Quick Details
-
Output Speed:
-
37.5rpm
-
Warranty:
-
1year
-
Weight (KG):
-
24
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
juzhi
-
Product name:
-
Rotary Tiller Gearbox Ltd
-
Color:
-
Green, blue,etc
-
Packing:
-
Wooden box/ carton
-
Ratio:
-
30
-
Material of housing:
-
Iron cast
-
Installation:
-
Horizontal or Vertical
-
Type:
-
Gearbox Ltd
-
Lubricant:
-
Synthetic & Mineral
Quick Details
-
Gearing Arrangement:
-
Worm
-
Output Torque:
-
99N.M
-
Input Speed:
-
1500rpm
-
Output Speed:
-
37.5rpm
-
Warranty:
-
1year
-
Weight (KG):
-
24
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
juzhi
-
Product name:
-
Rotary Tiller Gearbox Ltd
-
Color:
-
Green, blue,etc
-
Packing:
-
Wooden box/ carton
-
Ratio:
-
30
-
Material of housing:
-
Iron cast
-
Installation:
-
Horizontal or Vertical
-
Type:
-
Gearbox Ltd
-
Lubricant:
-
Synthetic & Mineral
Gear box are used to transfer rotation and torque from motor to working machine.Most gear boxes are used to decrease speed by gears in the gear box .
Worm gear box is much widely used in mordern machinery systems,since it’s ratio can be up to 1:100 easily ,which is much bigger than all gears box , and it’s demision is much smaller than all gears when ratio is same.
Design characteristics:
Our Gearbox has many items for your choosing and we can produce as per your drawing or sample to meet your special request
1. Large output torque
2. Safe, reliable, economical and durable
3. Stable transmission, quiet operation
4. High carrying ability
5. High modularization design, may equip with various outer power input conveniently. Same machine type may equip with various
power motor. It is easy to realize the combination and junction between every machine type
6. Transmission ratio: Fine division, wide scope. The combined machine type may form very large transmission ratio, i. E.
Output very low rotary speed.
7. Form of installation: The position to be installed is not limited.
8. High strength, compact the box body of high strength cast iron, gear and gear shaft adapts the gas carbonization, quenching
and fine grinding process, therefore the bearing capacity of unit volume is high.
9. Long life: Under the condition of correct type chosen(including choosing suitable operation parament ) normal operation and
maintenance, the life if main parts speed reducer(except wearing parts)should not be less than 20000 hours. The wearing parts
include lubricating oil, oil seal and bearing.
10. Low noise: Because main parts of speed reducer are processed, and tested critically, therefore the noise of speed reducer
is low.
11.Our gear box have reached the advance international level, can replace the same kind of products imported.
Maintence:
After 300-hour operation, please change the oil, and flush the gear uint with suitable detergents.
Pls do not mix the mineral oil and synthetic oil.
pls check the oil level in regular time.
Storage:
1:Pls do not store in outdoor.
2:pls put cardboard, wood or other material between the products and floor. the gear box cannot directly touch the floor.
(1) With excellent quality and Reasonable price
(2) Promise to delivery on time
(3) Safe, reliable, economical and durable
(4) Stable transmission, quiet operation
(5) High heat-radiating efficiency, high carrying ability
(6) Every product must be tested before sending
