Automatic PFA Pipe production line FEP PFA FLUORINE TUBE MACHINE LINE PFA pipe extruder for semiconductor
Automatic PFA Pipe production line FEP PFA FLUORINE TUBE MACHINE LINE PFA pipe extruder for semiconductor
Automatic PFA Pipe production line FEP PFA FLUORINE TUBE MACHINE LINE PFA pipe extruder for semiconductor
Automatic PFA Pipe production line FEP PFA FLUORINE TUBE MACHINE LINE PFA pipe extruder for semiconductor
Automatic PFA Pipe production line FEP PFA FLUORINE TUBE MACHINE LINE PFA pipe extruder for semiconductor
Automatic PFA Pipe production line FEP PFA FLUORINE TUBE MACHINE LINE PFA pipe extruder for semiconductor
Automatic PFA Pipe production line FEP PFA FLUORINE TUBE MACHINE LINE PFA pipe extruder for semiconductor
Automatic PFA Pipe production line FEP PFA FLUORINE TUBE MACHINE LINE PFA pipe extruder for semiconductor

Automatic PFA Pipe production line FEP PFA FLUORINE TUBE MACHINE LINE PFA pipe extruder for semiconductor

FOB Reference Price: Get Latest Price
≥1 Sets
US $25000
Free Inquiry
Customized Request
  • Product Details
  • {{item.text}}

Quick Details

Place of Origin:
Zhangjiagang
Brand Name:
ACC
Voltage:
Customized
Dimension(L*W*H):
12*0.8*1.85 M
Power (kW):
40
Weight:
350 KG
Name:
Extrusion Machine
Raw material:
FEP PFA PTFE
After-sales Service Provided:
Engineers
Usage:
semiconductor
Final product:
Diameters Pipes
Inverter:
ABB
Motor:
SIEMENS
Certification:
CE ISO
Contactor:
Schnerder
Screw:
Special for fluorine material

Quick Details

Screw Design:
Single-screw
Screw L/D Ratio:
28:1
Screw Speed (rpm):
100 rpm
Place of Origin:
Zhangjiagang
Brand Name:
ACC
Voltage:
Customized
Dimension(L*W*H):
12*0.8*1.85 M
Power (kW):
40
Weight:
350 KG
Name:
Extrusion Machine
Raw material:
FEP PFA PTFE
After-sales Service Provided:
Engineers
Usage:
semiconductor
Final product:
Diameters Pipes
Inverter:
ABB
Motor:
SIEMENS
Certification:
CE ISO
Contactor:
Schnerder
Screw:
Special for fluorine material
Product Description
No.
Item
Qty
1
Feeder
1set
2
SJ-45/28 single screw extruder
1set
3
Mould
1set
4
Vacuum Calibration Box and Water tank
1set
5
Diameter measuring instrument
1set
6
Traction machine
1set
7
Stacker
1set
If you need more details, Please contact us!
Specification



Main Extruder

Screw diameter: 45mm
L/D: 28:1
Screw and barrel materials :38CrMoAlA
Control system: Electric control box
Transducer: ABB
Voltage：380V, 50HZ, 3P
(can be customized)





Mould
Heating power: 1.5 kw
Specification of mold: 3/5, 4/6.5, 4/7mm
The material of sizing unit is high-quality wearing resistance copper





Vacuum Calibration Box
Method: Recycling water
Material of the tank: Stainless steel
Water pump: 1.5 kw
Water Tank Length: 5000 mm
Height of the centerline: 1000mm





Traction Machine

Haul-off method:Belt
Pressing method:Pneumatic pressing
Drawing speed:1-15m/min
Motor Method:AC Motor
Power:0.75 kw×2






Diameter measuring instrument

PLC control
with Automatic Feedback System




Stacker

Material: Stainless steel
Method: pneumatic
