Quick Details
-
Brand Name:
-
HYSINCERE
-
Model Number:
-
HX12400S
-
Place of Origin:
-
Guangdong, China
-
Weight:
-
45-200kg
-
The charging ratio:
-
1c
-
The discharge rate:
-
3c
-
Electric Energy:
-
5120 Wh
-
Certification:
-
PSE, IEC62133, METI, CE, REACH
-
Battery type:
-
Lithium Iron Phosphate Battery
-
OEM/ODM:
-
Accepatable
-
Cycle life:
-
6000 Times
Quick Details
-
Storage Type:
-
-20 to 60
-
Anode Material:
-
LFP
-
Application:
-
Power Tools, Home Appliances, Consumer Electronics, BOATS, Golf Carts, SUBMARINES, Electric Bicycles/Scooters, electric vehicles, Electric Wheelchairs, Electric Power Systems, Solar Energy Storage Systems, Uninterruptible Power Supplies, Electric Forklifts
-
Brand Name:
-
HYSINCERE
-
Model Number:
-
HX12400S
-
Place of Origin:
-
Guangdong, China
-
Weight:
-
45-200kg
-
The charging ratio:
-
1c
-
The discharge rate:
-
3c
-
Electric Energy:
-
5120 Wh
-
Certification:
-
PSE, IEC62133, METI, CE, REACH
-
Battery type:
-
Lithium Iron Phosphate Battery
-
OEM/ODM:
-
Accepatable
-
Cycle life:
-
6000 Times
Pls，contact us "
send inquiry
"，get sample with discount
Welcome U, we will provide you with best price and shipping costs
Specification
Key features
1. Withstand thermal shock and puncture without fire or explosion
2. Compatible with global mainstream brands inverter
3. Real-time monitoring on LCD screen
4. Communication compatibility: CAN, RS485, RS232
5. Built-in 1A active balancer
6, Built-in 120A circuit breaker, dual protection
7, Modular design, easy to install and maintain, support parallel connection
8, Professional BMS, multiple protection
9, 6000 cycles, long life
10, Can be connected to APP remote control
|
Model
|
HX48100L
|
HX48100H
|
HX48150H
|
HX48200H
|
|||
|
Nominal Voltage
|
48V
|
51.2V
|
51.2V
|
51.2V
|
|||
|
Nominal Capacity
|
100Ah
|
100Ah
|
150Ah
|
200Ah
|
|||
|
Rated Energy
|
4800Wh
|
5120Wh
|
7680Wh
|
10240Wh
|
|||
|
Maximum Charge Voltage
|
54V
|
57.6V
|
57.6V
|
57.6V
|
|||
|
Maximum Charge Current
|
100A
|
100A
|
150A
|
200A
|
|||
|
Maximum Continuous Discharge Current
|
100A
|
100A
|
150A
|
200A
|
|||
|
Maximum Peak Discharge Current (5 seconds)
|
200A
|
200A
|
300A
|
400A
|
|||
|
Discharge Cut-off Voltage
|
40.5V
|
43.2V
|
43.2V
|
43.2V
|
|||
|
Charge Temperature
|
-5~+60℃
|
|
|
|
|||
|
Discharge Temperature
|
-10~+65℃
|
|
|
|
|||
|
Storage Temperature
|
-20~+45℃
|
|
|
|
|||
|
Self Discharge (Stored at 50%SOC)
|
≤3%/month
|
|
|
|
|||
|
Cycle Life (25℃, 0.5C, 100% DOD)
|
>6000
|
|
|
|
|||
|
Terminals
|
M8 Nut
|
|
|
|
|||
|
Protection Level
|
IP54
|
|
|
|
|||
|
Dimensions
|
482*550*156mm
|
482*550*156mm
|
482*568*200mm
|
482*568*247mm
|
|||
|
Weight
|
42g
|
44kg
|
65kg
|
82kg
|
|||
|
Communication Protocol
|
CAN/RS485/RS232
|
|
|
|
|||
