|
Brand
|
Qty
|
|
compressor
|
Refcomp
|
1
|
|
Evaporator
|
Sinocold
|
1
|
|
water tank
|
Sinocold
|
1
|
|
Expansion valve
|
Danfoss
|
9
|
|
Ice bucket pump
|
hongjian
|
1
|
|
diaphragm pump
|
Aiboshi
|
1
|
|
Bearing
|
Ntn(japan)
|
5
|
|
Electrical Box
|
Sinocold
|
1
|
|
circuit breaker
|
chit
|
1
|
|
Contactor
|
chit
|
3
|
|
Thermal relay
|
chit
|
3
|
|
Relay
|
Yiwei
|
1
|
