Quick Details
-
Brand Name:
-
S&K
-
Weight (T):
-
5
-
Product name:
-
plastic scrap crusher machinec
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Warranty time:
-
One year
-
Machine color:
-
Customized
-
warranty period:
-
1 year
-
Maximum capacity:
-
5000kg
-
Certification:
-
CE ISO
-
After Warranty Service:
-
Online support
-
Local Service Location:
-
None
-
Marketing Type:
-
New Product 2021
Quick Details
-
Max.Production Capacity (kg/h):
-
5000kg
-
Place of Origin:
-
Jiangsu, China
-
Production Capacity (kg/h):
-
1000 - 5000 kg/h
-
Brand Name:
-
S&K
-
Weight (T):
-
5
-
Product name:
-
plastic scrap crusher machinec
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Warranty time:
-
One year
-
Machine color:
-
Customized
-
warranty period:
-
1 year
-
Maximum capacity:
-
5000kg
-
Certification:
-
CE ISO
-
After Warranty Service:
-
Online support
-
Local Service Location:
-
None
-
Marketing Type:
-
New Product 2021
Products Description
XD Double Shaft Shredder Machine
The XD serious double shafts shredders have been designed for a wide ways of applications and industries, such as:shredding WEEE waste, scrap tires, packaging barrel, pallets, etc. Depending on input materials and the following process the shredded material can be used directly or go into the next step of size reduction. XD’s serious double shaft shredder has two rotors built into the machine that rotate at low speeds, high torque and low noise. Adopt with microcomputer control system with function of start, stop, automatic reverse sensors to protect the machine against over loading and jamming.
Based on different materials, we design the special blades with different hooks, normally, we have single hooks blade, double hooks blades, four hooks blades and multi-hooks blades. Also the thickness of blades for different materials are different, the range is 10mm-80mm. We design single or multi-hooks of blades with different thickness for different materials.
Such as:
The 10 and 20mm thick blades are suitable for fragile materials such as medical packaging and electrical board.
The 40 and 50mm thick blades are widely used for various materials such as tires, plastic products, wood pallets, film and etc.
The 80mm thickness blades are used for shredding metal items or plastic and metal compounds such as refrigerator and drums, the blades can handle material up to 10mm in thickness.
XD400 Double Shaft Shredder Machine
XD600 Double Shaft Shredder Machine
XD800 Double Shaft
Shredder Machine
XD1000&1200 Double Shaft
Shredder Machine
XD1500 Double Shaft
Shredder Machine
Shredder Machine
|
Model
|
XD400
|
XD600
|
XD800
|
XD1000
|
XD1200
|
XD1500
|
|
Motor Power
|
3+3 kw
|
7.5+7.5 kw
|
15+15 kw
|
18.5+18.5 kw
|
30+30 kw
|
55+55 kw
|
|
Qty of Rotor blades
|
20pcs
|
20pcs
|
20pcs
|
20pcs
|
24pcs
|
30 pcs
|
|
Qty of Fixed blades
|
20mm
|
30mm
|
40mm
|
50mm
|
50mm
|
50mm
|
|
Materials of blades
|
Cr12MoV/SKDII
|
Cr12MoV/SKDII
|
Cr12MoV/SKDII
|
Cr12MoV/SKDII
|
Cr12MoV/SKDII
|
Cr12MoV/SKDII
|
|
Speed
|
15-24rpm
|
15-24rpm
|
15-24rpm
|
15-24rpm
|
15-24rpm
|
15-24rpm
|
|
Diameter of Rotor
|
200 mm
|
285 mm
|
285 mm
|
320 mm
|
380 mm
|
480 mm
|
|
shredding room size
|
400*250 mm
|
600*430 mm
|
800*430 mm
|
1000 *500 mm
|
1000 *580 mm
|
1000 *740 mm
|
|
Dimension L/W/H
|
1200*1300*1400 mm
|
2800*1300*1850 mm
|
3200*1300*1950 mm
|
3200*1300*2000mm
|
4000*1400*2200mm
|
4500*1500*2400mm
|
|
Weight
|
1100 kg
|
2300 kg
|
3300 kg
|
5000 kg
|
6800 kg
|
10000 kg
|
Note:
1.
The above machine configurations are our factory's standard configurations, and there may be different configurations for different materials. Please contact us for specific situations or special requirements.
2. The standard configuration of the dual axis shredder blade is 1 claw, 3 claws, 5 claws, 7 claws, and 9 claws. If you have any special requirements, please call for consultation.
3. The above technical parameters are for reference only and are subject to change without prior notice. Customers should call our sales personnel to confirm before placing an order.
