Quick Details
-
Warranty:
-
25 Years Warranty, 25 years linea warranty
-
Brand Name:
-
JA Solar
-
Model Number:
-
JAM54D41
-
Place of Origin:
-
Jiangsu, China
-
Panel Dimensions:
-
1762*1134*30mm
-
Application:
-
Solar Power System
-
No. of cells:
-
144 (6*24) Cells
-
Junction box:
-
IP68,3 diodes
-
Package:
-
36 pcs per pallet
-
40HQ:
-
936Pcs
-
OEM Order:
-
Acceptaple
-
Color:
-
Deep Blue
-
Certificate:
-
CE TUV ETL
Quick Details
-
Cell size:
-
182mmx182mm
-
Type:
-
PERC, Half Cell, Bifacial, Double-glass, All Black, IBC, HJT, N-TYPE
-
Panel Efficiency:
-
22.8%
-
Warranty:
-
25 Years Warranty, 25 years linea warranty
-
Brand Name:
-
JA Solar
-
Model Number:
-
JAM54D41
-
Place of Origin:
-
Jiangsu, China
-
Panel Dimensions:
-
1762*1134*30mm
-
Application:
-
Solar Power System
-
No. of cells:
-
144 (6*24) Cells
-
Junction box:
-
IP68,3 diodes
-
Package:
-
36 pcs per pallet
-
40HQ:
-
936Pcs
-
OEM Order:
-
Acceptaple
-
Color:
-
Deep Blue
-
Certificate:
-
CE TUV ETL
Specification
|
Mechanical Parameters
|
|
|
|
Cell
|
Mono
|
|
|
Weight
|
22kg
|
|
|
Dimensions
|
1762*1134*30mm
|
|
|
Cable Cross Section Size
|
4mm²(IEC),12WG(UL)
|
|
|
NO.of cells
|
106
|
|
|
Junction box
|
IP68,3diodes
|
|
|
Front Glass/Back Glass
|
1.6mm/1.6mm
|
|
|
Packaging Configuration
|
36pcs/Pallet, 936pca/40HQ Container
|
|
|
ELECTRICAL DATA (STC)
|
|
|
|
|
|
|
||||||
|
Type
|
430
|
435
|
440
|
445
|
450
|
455
|
||||||
|
Rated Maximum Power Pmax(W)
|
430
|
435
|
440
|
445
|
450
|
455
|
||||||
|
Open Circuit Voltage-Voc(V)
|
38.5
|
38.7
|
38.9
|
39.10
|
39.30
|
39.50
|
||||||
|
Maximum Power Voltage-Vmpp(V)
|
32.12
|
32.29
|
32.47
|
32.65
|
32.822
|
33.00
|
||||||
|
Short Circuit Current-lsc(A)
|
14.14
|
14.23
|
14.31
|
14.40
|
14.48
|
14.56
|
||||||
|
Maximum Power Current-lmpp(A)
|
13.39
|
13.47
|
13.35
|
13.63
|
13.71
|
13.79
|
||||||
|
Module Efficiency(%)
|
21.5
|
21.8
|
22.0
|
22.3
|
22.5
|
22.8
|
||||||
|
Power Tolerance
|
0--+3%
|
|
|
|
|
|
||||||
|
Temperature Coefficient of Isc
|
+0.046%/℃
|
|
|
|
|
|
||||||
|
Temperature Coefficient of Voc
|
-0.260%/℃
|
|
|
|
|
|
||||||
|
Temperature Coefficient of Pmax
|
-0.290%/℃
|
|
|
|
|
|
||||||
|
STC
|
Irradiance 1000W/m², cell temperature 25℃,AM1.5G
|
|
|
|
|
|
||||||
|
Electrical characteristics with 10% SOLAR IRRADIATION RATIO
|
|
|
|
|
|
|
||||||
|
Type
|
430
|
435
|
440
|
445
|
450
|
455
|
||||||
|
Rated Max Power(Pmax)(W)
|
464
|
470
|
475
|
481
|
486
|
491
|
||||||
|
Open Circuit Voltage-Voc(V)
|
38.5
|
38.70
|
38.90
|
39.10
|
39.30
|
39.50
|
||||||
|
Maximum Power Voltage-Vmp(V)
|
32.11
|
32.29
|
32.47
|
32.65
|
32.82
|
32.99
|
||||||
|
Short Circuit Current-lsc(A)
|
15.27
|
15.36
|
15.46
|
15.55
|
15.64
|
15.73
|
||||||
|
Maximum Power Current-Impp(A)
|
14.46
|
14.55
|
14.63
|
14.72
|
14.81
|
14.89
|
||||||
|
Irradiation Ratio (rear/front)
|
10%
|
|
|
|
|
|
||||||
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
