Quick Details
-
Brand Name:
-
amity
-
Weight (KG):
-
979 kg
Quick Details
-
Min. Lifting Height:
-
1m, 2m, 2.5m, 3m
-
Warranty:
-
1 Year
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
amity
-
Weight (KG):
-
979 kg
|
CDD0516 |
CDD1016 |
CDD1516 |
CDD2016 |
CDD3016 |
|
|
Load Capacity (kg) |
500 |
1000 |
1500 |
2000 |
3000 |
|
Max. Lift Height (mm) |
1600 |
1600 |
1600 |
1600 |
1600 |
|
Battery (V/Ah) |
24/120 |
24/135 |
24/165 |
24/180 |
24/210 |
|
Charger (V/A) |
24/15 |
24/20 |
24/25 |
24/25 |
24/30 |
|
Lift Motor (kw) |
2.5 |
2.5 |
2.5 |
2.5 |
4.0 |
|
Drive Motor (kw) |
AC1.5 |
AC1.5 |
AC1.5 |
AC1.5 |
AC2.5 |
|
Outriggers Width (mm) |
562 |
562 |
562 |
562 |
562 |
|
Weight (kg) |
610 |
630 |
650 |
670 |
840 |
|
Overall Size (LxWxH) (mm) |
2000 *850 *2000 |
||||
|
ForkSize (mm) |
1150*160*70 (LxWxH) |
||||
|
Fork Overall Width (mm) |
600 |
||||
|
Min. Fork Height (mm) |
85 |
||||
|
Outriggers Size (mm) |
1000*115*50 (LxWxH) |
||||
|
Drive Wheel (mm) |
¢ 250*80 x lpc |
||||
|
Auxiliary Wheel (mm) |
¢ 150*50 x 2pcs |
||||
|
Front Wheel (mm) |
¢ 80*70 x 4pcs |
||||
|
Climbing Slope (%) |
4/6 |
||||
|
Travel Speed (km/h) Lifting Speed (mm/s) Falling Speed (mm/s) |
Loaded/Unloaded 45/50 Loaded/Unloaded 45/40 Loaded/Unloaded |
||||
|
Service Brake |
Electromagnetic Braking |
||||
1:Suitable for single-sided and double-sided tray
2:Mast can move forward 500mm
3:Powerful drive system, stable performance
4:Intelligent battery charger automatically cut off power when charging is completed
5:Ultra-silence Abrasion resistant PU Wheels could prevent working floor from scratch
6:Durable lead-acid battery lasts for long time continuously work
7:Small volume Lifting pump ,with reliable and stable performance, noiseless and e nvironment protecting
8:Adopts America Curtis e lectronic control assembly , with power display table, and power condition s are v isible at any time
