Quick Details
-
Dimension(L*W*H):
-
700*700*2500mm
-
Weight:
-
800 KG
-
After-sales Service Provided:
-
Online support
-
Name:
-
600m depth water well drilling rig/water swivel for drilling rig
-
Drilling depth:
-
80-600M
-
Application:
-
ater swivel for drilling rig
-
Drilling diameter:
-
75-300mm
-
Feature:
-
portable water well drilling equipment
-
Keyword:
-
Hydraulic Drilling Rig For Water Wells
-
Item:
-
portable rotary water well drilling
-
Product name:
-
Multifunction Hydraulic Drilling Rig For Water Wells
-
Certification:
-
ISO
Quick Details
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
ORANGEMECH
-
Voltage:
-
220v /380v
-
Dimension(L*W*H):
-
700*700*2500mm
-
Weight:
-
800 KG
-
After-sales Service Provided:
-
Online support
-
Name:
-
600m depth water well drilling rig/water swivel for drilling rig
-
Drilling depth:
-
80-600M
-
Application:
-
ater swivel for drilling rig
-
Drilling diameter:
-
75-300mm
-
Feature:
-
portable water well drilling equipment
-
Keyword:
-
Hydraulic Drilling Rig For Water Wells
-
Item:
-
portable rotary water well drilling
-
Product name:
-
Multifunction Hydraulic Drilling Rig For Water Wells
-
Certification:
-
ISO
small portable water well drilling rig HY-350
Portable small water well drilling rig for sale
Small trailer borehole water well drilling rig for sale
Movable Portable Hydraulic Used for Borehole Water Well Drilling Rig Machine
Portable Small Diesel Engines Water Well Drilling Rig
Multifunction Hydraulic Drilling Rig For Water Wells
600m depth water well drilling rig/water swivel for drilling rig/drilling equipment for water manufacture factory
Full hydraulic pprtable minin water well drilling rig machine for sale
Portable small water well drilling rig for sale
Small trailer borehole water well drilling rig for sale
Movable Portable Hydraulic Used for Borehole Water Well Drilling Rig Machine
Portable Small Diesel Engines Water Well Drilling Rig
This machine mainly used for geothermal drilling, farm irrigation , house yard, gardens and water well drilling, drilling diameter is 70-3 5 0mm, and drilling depth is 80m to 100m . It also can be used in small building piling, like farmhouse or factory, the drilling diameter can reach 6 00mm and depth can be more than 1 20 meter.
The advantage of the water well drilling machine are as below:
1.
Light weight
, energy saving.
2.
Patented product, u
nique design and simple drilling structure;
3. Easy to transport and can learn how to handle the machine in short time;
4. Can drill through hard stratum, unless thick rock layer ;
5.
One person operation
, reduce the labor intensity ;
6. High efficiency
and work fast.
7. Assure easily operation and long life service life
Small trailer borehole water well drilling rig for sale
Portable Small Diesel Engines Water Well Drilling Rig
|
Type |
Electric type machine |
Electric type machine |
|
Model of drilling machine |
HY-180 electric type |
HY-350 electric type |
|
Drilling machine overall dimension(mm) |
700*700*2500 |
800*800*2700 |
|
Weight of Drilling machine (kg) |
120 |
250 |
|
Drill rod diameter (mm) |
Ø42 |
Ø 51 |
|
Drill rod length(mm) |
1500 |
1500 |
|
Rod change method |
Full automatic screw thread |
F ull automatic screw thread |
|
Drilling depth(m) |
80 |
100 |
|
Energy |
220V |
Motor |
|
Motor power (KW) |
DC60V, 1.5KW~2KW |
3kw |
|
Drilling method |
Percussive and rotating type |
P ercussive and rotating type |
|
Pump power (KW) |
2.2KW |
2.2kw |
|
Drilling hole diameter(mm) |
Within Ø 200mm |
Within Ø 350mm |
