Quick Details
-
Brand Name:
-
DTB
-
Power supply:
-
DC5V USB port power supply
-
Effective distance:
-
3-7cm
-
Card reading time:
-
Maximum Current: <150mA
-
Potter:
-
9600 bit/s
-
Weight:
-
50g
-
Communication Interface:
-
Bluetooth
-
Operating temperature:
-
-40℃ +85℃
-
Product Size:
-
118mmx65mmx7mm
Quick Details
-
Frequency:
-
860-960mhz
-
Protocol:
-
ISO 18000-6C
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
DTB
-
Power supply:
-
DC5V USB port power supply
-
Effective distance:
-
3-7cm
-
Card reading time:
-
Maximum Current: <150mA
-
Potter:
-
9600 bit/s
-
Weight:
-
50g
-
Communication Interface:
-
Bluetooth
-
Operating temperature:
-
-40℃ +85℃
-
Product Size:
-
118mmx65mmx7mm
|
Non Contact Reading
|
USB Fast Charging
|
ID/IC Card
|
Multi System
|
Product Paramenters
|
Power & Communications
|
|
|
|
Power Supply
|
Battery Power Supply, Can Be Charged
|
|
|
Consumption
|
Maximum Current:
|
|
|
Frequency Paragraph
|
13.56 MHz
|
|
|
Potter
|
9600 bit/s
|
|
|
Communication Interface
|
Bluetooth
|
|
|
Antenna
|
Built -in
|
|
|
Reading Distance
|
3 cm ~ 7cm (Depending on The Size and Quality of The Card or Tag)
|
|
|
Appearance
|
|
|
|
Size
|
118mmx65mmx7mm (L*W*H)
|
|
|
Weight
|
50g
|
|
|
Material
|
Black, Scrub
|
|
|
Model
|
QY-BR100
|
|
|
Environmental Character
|
|
|
|
Operating Temperature
|
-20°C~+80°C
|
|
|
Storage Temperature
|
-40°C~+85°C
|
|
|
Humidity
|
Relative Humidity 5%~ 95%
|
|
|
Standards Compliant
|
|
|
|
Power Supply
|
MIFARE® Classic 1K /4K, FuDan FM11RF08,MIFARE Ultralight®, MIFARE Ultralight® C, MIFARE® DESFire®EV1/EV2, MIFARE® Smart MX,
MIFARE® Plus S / X, MIFARE® Pro X, NTAG 21x |
|
|
Consumption
|
SRI4K, SRIX4K, AT88RF020, 66CL160S, SR176
|
|
|
ISO15693
|
EM4135, EM4043, EM4x33, EM4x35, ICode SLI/SLIX, M24LR16/64, TI Tag-it HF-I, SRF55Vxx (MY-Dvicinity) ,
|
|
Diversified connection
:
Can use USB or Bluetooth and smartphones, portable devices Computers and other equipment are conducted wired/wireless communication to transmit recognition results.
Non -Contact Reading
The reaction speed <02 seconds quickly read and write;The interval time of the card reading ≤ 0.2 seconds;Support reading ID/IC card
USB Charging interface to plug
The cable is about 1.4 meters, and the exterior of the interface line uses PVC materials to wrap the strong and durable transmission efficiency.
Non Slip Sponge Pad
The four sides of the bottom are equipped with sponge pads, anti -slip and wear -resistant sponge pads inside removable screws
Packing & Delivery
Application
Loyalty Cards
Hospitaligy Industry
Public Transportation
Access Control
Employee Card
Cashless Payment
