Quick Details
-
Brand Name:
-
Sunpor, Sunpor
-
Model Number:
-
KDE6500T
-
Weight:
-
150kg
-
Type:
-
KDE6500T
-
Rated frequency(Hz):
-
50/60Hz
-
Rated output(kW):
-
4.5 4.8
-
Max.output(kW):
-
5.0 5.2
-
Rated voltage(V):
-
220 or as request
-
Rated current(A):
-
20.5 22.7
-
Rated speed(r/min):
-
3000 3600
-
Phase.No:
-
Single Phase
-
Rated Power[kW(r/min)]:
-
5.7/3000 6.3/3600
Quick Details
-
Rated Current:
-
20.5 22.7A
-
Frequency:
-
50/60Hz
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Sunpor, Sunpor
-
Model Number:
-
KDE6500T
-
Weight:
-
150kg
-
Type:
-
KDE6500T
-
Rated frequency(Hz):
-
50/60Hz
-
Rated output(kW):
-
4.5 4.8
-
Max.output(kW):
-
5.0 5.2
-
Rated voltage(V):
-
220 or as request
-
Rated current(A):
-
20.5 22.7
-
Rated speed(r/min):
-
3000 3600
-
Phase.No:
-
Single Phase
-
Rated Power[kW(r/min)]:
-
5.7/3000 6.3/3600
Product Description
| Diesel Generator | ||||||
| Model | KDE3500T | KDE6500T | KDE7500T | KDE8600T | KDE10000T | KDE13000T |
| Rated frequency(Hz) | 50/60Hz | |||||
| Rated output(kW) | 2.5 2.8 | 4.5 4.8 | 4.8 5.0 | 6.0 6.2 | 8 | 9.5 |
| Max.output(kW) | 2.8 3.0 | 5.0 5.2 | 5.2 5.5 | 6.5 7.0 | 8.8 | 10 |
| Rated voltage(V) |
220 or as request
|
|||||
| Rated current(A) | 11.3 12.7 | 20.5 22.7 | 22.7 23.6 | 27.2 28.2 | 36.9 | 39.1 |
| Rated speed(r/min) | 3000 3600 | 3000 | 3000 | |||
| Phase.No | Single Phase | |||||
| Power factor | 1 | 1 | ||||
| Insulation Grade | F | F | ||||
| Pole Number | 2 | 2 | ||||
| Excitation Mode | Self-excitation & constant voltage(AVR) | |||||
| Panel Type | General Panel | General Panel | ||||
| Receptacle |
Two receptacles
|
|||||
| DC12 output | Optional | |||||
| Overall Dimension(LxWxH)mm | 945x555x700 | 945x555x700 | 945x555x700 | 945x555x700 | 1050x620x730 | 1130x680x800 |
| Dry Weight(kg) | 144 | 150 | 150 | 155 | 195 | 220 |
| Noise Level(7m) | 72 | 72 | 72 | 72 | 72 | 72 |
| Structure type | Silent | |||||
| Engine Model | SP178F | SP186FA | SP188FA | SP192FC | SP1100FE | SP1103F |
| Engine Type | Single Cylinder,vertical,four stroke,direct injection,air cooled | |||||
| Cylinder NO-Bore*Stroke(mm) | 78*62 | 86*72 | 88*75 | 92*75 | 100*85 | 103*85 |
| Displacement(cc) | 296 | 418 | 456 | 498 | 670 | 740 |
| Rated Power[kW(r/min)] | 3.68/3000 4/3600 | 5.7/3000 6.3/3600 |
6.5/3000
7.2/3600 |
8.1/3000
8.7/3600 |
10.5/3000 | 12.5/3000 |
| Compression Ratio | 20:01 | 19:01 | ||||
| Lubrication System | Pressure splashed | |||||
| Starting system | Recoil+Electrical | Electrical | ||||
| Fuel Type | 0#(summer)-10#(winter) -35(chillness) diesel | |||||
| Lube oil brand | CD grade or SAE10W-30,15W-40 | |||||
| Lube capacity (L) | 1.1 | 1.65 | 1.65 | 1.65 | 2 | 3 |
| Fuel Tank Capacity(L) | 16 | 16 | 16 | 16 | 28 | 28 |
