Quick Details
-
Table Travel (Y) (mm):
-
500
-
Dimension(L*W*H):
-
2400x2000x2400 mm
-
Weight (T):
-
4 T
-
Range of Spindle Speed(r.p.m):
-
40 - 8000 r.p.m
-
Spindle Motor Power(kW):
-
7.5
-
Max. Table Load(kg):
-
600 kg
-
Feed Speed(mm/min):
-
1 - 8000 mm/min
-
Rapid Feed Speed(m/min):
-
48/48/48
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Longkai
-
Marketing Type:
-
Hot Product 2023
-
Model NO.:
-
VMC650
-
Supply capacity:
-
100 sets/year
-
Fast moving speed:
-
up to 48m/min
-
Driver and motor:
-
Servo
-
Certification:
-
CE, RoHS, ISO 9001
-
Transport Package:
-
Wooden Box Packing
-
Trademark:
-
Longkai
-
HS Code:
-
8457101000
-
Origin:
-
Suzhou, China
Quick Details
-
Table Size (mm):
-
800*400
-
Number of Axes:
-
3
-
Table Travel (X) (mm):
-
600
-
Table Travel (Y) (mm):
-
500
-
Dimension(L*W*H):
-
2400x2000x2400 mm
-
Weight (T):
-
4 T
-
Range of Spindle Speed(r.p.m):
-
40 - 8000 r.p.m
-
Spindle Motor Power(kW):
-
7.5
-
Max. Table Load(kg):
-
600 kg
-
Feed Speed(mm/min):
-
1 - 8000 mm/min
-
Rapid Feed Speed(m/min):
-
48/48/48
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Longkai
-
Marketing Type:
-
Hot Product 2023
-
Model NO.:
-
VMC650
-
Supply capacity:
-
100 sets/year
-
Fast moving speed:
-
up to 48m/min
-
Driver and motor:
-
Servo
-
Certification:
-
CE, RoHS, ISO 9001
-
Transport Package:
-
Wooden Box Packing
-
Trademark:
-
Longkai
-
HS Code:
-
8457101000
-
Origin:
-
Suzhou, China
Product Description
Specification
|
|
Parameter item
|
Equipment type
|
Unit
|
VMC650
|
|
|
|
Axis travel
|
X-axis travel
|
mm
|
600
|
|
|
|
|
Y-axis travel
|
mm
|
500
|
|
|
|
|
Z-axis travel
|
mm
|
500
|
|
|
|
Spindle end to table
|
|
mm
|
110-610
|
|
|
|
Spindle speed
|
|
rpm
|
10000
|
|
|
|
Spindlemotor power
|
|
kw
|
7.5
|
|
|
|
Three axis motor power
|
|
kw
|
X2/Y2/Z2
|
|
|
|
Table area
|
|
mm
|
500*800
|
|
|
|
T-groove(groove*width*centerdistance)
|
|
mm
|
3-18*144
|
|
|
|
X-axis rapid displacement
|
|
|
24000/36000
|
|
|
|
Y-axis rapid displacement
|
|
mm/min
|
24000/36000
|
|
|
|
Z-axis rapid displacement
|
|
mm/min
|
18000/36000
|
|
|
|
Feed rate
|
|
mm/min
|
1-8000
|
|
|
|
Spindletaper
|
|
|
BT40
|
|
|
|
Tool quantity
|
|
|
24
|
|
|
|
Maximumtool diameter
|
|
mm
|
80
|
|
|
|
Maximumtool length
|
|
mm
|
200
|
|
|
|
Tool weight
|
|
kg
|
7
|
|
|
|
Tool magazine category
|
|
|
bamboo hat shape/knife arm
|
|
|
|
Air pressure source
|
|
kg/cm2
|
5.5
|
|
|
|
Bearing of worktable
|
|
kg
|
600
|
|
|
|
Machine tool weight
|
|
kg
|
5500
|
|
