Quick Details
-
Color:
-
White,Grey,Navy,Red,Khaki,Purple,Green,Black etc
-
Size:
-
2950*1340*1820mm
-
Brakes:
-
Hydraulic Disc
-
Motor:
-
48V 5KW AC motor
-
Place of origin:
-
Guangzhou,China
-
Recharge Time:
-
8-10h
-
Climbing Ability:
-
30%
-
Battery:
-
8V 150Ah 6PCS
Quick Details
-
Tire Size:
-
12X7
-
Dimension:
-
2520*1340*1895mm
-
Product Name:
-
CE approved 2 seat battery powered 4-wheel electric club car golf cart
-
Color:
-
White,Grey,Navy,Red,Khaki,Purple,Green,Black etc
-
Size:
-
2950*1340*1820mm
-
Brakes:
-
Hydraulic Disc
-
Motor:
-
48V 5KW AC motor
-
Place of origin:
-
Guangzhou,China
-
Recharge Time:
-
8-10h
-
Climbing Ability:
-
30%
-
Battery:
-
8V 150Ah 6PCS
Product Description
|
STD
|
|
|
Size Overall
|
2950*1340*1820mm
|
||||
|
Motor:KDS 48V AC motor
Power :5KW
Electrical System :48V Battery :Shengyang 6 pcs 6x8V Lead Acid Charger:Intelligent, 48V/18A, Charging time<8hours (discharging rete 80%) Controller :BORCART48V350A DC: DC-DC 48V/12V-300W
Motor:KDS 72V AC motor
Power:5KW Electrical System:72V Battery:Guosheng 72V120A Lithium Charger:Intelligent, 72V17A, charging time<8hours (discharging rate 80%) Controller :BORCART72V350A DC:DC-DC 72V/12V-300W |
|
|
No.of Passengers
|
4 Passengers( 2/4/6/8 seaters selected )
|
||||
|
|
|
|
Net Weight
|
<=565kg
|
||||
|
|
|
|
wheel dis Front/rear
|
Front 920mm/Rear 1015mm
|
||||
|
|
|
|
Max Speed
|
25MPH
|
||||
|
|
|
|
Climb Performance
|
25%
|
||||
|
|
|
|
Slope Performance
|
25%
|
||||
|
|
|
|
Battery life
|
50-70 mile(Normal road)
|
||||
|
|
|
|
Brake distance
|
<3.5m
|
||||
|
|
|
|
Battery
|
Acid /Lithium Battery
|
||||
|
Confortable Performance
|
|
|
|
|
||||
|
1.Front suspension:Macpherson Independent Suspension
2.Rear suspension:Integral rear axle,Speed ratio 16:1 Spring plate and Hydraulic Shock
3.Braking system:rear axle,4wheel hydraulic brake, 4wheel disc brake + electronic brake parking
4.Turning system:Bi-directional rack and pinion steering system, Automatic backlash compensation
5.Frame:High-strength metal trapezoidal frame (electrophoresis + high gloss)
|
|
|
|
|
||||
|
|
|
|
|
|
||||
Factory Installed Accessories
Ceiling：
Square tube frame Coating + PP injection molding one-piece
Wind screen
：
DOT certified foldable glass
Safety Belt：
DOT certified safety belts
Body：
The front cover, seat barrel, body and rear cover are molded by special injection material for automobiles
Floor：
Aluminum alloy profile anti-slip floor, high-strength, corrosion resistance, aging resistance
Dash board：
Plastic-molded instrument panel, IP66 waterproof , water cup holder; 12V power supply, USB+ Type-c charging/Dual USB charging.
LCD Screen：
HASDA IP66, 5 inch LCD , Multimedia instrument, with vehicle detection
Speaker system：
HASDA IP66 full range speaker H058
Seats
：
verall foam molding seat cushion; solid color leather; rear basket (including: ball bag bracket)
Hub：
BK-A186; BK-0828 10-inch aluminum wheel Size:10x7 PCD: 4/101.BK-A186; BK-0828
Tire：
DOT certification; Road tire 205/50-10 (4 Ply Rated)/tire
Rear Mirror：
Adjustable,foldable rear view mirror
LED and alarm Signal：
Front multi functional LED light/Rear multi functional L ED light
Color of Body：
Standard (Forest Green, Ivory, White, Gold, Electric Blue, Apple red, black, Grey)
