- Product Details
- {{item.text}}
Quick Details
-
Power:
-
180kw
-
Dimension(L*W*H):
-
40m*19m*18.5m
-
Weight:
-
62000 kg
-
Product name:
-
Asphalt Mixing Plant
-
After-sales Service Provided:
-
Engineers
-
Mixing Type:
-
Hot Asphalt Mixing Plant
-
Model:
-
HZS180D
-
Theory prouducivity:
-
180 m³/h
-
Volume of mainframe:
-
3m³
-
Aggregate max scale:
-
4*3000KG
-
Cement max scale:
-
1600KG
-
Water max scale:
-
800KG
-
Liquid additive max scale:
-
80KG
Quick Details
-
Place of Origin:
-
Hunan, China
-
Brand Name:
-
Top Brand
-
Voltage:
-
/
-
Power:
-
180kw
-
Dimension(L*W*H):
-
40m*19m*18.5m
-
Weight:
-
62000 kg
-
Product name:
-
Asphalt Mixing Plant
-
After-sales Service Provided:
-
Engineers
-
Mixing Type:
-
Hot Asphalt Mixing Plant
-
Model:
-
HZS180D
-
Theory prouducivity:
-
180 m³/h
-
Volume of mainframe:
-
3m³
-
Aggregate max scale:
-
4*3000KG
-
Cement max scale:
-
1600KG
-
Water max scale:
-
800KG
-
Liquid additive max scale:
-
80KG
CONTACT US
Sinomada Heavy Industry (Changsha) Co., Ltd.
Tel: +86-0731-8515-1898
Whatsapp/Wechat/Mobile: +86-17343763978
E-mail: icy@sinomada.com
Add: Room 3501, Building T6, CFC Fuxing World Financial Center, No. 303, Section 1, Furong Middle Road, Kaifu District, Changsha, Hunan, China
Products Description
Asphalt Mixing Dry Mix Mortar Plant HZS180D with Advanced Technology
1. HZS180D Asphalt Mixture Mixing Plant is a self-developed product which has internationally advanced level.
2. The equipment can produce various gradations of asphalt mixture, modified asphalt mixture and warm mixing asphalt mixture, support the use of hot regeneration equipment and foam asphalt equipment, it can fully meet the engineering need of highway, grade roads, municipal roads, airports, dams, freight yard.
3. HZS180D Asphalt Mixture Mixing Plant has obtained many inventions and utility model patents, which have been applied to the equipment.
4. The equipment has a screening accuracy control technology, expert database intelligent precision weighing technology, asphalt secondary weighing technology, intelligent feeding material compensation technology, PID control and expert control technology, intelligent combustion technology, high efficiency dust removal technology, intelligent fault diagnosis technology, which embody the core features of reliable, advanced, intelligent, green of Asphalt Mixture Mixing Plant.
2. The equipment can produce various gradations of asphalt mixture, modified asphalt mixture and warm mixing asphalt mixture, support the use of hot regeneration equipment and foam asphalt equipment, it can fully meet the engineering need of highway, grade roads, municipal roads, airports, dams, freight yard.
3. HZS180D Asphalt Mixture Mixing Plant has obtained many inventions and utility model patents, which have been applied to the equipment.
4. The equipment has a screening accuracy control technology, expert database intelligent precision weighing technology, asphalt secondary weighing technology, intelligent feeding material compensation technology, PID control and expert control technology, intelligent combustion technology, high efficiency dust removal technology, intelligent fault diagnosis technology, which embody the core features of reliable, advanced, intelligent, green of Asphalt Mixture Mixing Plant.
Product Paramenters
|
Technical parameters
|
|
Unit
|
HZS180D
|
|
|
Theory prouducivity
|
|
m³/h
|
180
|
|
|
Volume of mainframe
|
|
m³
|
3
|
|
|
Batcher
|
|
|
PLD4800QD-IV
|
|
|
Batcher(volume perbin)
|
|
m³
|
20
|
|
|
Batcher(bin's amout)
|
|
|
4
|
|
|
Aggregate max scale
|
|
kg
|
4*3000
|
|
|
Cement max scale
|
|
kg
|
1600
|
|
|
Powder material max scale
|
|
kg
|
600
|
|
|
Water max scale
|
|
kg
|
800
|
|
|
Liquid additive max scale
|
|
kg
|
80
|
|
|
The mixer's power
|
|
kw
|
2×55
|
|
|
Lifting power
|
|
kw
|
45
|
|
|
Whole power
|
|
kw
|
190
|
|
|
Discharging height
|
|
m
|
3.8
|
|
|
The whole weight
|
|
t
|
62
|
|
|
Dimension(length×witch×height)
|
|
m
|
40×19×18.5
|
|
|
Feeding style
|
|
|
lifting(lilting)
|
|
|
Calcuulating precision
|
Aggregate
|
|
±2%
|
|
|
|
Powder material
|
|
±1%
|
|
|
|
Water
|
|
±1%
|
|
|
|
Additives
|
|
±1%
|
|
Product Pictures
