- Product Details
- {{item.text}}
Quick Details
-
Fork Length:
-
920 MM
-
Fork Width:
-
100 MM
-
Overall Dimensions:
-
2982*1086*4030MM
-
Weight (KG):
-
3270 kg
-
Product Name:
-
Electric Forklift Truck
-
Power type:
-
Electric Power
-
Rated capacity:
-
1800 KG
-
Load center:
-
500 MM
-
STD Max lifting height:
-
3000 MM
-
Wheelbase:
-
1380 MM
-
Min.turning radius:
-
1800 MM
-
STD operating weight:
-
3270 KG
-
Lead-acid Battery votage/capacity:
-
48/420 V/Ah
-
Model:
-
LG18B
Quick Details
-
Warranty:
-
1 Year
-
Place of Origin:
-
China
-
Brand Name:
-
LONKING
-
Fork Length:
-
920 MM
-
Fork Width:
-
100 MM
-
Overall Dimensions:
-
2982*1086*4030MM
-
Weight (KG):
-
3270 kg
-
Product Name:
-
Electric Forklift Truck
-
Power type:
-
Electric Power
-
Rated capacity:
-
1800 KG
-
Load center:
-
500 MM
-
STD Max lifting height:
-
3000 MM
-
Wheelbase:
-
1380 MM
-
Min.turning radius:
-
1800 MM
-
STD operating weight:
-
3270 KG
-
Lead-acid Battery votage/capacity:
-
48/420 V/Ah
-
Model:
-
LG18B
Product Description
LONKING New 1.8 TON Electric Forklift LG18B
With Competitive Price
Product Features:
Safety and Reliable
Overall design frame and overhead guard with integral welded, Reduce vibration of whole machine and enhance frame strength.
High Stability
New dynamic counterweight design technology makes the center of gravity move backward, which improves load capacity and safety of loaded driving greatly.
Energy Efficiency
Optimized design of cooling system and air duct. Cyclone air filter with large flow.
Operating Comfort
Adopted interactive ergonomic design to improve operating comfort. Equipped with wide field of view mast to improve driver's field of view.
Well-adapted
Steering wheel can be adjusted at a large Angle to meet different driving needs.
Convenient Maintenance
Interior space of car body is more spacious Parts Positions are more reasonable. Maintainability of machine is better.
Overall design frame and overhead guard with integral welded, Reduce vibration of whole machine and enhance frame strength.
High Stability
New dynamic counterweight design technology makes the center of gravity move backward, which improves load capacity and safety of loaded driving greatly.
Energy Efficiency
Optimized design of cooling system and air duct. Cyclone air filter with large flow.
Operating Comfort
Adopted interactive ergonomic design to improve operating comfort. Equipped with wide field of view mast to improve driver's field of view.
Well-adapted
Steering wheel can be adjusted at a large Angle to meet different driving needs.
Convenient Maintenance
Interior space of car body is more spacious Parts Positions are more reasonable. Maintainability of machine is better.
Specification:
|
Speciality
parameter |
Model
|
|
|
Unit
|
LG18B
|
||
|
|
Power type
|
|
|
|
ELECTRIC
|
||
|
|
Rated capacity
|
|
|
kg
|
1800
|
||
|
|
Load center
|
|
|
mm
|
500
|
||
|
|
Lift height
|
|
|
mm
|
3000
|
||
|
|
Mast tilt angle
(forward/backward) |
|
|
Deg
|
6/12
|
||
|
|
Wheel-base
|
|
|
mm
|
1700
|
||
|
|
Tread(front/rear)
|
|
|
mm
|
1000/980
|
||
|
Performance
parameter |
Travel brake
|
|
|
|
Hydraulic-Foot pedal
|
||
|
|
Parking brake
|
|
|
|
Mechanical-Hand level
|
||
|
|
Lift speed(with/without load)
|
|
|
mm/s
|
400/440
|
||
|
|
Lower speed (with/without load)
|
|
|
mm/s
|
(with load)<600 ,
(without load)>300 |
||
|
|
Travel speed (with/without load)
|
|
|
km/h
|
18/19
|
||
|
|
Max. Towing (with/without load)
|
|
|
kN
|
15/13
|
||
Photos:
