Quick Details
-
Model Number:
-
XQY15-96-H65-BQ
-
Frequency:
-
102HZ
-
rated power:
-
15KW
-
Peak power:
-
28KW
-
Rated voltage:
-
96V
-
Rated torque (N.m):
-
47.8
-
Rated speed:
-
3000r/min
-
Peak speed:
-
6000r/min
-
Working system:
-
S9
-
Insulation class:
-
H
-
Protection level:
-
IP67
-
rated current:
-
130A
Quick Details
-
AC Voltage:
-
96V
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Depuda
-
Model Number:
-
XQY15-96-H65-BQ
-
Frequency:
-
102HZ
-
rated power:
-
15KW
-
Peak power:
-
28KW
-
Rated voltage:
-
96V
-
Rated torque (N.m):
-
47.8
-
Rated speed:
-
3000r/min
-
Peak speed:
-
6000r/min
-
Working system:
-
S9
-
Insulation class:
-
H
-
Protection level:
-
IP67
-
rated current:
-
130A
Products Description
|
rated power
|
15KW
|
|
Peak power
|
28KW
|
|
Rated voltage
|
96V
|
|
Rated torque (N.m)
|
47.8
|
|
Rated speed
|
3000
|
|
Peak speed
|
6000
|
|
Working system
|
S9
|
|
Insulation class
|
H
|
|
Protection level
|
IP67
|
|
Main scope of application
|
Low-speed electric passenger vehicles, logistics vehicles
SIGHTSEEING BUS MOTOR、GOLF CART MOTOR、ELECTRIC TRUCK MOTOR
|
1.
Smooth and reliable. Joined with transaxle of vehicles with involute spline shaft,provide reliable and safe guarantee for vehicle.
2. Climbing ability. High starting torque, greater speed range and higher top speed, higher overload capability, which will supply big power for electric car and meet the climbing needs.
3.Long driving range of a single charge. Higher motor efficiency,provide the effectiveness
4. Durable in use,easy maintenance
