Quick Details
-
Engine:
-
100CC Single-cylinder air-cooled, 4-stroke
-
Color:
-
Red/Blue/Green/Black etc
-
Wheel:
-
Spoke wheel/Aluminium Wheel
-
Brake:
-
Front Disc/Drum brake, Rear Drum brake
-
Seat:
-
Lengthened and thickened seat
-
Clutch:
-
Manual Clutch
-
Fuel consumption:
-
<1.8L/100KM
-
Carburter:
-
Deli/Kama
-
Battery:
-
Liyang/Yuasa
Quick Details
-
Displacement:
-
50-100CC
-
Max. Speed:
-
> 80km/h
-
Model Number:
-
BX100S
-
Engine:
-
100CC Single-cylinder air-cooled, 4-stroke
-
Color:
-
Red/Blue/Green/Black etc
-
Wheel:
-
Spoke wheel/Aluminium Wheel
-
Brake:
-
Front Disc/Drum brake, Rear Drum brake
-
Seat:
-
Lengthened and thickened seat
-
Clutch:
-
Manual Clutch
-
Fuel consumption:
-
<1.8L/100KM
-
Carburter:
-
Deli/Kama
-
Battery:
-
Liyang/Yuasa
Product Introduction
Specification
|
ENGINE
|
|
|
|
Engine Type:
|
Single-cylinder,air-cooled, 4-stroke
|
|
|
Displacement (ml):
|
98ml
|
|
|
Bore X Stroke (mm):
|
50*49.8
|
|
|
Compression Ratio:
|
9.5:1
|
|
|
Max. Power (kw/r/min)
|
5.8/8500
|
|
|
Max. Torque (N.m/r/min):
|
6.5/7500
|
|
|
Max. Speed (Km/h):
|
≥90
|
|
|
Lubrication:
|
Pressure ,splash
|
|
|
Clutch Type:
|
Multiplate wet clutch
|
|
|
Ignition:
|
CDI
|
|
|
Starting System:
|
Electric/Kick start
|
|
|
Transmission System:
|
Chain drive
|
|
|
CHASSIS
|
|
|
|
Front shock absorber:
|
hydraulic pressure and spring
|
|
|
Rear shock absorber:
|
hydraulic pressure and spring, double rear shock absorbers
|
|
|
Chassis structure:
|
Steel tube and steel plate,rhombic structure
|
|
|
Rear fork:
|
steel
|
|
|
Front Brake:
|
Disc/Drum Brake
|
|
|
Rear Brake:
|
Drum Brake
|
|
|
Front Tire:
|
2.5-18
|
|
|
Rear Tire:
|
3.00-17
|
|
|
Muffler:
|
steel
|
|
|
Steering Head Angle:
|
39/41
|
|
|
Wheel rim
|
Alloy/Spoke
|
|
|
Battery:
|
12V5Ah
|
|
|
DIMENSIONS
|
|
|
|
L X W X H (mm):
|
1920*770*1080
|
|
|
Seat Height (mm):
|
845mm
|
|
|
Wheelbase (mm):
|
1250mm
|
|
|
Min. Ground Clearance (mm):
|
160mm
|
|
|
Max. Permissionable Weight (kg):
|
150
|
|
|
Rider Capacity:
|
2 Persons
|
|
|
Dry. Weigth (kg):
|
85
|
|
|
Fuel Tank Capacity (L):
|
8
|
|
|
Packing Size (mm):
|
1480×380×860
|
|
|
Packing Weight (kg):
|
105
|
|
