Quick Details
-
Brand Name:
-
HUGO
-
Fork Length:
-
1000/1200/1500mm
-
Fork Width:
-
720/730/740MM, 550/685MM
-
Overall Dimensions:
-
1180*750*2040mm
-
Weight (KG):
-
300 kg
-
Product Name:
-
manual stacker 500kg
-
Color:
-
Red Yellow Blue
-
Power type:
-
Manual Hydraulic Pump
-
Lifting height:
-
1.6M
-
big wheel size:
-
180*50
-
pump:
-
ac casting pump
-
Min. Lifting Height::
-
85mm
-
Loading Capacity::
-
1-2t
-
wheel:
-
nylon
Quick Details
-
Min. Lifting Height:
-
85mm
-
Warranty:
-
1 Year
-
Place of Origin:
-
Tianjin, China
-
Brand Name:
-
HUGO
-
Fork Length:
-
1000/1200/1500mm
-
Fork Width:
-
720/730/740MM, 550/685MM
-
Overall Dimensions:
-
1180*750*2040mm
-
Weight (KG):
-
300 kg
-
Product Name:
-
manual stacker 500kg
-
Color:
-
Red Yellow Blue
-
Power type:
-
Manual Hydraulic Pump
-
Lifting height:
-
1.6M
-
big wheel size:
-
180*50
-
pump:
-
ac casting pump
-
Min. Lifting Height::
-
85mm
-
Loading Capacity::
-
1-2t
-
wheel:
-
nylon
Product Description
The manual hydraulic stacker is suitable for production plants, production workshops, warehouses, stations, docks, airports and other places, especially for places with fire and explosion protection requirements, such as printing workshops, various oil depots, chemical warehouses and other places.
Specification
|
|
JD-A1.0
|
JD-A2.0
|
JD-A3.0
|
|
Rated lifting capacity(kg)
|
1000
|
2000
|
3000
|
|
Max. lifting height(mm)
|
1600
|
1600
|
1600
|
|
Lowered height of forks(mm)
|
100
|
100
|
100
|
|
Fork length(mm)
|
900
|
900
|
1000
|
|
Adjustable width of forks(mm)
|
200-580
|
240-680
|
300-770
|
|
Outer width of front legs(mm)
|
720
|
740
|
750
|
|
Operation power of crank(kg)
|
24
|
32
|
40
|
|
Min. refuel volume for fuel tank(L)
|
1.6
|
2.0
|
3.0
|
|
Front wheel size(mm)
|
Φ100x50
|
Φ100x50
|
Φ100x50
|
|
Rear wheel size(mm)
|
Φ180x50
|
Φ180x50
|
Φ180x50
|
|
Overall size(mm)
|
2050x730x1380
|
2050x740x1480
|
2050x740x1650
|
|
Self weight(kg)
|
115
|
180
|
280
|
