Work efficiency is very high. Filter clean, environmental protection, no pollution. Smooth and uniform paint, no impurities. Best quality, perfect choice.
- Product Details
- {{item.text}}
Quick Details
-
Voltage:
-
220V/380V
-
Disc Dia.:
-
Non
-
No Load Speed:
-
0.3m/s
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Jinding
-
Model Number:
-
JD-A1
-
Warranty:
-
24 months
-
Certification:
-
ce
-
Product name:
-
Spray Booth
-
Usage:
-
paint spray and bake
-
Color:
-
Red White Orange Blue
-
Heating System:
-
Diesel Burner/gas burner/electric
-
Lighting System:
-
LED
-
Environmental certificate:
-
CE
-
Fans kind:
-
Centrifugal Fans CE
-
Filters:
-
4-stage Filter System
-
Warranty Time:
-
1 Year
Quick Details
-
Power:
-
33KW
-
External Size:
-
7000*5300*3200mm
-
Internal Size:
-
6900*3900*2400mm(L*W*H)
-
Voltage:
-
220V/380V
-
Disc Dia.:
-
Non
-
No Load Speed:
-
0.3m/s
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Jinding
-
Model Number:
-
JD-A1
-
Warranty:
-
24 months
-
Certification:
-
ce
-
Product name:
-
Spray Booth
-
Usage:
-
paint spray and bake
-
Color:
-
Red White Orange Blue
-
Heating System:
-
Diesel Burner/gas burner/electric
-
Lighting System:
-
LED
-
Environmental certificate:
-
CE
-
Fans kind:
-
Centrifugal Fans CE
-
Filters:
-
4-stage Filter System
-
Warranty Time:
-
1 Year
Product Description
|
Model
|
JD-A1
|
|
Production name
|
50mm
EPS wallboard
electric heating car spray booth
|
|
External dimensions
|
7000*5100*3200mm (L×W×H)(as your requirements)
|
|
Internal dimensions
|
6900*3900*2500mm (L×W×H)(as your requirements)
|
|
Composite plate
|
50mm foam wool board, density 10kg, tin thickness 0.4mm
|
|
Basement and Floor
|
Channel steel welding assemble, full metal foundation, height is 300mm.
|
|
Steel grating
|
Mechanism of pressure welding 3*4, both sides of the anti slide thickness 1.5mm
|
|
Climbing table
|
Size 1.6*0.5m, mechanism pressure welding 3*4 grille
|
|
The vertical leg
|
10cm international steel welding
|
|
Box
|
4*4 pipe welding, spray
|
|
Lighting system
|
LED lighting, 24 groups(36 groups)
|
|
The top beam
|
4*4 pipe welding
|
|
Two layer bending parts
|
0.6mm galvanized plate bending, spray
|
|
Filter cotton
|
High efficiency three-dimensional plastic filter cotton
|
|
Filter cotton box
|
Using 1mm thick galvanized sheet bending, welding
|
|
The door and the edge
|
Aluminium alloy
|
|
Fan
|
2×3KW YDW double-intake centrifugal fans, total air capacity: 25000m³/h.
|
|
Wire
|
4 square copper core
|
|
Heating system
|
8 groups of three
electric heating
tube infrared heat lamp, each 1kw.
|
|
Air duct
|
Air duct of galvanized plate mechanism, square, tin thickness 0.6mm
|
|
Control system
|
Lighting switch, spraying, heat spraying, baking, temperature controller, time setting, emergency stop, failure indicator, hour meter, thermostat.
|
|
Other parts
|
A sets
|
|
The total power
|
33kw
|
Good environment High work efficiency
Healthy materials
Safe and Convenient
It saves space and is convenient to use. At the same time, it can forcibly dry the primer and topcoat, accelerating work rhythm and increasing work power.
Installation case and Presentation
Suitable for industries such as machinery, automobiles, metal processing, furniture, chemical equipment, etc.
Our spray booth can customized according to your requirements. And with our manufacturing experience and ability, we are able to offer customization at reasonable pricing to fit you.
Detailed Images
Packing & Delivery
The normal packing is sea packing suitable for container loading. If customers have special requirements, we will do our best to meet customer requirements.
