Quick Details
-
Engine Brand:
-
CHANGCHAI
-
Travel Speed:
-
0-10km/h
-
Grade Ability:
-
35%
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Storike
-
Dimension(L*W*H):
-
2850*1580*2680 mm
-
Drum diameter:
-
630/720/900mm
-
Exciting Force:
-
30-45KN
-
Marketing Type:
-
Hot Product 2022
-
Vibration frequency:
-
65 HZ
-
Exciting force:
-
30-45KN
-
Nominal amplitude:
-
0.5 mm
-
Walking speed:
-
0-5 KM/H
-
Climbing ability:
-
30%
-
Steering mode:
-
Hydraulic steering
-
Steering system:
-
Swing articulated
-
Water tank capacity:
-
180 L
-
Hydraulic tank capacity:
-
60 L
-
Drum size:
-
900*1400mm*2
Quick Details
-
Type:
-
Drive Tandem Vibratory Roller
-
Power:
-
18.6 KW, 28.5 KW, 36 KW
-
Weight:
-
2000/3000/4000/5000KG
-
Engine Brand:
-
CHANGCHAI
-
Travel Speed:
-
0-10km/h
-
Grade Ability:
-
35%
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Storike
-
Dimension(L*W*H):
-
2850*1580*2680 mm
-
Drum diameter:
-
630/720/900mm
-
Exciting Force:
-
30-45KN
-
Marketing Type:
-
Hot Product 2022
-
Vibration frequency:
-
65 HZ
-
Exciting force:
-
30-45KN
-
Nominal amplitude:
-
0.5 mm
-
Walking speed:
-
0-5 KM/H
-
Climbing ability:
-
30%
-
Steering mode:
-
Hydraulic steering
-
Steering system:
-
Swing articulated
-
Water tank capacity:
-
180 L
-
Hydraulic tank capacity:
-
60 L
-
Drum size:
-
900*1400mm*2
Product Description
Specification
|
Model
|
ST2000
|
ST3000
|
ST4000
|
ST5000
|
||||
|
Operating Weight
|
2000 kg
|
3000 kg
|
4000 kg
|
5000 kg
|
||||
|
Static linear load
|
110/105 N/cm
|
106/94 N/cm
|
135/120 N/cm
|
155/140 N/cm
|
||||
|
Dimensions
|
|
|
|
|
||||
|
Size
|
2445*1050*2255 mm
|
2400*1355*2630 mm
|
2480*1370*2630 mm
|
2850*1580*2680 mm
|
||||
|
Turning radius
|
2955/4005 mm
|
2405/3760mm
|
2405/3760 mm
|
4380 mm
|
||||
|
Drum size
|
630*900 mm *2
|
630*1200 mm*2
|
720*1200 mm*2
|
900*1400mm*2
|
||||
|
Wheel base
|
1565 mm
|
1650 mm
|
1650 mm
|
1950 mm
|
||||
|
Engine
|
|
|
|
|
||||
|
Model
|
Changchai/Yanmar/Kubota
|
Changchai/Yanmar/Kubota
|
Changchai/Yanmar/Kubota
|
Changchai/Yanmar/Kubota
|
||||
|
Power
|
12/18.6/19.9KW
|
28.5/33KW
|
28.5/33KW
|
36/34.5/33.6 KW
|
||||
|
Rating speed
|
3600 rpm
|
3600 rpm
|
3600 rpm
|
3600 rpm
|
||||
|
Driving Character Istics
|
|
|
|
|
||||
|
Walking speed
|
0-8Km/h
|
0-10 Km/h
|
0-10 Km/h
|
0-12 Km/h
|
||||
|
Climbing ability
|
35 %
|
35 %
|
40 %
|
40 %
|
||||
|
Steering
|
|
|
|
|
||||
|
Steering mode
|
Hydraulic steering
|
Hydraulic steering
|
Hydraulic cylinder, articulated steering
|
Hydraulic cylinder, articulated steering
|
||||
|
Steering system
|
Swing articulated
|
Swing articulated
|
Swing articulated
|
Swing articulated
|
||||
|
Exciter System
|
|
|
|
|
||||
|
Vibrating drum
|
Front+Rear
|
Front+Rear
|
Front+Rear
|
Front+Rear
|
||||
|
Driving Form
|
Hydraulic motors
|
Hydraulic motors
|
Hydraulic motors
|
Hydraulic motors
|
||||
|
Frequency
|
65 HZ
|
65 HZ
|
65 HZ
|
65 HZ
|
||||
|
Amplitude
|
0.5 mm
|
0.5 mm
|
0.5 mm
|
0.5 mm
|
||||
|
Centrifugal force
|
30 KN*2
|
35 KN*2
|
40 KN*2
|
45 KN*2
|
||||
|
Sprinkler System
|
|
|
|
|
||||
|
Type of sprinkling
|
Pressure
|
Pressure
|
Pressure
|
Pressure
|
||||
|
Capacities
|
|
|
|
|
||||
|
Hydraulic oil
|
45 L
|
46 L
|
48 L
|
60 L
|
||||
|
Fuel
|
36 L
|
42 L
|
44 L
|
45 L
|
||||
|
Water
|
140 L
|
140 L
|
180 L
|
180 L
|
||||
