Quick Details
-
Model Number:
-
WTDZW-63A
-
Rated Voltage:
-
80-300V
Quick Details
-
Poles Number:
-
2
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
RMshebei
-
Model Number:
-
WTDZW-63A
-
Rated Voltage:
-
80-300V
Features:
meter prepayment,
over-voltage protection,
under-voltage protection,
over-current protection,
leakage protection,
temperature protection,
timer, countdown timer,
cycle timer,
pointing switch,
all of which can be queried for hourly-annual power consumption,
prepaid password management.
Technical Parameters:
Overvoltage default 275V
Undervoltage default 175V
Default Temperature 85℃
Rated current In: In is 63A.
(Over-voltage, under-voltage, temperature, up and down can be set at your own discretion.)
Overvoltage value 240-300V
Undervoltage value 145-210V
Temperature 10-85℃
Tripping times 1-30 times
Operating characteristics under overpressure:
Setting range of overvoltage action value :AC240-300V.
Overvoltage Recovery Uvor:AC 220-250V.
Undervoltage action characteristics:
Setting range of undervoltage action value:AC 140-190V.
Undervoltage Recovery Value Uvur: AC 170-220V.
Under voltage operation delay: 0.5S-6S
Power on again after power off: If the system is settoautomatic mode,the system automatically closeswhen no fault is detected, and the closing time is lessthan 3S: If the system is set to manual mode, thesystem cannot automatically close.
