Quick Details
-
Brand Name:
-
ENIKOL
-
Model Number:
-
ESK4805CR/ESK4810CR/ESK2420CR
-
Place of Origin:
-
Guangdong, China
-
Weight:
-
23kg/43kg
-
The charging ratio:
-
99%
-
The discharge rate:
-
98%
-
Type:
-
Rack mounted
-
Rated Capacity:
-
51.2V50AH(2560WH) / 51.2V100AH(5120WH) / 25.6V200AH(5120WH)
-
Display:
-
LCD
-
Cycle life:
-
≥6000 times
-
Shell Material:
-
Black painted steel shell(optional)
-
Communication function:
-
RS485/CAN protocol
-
Warranty:
-
5 years, 5years
-
Protection:
-
Built-in BMS
-
Certification:
-
MSDS/CE/FCC/UKCA
-
Parallel connection:
-
Yes
Quick Details
-
Storage Type:
-
Standard storage
-
Anode Material:
-
LFP
-
Application:
-
Toys, Power Tools, Home Appliances, Consumer Electronics, BOATS, Golf Carts, SUBMARINES, Electric Bicycles/Scooters, electric vehicles, Electric Wheelchairs, Electric Power Systems, Solar Energy Storage Systems, Uninterruptible Power Supplies, Electric Forklifts
-
Brand Name:
-
ENIKOL
-
Model Number:
-
ESK4805CR/ESK4810CR/ESK2420CR
-
Place of Origin:
-
Guangdong, China
-
Weight:
-
23kg/43kg
-
The charging ratio:
-
99%
-
The discharge rate:
-
98%
-
Type:
-
Rack mounted
-
Rated Capacity:
-
51.2V50AH(2560WH) / 51.2V100AH(5120WH) / 25.6V200AH(5120WH)
-
Display:
-
LCD
-
Cycle life:
-
≥6000 times
-
Shell Material:
-
Black painted steel shell(optional)
-
Communication function:
-
RS485/CAN protocol
-
Warranty:
-
5 years, 5years
-
Protection:
-
Built-in BMS
-
Certification:
-
MSDS/CE/FCC/UKCA
-
Parallel connection:
-
Yes
Why Choose Us
With RS485/CAN communication protocol which can better match with 14 brands of solar inverter(PYLONTECH/GOODWE/Growatt/SMA/Victron/TBB/Must/Srne/MEGAREVO/Deye/INVT/Voltronic/SOFAR/SOROTEC)
Products Description
|
Product Model:
|
ESK-2420CR
|
ESK-4810CR
|
ESK-4805CR
|
||
|
Type of Battery:
|
Lithium Iron Phosphate
|
|
|
||
|
Type of Battery:
|
16S1P
|
|
|
||
|
Max parallel:
|
64sets
|
|
|
||
|
Rated capacity:
|
200AH (5120WH)
|
100AH (5120WH)
|
50AH (2560WH)
|
||
|
Rated voltage :
|
25.6v
|
51.2v
|
51.2v
|
||
|
Charging voltage:
|
29.2V
|
58.4V
|
58.4V
|
||
|
Max charging current :
|
100A
|
|
50A
|
||
|
Max continuous discharge current:
|
100A
|
|
|
||
|
Weight:
|
43kg
|
43kg
|
27kg
|
||
|
Display:
|
LCD
|
|
|
||
|
Dimension (L* W * H) mm:
|
460*442*117
|
460*442*117
|
442*360*132.5
|
||
|
Warranty :
|
5 years
|
|
|
||
|
communication faction:
|
CAN/RS485 or dry contact
|
|
|
||
|
communication faction:
|
≥6000 times
|
|
|
||
|
Charging temperature：
|
0℃ to +55℃
|
|
|
||
|
Operating temperature：
|
-20℃ to +65℃
|
|
|
||
|
Protection function:
|
overcharge protection, over discharge protection, over-current protection, short circult protection, over temperature protection and
low voltage alarm.
|
|
|
||
Stackable Batteries 48v lto battery Rack Lifepo4 50ah 100ah
address definition operation indicator
*LCD display, communication protocol matching with mainstream solar inverter.
*Double positive and negative pole interfaces are specially designed for parallel stacking.
*positive and negative pole interfaces can support up to 64 sets in parallel.
Our Advantages:
[Extremely Safe]
: Built-in automatic protection which can prevent overcharge, overdischarge, overvoltage, short circuit, low voltage alarm and over temperature. Rack mounted design, Firm structure and easy installation.
[Smart BMS] : Our lithium battery has a built-in Battery Management System (BMS) to balance all cells, we can ensure consistency and stability during battery use.
[Wide Application] : Suitable for home energy storage, Photovoltaic energy storage projects, Wind energy storage, UPS, Energy storage of base station, Fire emergency equipment, RV, etc.
[Smart BMS] : Our lithium battery has a built-in Battery Management System (BMS) to balance all cells, we can ensure consistency and stability during battery use.
[Wide Application] : Suitable for home energy storage, Photovoltaic energy storage projects, Wind energy storage, UPS, Energy storage of base station, Fire emergency equipment, RV, etc.
Installation Cases
FAQ.(contact our sales for more details!)
Q1: What’s the life of Enikol rack mounted battery?
A: 80% DOD more than 6000 cycles.
Q2: Can the battery be connect in parallel?
A: Yes, support in parallel for at most 64pcs.
Q3: Can the rack mounted battery work with my hybrid inverter?
A: Yes, the rack mounted battery suitable for all off grid and hybrid inverter.
Q4: What’s the warranty of rack mounted battery?
A: 5 years, we support extended warranty services.
Q5: What is the battery output power?
A: 5KW Per battery.
Q6: Does the rack mounted battery including inverter?
A: No, is battery only, so it is more flexible to work with 14 brand of inverter preferred by customer.
Q7: Does the rack mounted battery with communication function?
A: Yes, Enikol rack mounted battery with RS485/CAN protocol communication with PC and smart LCD for monitoring.
Q2: Can the battery be connect in parallel?
A: Yes, support in parallel for at most 64pcs.
Q3: Can the rack mounted battery work with my hybrid inverter?
A: Yes, the rack mounted battery suitable for all off grid and hybrid inverter.
Q4: What’s the warranty of rack mounted battery?
A: 5 years, we support extended warranty services.
Q5: What is the battery output power?
A: 5KW Per battery.
Q6: Does the rack mounted battery including inverter?
A: No, is battery only, so it is more flexible to work with 14 brand of inverter preferred by customer.
Q7: Does the rack mounted battery with communication function?
A: Yes, Enikol rack mounted battery with RS485/CAN protocol communication with PC and smart LCD for monitoring.
