Quick Details
-
Model Number:
-
W250-92
-
Dimension:
-
10 INCH
-
Output Power:
-
250W
-
Nominal diameter:
-
10 inch
-
Nominal impedance:
-
8 ohm
-
Power rating:
-
250w
-
Sensitivity:
-
96dB
-
Frequency range:
-
75-6K Hz
-
Voice coil diameter:
-
65.5mm
-
Magnet:
-
neodymium
-
Fs:
-
75Hz
-
Re:
-
4.6ohm
-
Net weight:
-
2.966KG
Quick Details
-
Warranty:
-
3months-1year
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
BMY
-
Model Number:
-
W250-92
-
Dimension:
-
10 INCH
-
Output Power:
-
250W
-
Nominal diameter:
-
10 inch
-
Nominal impedance:
-
8 ohm
-
Power rating:
-
250w
-
Sensitivity:
-
96dB
-
Frequency range:
-
75-6K Hz
-
Voice coil diameter:
-
65.5mm
-
Magnet:
-
neodymium
-
Fs:
-
75Hz
-
Re:
-
4.6ohm
-
Net weight:
-
2.966KG
Product Description
Specification
|
Nominal diameter
|
10 inch
|
|
Nominal impedance
|
8 ohm
|
|
Power rating
|
250w
|
|
Sensitivity
|
96dB
|
|
Frequency range
|
76-6 K Hz
|
|
Voice coil diameter
|
65.5mm
|
|
Magnet
|
neodymium
|
|
Fs
|
75Hz
|
|
Re
|
4.6ohm
|
|
Qms
|
6.711
|
|
Qes
|
0.467
|
|
Qts
|
0.437
|
|
Vas
|
17.227Ltr
|
|
Cms
|
101.126 u M/N
|
|
n.(%)
|
1.54%
|
|
BL
|
14.327T
|
|
Sd
|
34.636cm²
|
|
Basket
|
Die cast alumium
|
|
Cone and dust cap
|
Paper U- SONIC
|
|
Surround
|
Cloth
|
|
Voice coil wire
|
COPPER
|
|
Voice coil bobbin
|
GLASS FIBER
|
|
Magnet
|
NEO
|
|
Over all diameter
|
261.4mm
|
|
Bolt circle diameter
|
245mm-6.5mm-4 holes
|
|
Cut out diameter
|
231mm
|
|
Depth
|
100mm
|
|
Net weight
|
2.966 Kg
|
|
X max
|
8.5mm
|
