Quick Details
-
Walkie Talkie Type:
-
walkie talkie
-
Place of Origin:
-
Fujian, China
-
Brand Name:
-
Recent
-
Model Number:
-
RS-35M
-
Dimensions:
-
117*79*42mm
-
Frequency Range:
-
400-470
-
Private Mold:
-
Yes
Quick Details
-
Talk Range:
-
1-5KM
-
Terminal style:
-
Handheld
-
Storage Channel:
-
22
-
Walkie Talkie Type:
-
walkie talkie
-
Place of Origin:
-
Fujian, China
-
Brand Name:
-
Recent
-
Model Number:
-
RS-35M
-
Dimensions:
-
117*79*42mm
-
Frequency Range:
-
400-470
-
Private Mold:
-
Yes
| ENERAL SPECIFICATIONS | |
|
Band
|
136-174MHz 403-527MHz |
| High Power Output |
5W( 136-174MHz ) 4W (403-527MHz) |
| High Power Output |
1W(
136-174MHz)
1W (403-527MHz) |
| Channel Spacing | 12.5/25KHz |
| Channel Capacity | 1000 |
| Dimensions(HXWXD) | 130.3 x 55.2 x 41.1mm |
| Weight(Radio + Standard 1600mAh Battery) | 365.5g |
| Digital/Analogue Battery Life(Standard 1600mAh Battery) | 11.5 - 16.0hrs |
| Power Supply(Nominal) | 7.5V |
| TRANSMITTER SPECIFICATIONS | |
| 4FSK Digital Modulation |
12.5 kHz Oata:7K60FID and 7K60FXD
|
| Digital Protocol | ETSI TS 102 361-1,-2,-3 |
| Conducted/Radiated Emissions(TIA603D) | -36dBm<1GHz, -30dBm>1GHz |
| Adjacent Channel Power |
60dB(12.5KHz channel), 70dB(25KHz channel) |
| Frequency Stability | ±0.5ppm |
| AUDIO SPECIFICATIONS | |
| Digital Vocoder Type | AMBE+2 |
| Audio Response | TIA603D |
| Rated Audio | 0.5 W |
| Audio Distortion at Rated Audio | 3% |
| Hum and Noise | -40 dB (12.5 kHz channel), -45 dB (25 kHz channel) |
| Conducted Spurious Emissions (TIA603D) | -57 dBm |
| ENVIRONMENTAL SPECIFICATIONS | |
| Operating Temperature | -30 °C to +60 °C |
| Storage Temperature |
-40 °C to +85 °C |
| Electrostatic Discharge | IEC 61000-4-2 Level 4 |
| Dust and Water Intrusion | IEC 60529 - IP67 |
| Packaging Test | MIL-STD 810D and E |
