Quick Details
-
Model Number:
-
G304
-
Max. Current:
-
20mA
-
Mechanical Life:
-
300000 cycles
-
Company assurance system:
-
ISO9001 & TS16949
-
Environmental compliance:
-
RoHS, Reach
-
Rating:
-
0.1A 12VDC
-
Electrical life:
-
100,000cycles
-
Color:
-
Black
-
Mechanical life:
-
100,000cycles
-
Operating force:
-
150gf max w.o lever
-
Function/circuit:
-
SPDT (NO or NC for option)
-
Terminal type:
-
PCB terminals (others for option)
Quick Details
-
Max. Voltage:
-
12V DC
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Unionwell
-
Model Number:
-
G304
-
Max. Current:
-
20mA
-
Mechanical Life:
-
300000 cycles
-
Company assurance system:
-
ISO9001 & TS16949
-
Environmental compliance:
-
RoHS, Reach
-
Rating:
-
0.1A 12VDC
-
Electrical life:
-
100,000cycles
-
Color:
-
Black
-
Mechanical life:
-
100,000cycles
-
Operating force:
-
150gf max w.o lever
-
Function/circuit:
-
SPDT (NO or NC for option)
-
Terminal type:
-
PCB terminals (others for option)
Products Description
|
Rating
|
|
0.1A 125/250VAC;3A/12VDC;0.1A/48VDC
|
|
|
Operating frequency
|
Electrical
|
0.1A-120;3A-10~30 cycles/min
|
|
|
|
Mechanical
|
120 cycles/min
|
|
|
Contact resistence
|
|
100M Ω Max(without wire type)
|
|
|
Insulation resistance
|
|
100M Ω Min
|
|
|
Vibration durability
|
|
10~55Hz, move 1.5mm(p-p)
|
|
|
Dielectric Strength
|
|
500VAC (50~60Hz)
|
|
|
Storage Temperature
|
|
-40℃+85℃
|
|
|
Storge Humidity
|
|
85% RH Max
|
|
|
Service
|
Electrical
|
Min 100,000 cycles
|
|
|
|
Mechanical
|
Min 500,000 cycles
|
|
