Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Lin Pack
-
Dimension(L*W*H):
-
2100*1400*1700mm(L*W*H)
-
Weight:
-
1600 KG
-
After-sales Service Provided:
-
Engineers available to service machinery overseas, Free spare parts, Video technical support, Online support
-
Material:
-
304 Stainless Steel Material
-
Filling material:
-
Puffed food, candy, biscuit, peanut, sugar, etc
-
Pouch size:
-
W:120-240mm, L:150-320mm
-
Pouch type:
-
Zipper bags, stand-up pouches, three/four side sealed bags
-
Filling volume:
-
20-2000g
-
Packing speed:
-
10-40bags
-
Compress air requiremen:
-
More than 0.6m3/min supply by user
-
After Warranty Service:
-
Video technical support, Online support, Spare parts, Field maintenance and repair service
-
Local Service Location:
-
Canada, Turkey, United Kingdom, United States, Italy, France, Germany, Viet Nam, Philippines, Indonesia, Pakistan, India, Russia, Spain, Thailand, Japan, Malaysia, Australia, Kenya, South Korea, UAE, South Africa, Ukraine
-
Certification:
-
CE ISO9001
Quick Details
-
Packaging Type:
-
Bags, Pouch, Stand-up Pouch
-
Packaging Material:
-
Plastic, Composite material
-
Voltage:
-
380V
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Lin Pack
-
Dimension(L*W*H):
-
2100*1400*1700mm(L*W*H)
-
Weight:
-
1600 KG
-
After-sales Service Provided:
-
Engineers available to service machinery overseas, Free spare parts, Video technical support, Online support
-
Material:
-
304 Stainless Steel Material
-
Filling material:
-
Puffed food, candy, biscuit, peanut, sugar, etc
-
Pouch size:
-
W:120-240mm, L:150-320mm
-
Pouch type:
-
Zipper bags, stand-up pouches, three/four side sealed bags
-
Filling volume:
-
20-2000g
-
Packing speed:
-
10-40bags
-
Compress air requiremen:
-
More than 0.6m3/min supply by user
-
After Warranty Service:
-
Video technical support, Online support, Spare parts, Field maintenance and repair service
-
Local Service Location:
-
Canada, Turkey, United Kingdom, United States, Italy, France, Germany, Viet Nam, Philippines, Indonesia, Pakistan, India, Russia, Spain, Thailand, Japan, Malaysia, Australia, Kenya, South Korea, UAE, South Africa, Ukraine
-
Certification:
-
CE ISO9001
Main Technical Parameter:
|
Model |
MR10-120ZK |
MR10-160ZK |
MR8-240ZK |
|
Bags Size |
W:55-120 mm L: 80-180mm |
W:80-160 mm L: 100-240mm |
W:120-240 mm L: 150-320mm |
|
Max. Filling |
1000g |
1000g |
2000g |
|
Speed |
40-60 bags/min |
30-50 bags/min |
10-40 bags/min |
|
Power |
6kw |
6kw |
6kw |
|
Dimension |
2500×1600×1650 |
2900×2050×1650 |
2600×2400×1650 |
|
Weight |
2100kg |
2500kg |
3000kg |
| Model NO.: | MR8-240ZK |
| Pouch type | stand-up pouches, zipper bags,four/three side sealed bags |
| Pouch Size | Width(mm): 120-240, Length(mm):150-320 |
| Filling Volume | 20-1000g(Depend on type of products) |
| Capacity(PPM) | 10-40 bags/ min |
| Package Accuracy | Error≤±1G |
| Total power | 2.5KW(220V/380V,3PH,50HZ) |
| Demension | 2600*1900*1700mm(L*W*H) |
| Weight | 3000KGS |
| Compress air requirement | ≥0.6m³/min supply by user |
| Features and Characteristics | 1. incessant rotary vacuum system |
| 2. quick changeover | |
| 3. comply with the sanitation requirements of food processing machines | |
| 4. materials contact parts adopt 304 stainless steels | |
| 5. easy to operate | |
| 6. sealing temperature detection | |
| 7. the machine adopts PLC and POD(touch screen)electrical control system | |
| 8. friendly man-machine interface | |
| 9. high-quality sealing bag mouth | |
| Application: | Block: chocolate, candies, cereal, biscuits, cakes, puffed food, etc. |
| Granule: nuts, capsules, seeds, feeds, pesticides, fertilizers, etc. | |
| Powder: seasoning, milk powder, washing powder, fine sugar,etc. | |
| Liquid/sauce: detergent, juice, beverage, ketchup, jam | |
| Pickles: carrots, etc. | |
| necessary infos offered in inquiry | pouch type |
| pouch size | |
| filling material |
Main Function:
Pick up Bag -Open bag -Fill Material -Vacuum - Seal for Products.
Applications:
Pickles, Peanut , Nuts , Fish, Meat , Rice , Fish Ball , Meat Ball , Cooked Food , Daily commodities, etc.
Pouch Type:
Machine Description:
Work Process:
Standard Equipment Part:
| 1. Date printer | 6. Magnetic valve |
| 2. PLC control system | 7. Temperature controller |
| 3. Pouch opening devices | 8. Vacuum pump |
| 4. Vibrator device | 9. Frequency convertor |
| 5. Cylinder | 10. Output system |
Optional Configuration:
