Quick Details
-
Place of Origin:
-
Shanghai, China
-
Product name:
-
Panel 4G LTE Mimo Antenna1800-2600mhz mimo 4g lte external
-
Connector type:
-
NK- connector (customized)
-
VSWR:
-
2.0
-
Polarization:
-
Linear
-
Gain(dBi):
-
12
-
Color:
-
Black
-
Frequency Range-MHz:
-
1800mhz2600mhz
-
Gain:
-
18dBi
-
Max power:
-
100w Car Antenna
Quick Details
-
Type:
-
Base station Antenna
-
Brand Name:
-
Saintenna
-
Model Number:
-
other
-
Place of Origin:
-
Shanghai, China
-
Product name:
-
Panel 4G LTE Mimo Antenna1800-2600mhz mimo 4g lte external
-
Connector type:
-
NK- connector (customized)
-
VSWR:
-
2.0
-
Polarization:
-
Linear
-
Gain(dBi):
-
12
-
Color:
-
Black
-
Frequency Range-MHz:
-
1800mhz2600mhz
-
Gain:
-
18dBi
-
Max power:
-
100w Car Antenna
Panel 4G LTE Mimo Antenna,1800-2600mhz mimo 4g lte external panel antenna
PRODUCT INFORMATION
| Dimension(mm) | 200mm *200mm*12mm |
| Connect Type | N-K(Customized) |
| Color | Black |
| Work Temp.(℃) | -40℃~+85℃ |
| Humidity | <75% |
| Frequency Range(GHz) | 1.7GHz-2.7GHz |
| Gain(dBi) | 12 |
| VSWR | <2 |
| Polarization | Linear |
| Input Impedance(Ω) | 50 |
| Max Input Power(w) | 10 |
| Mechanical Specification | |
| Name | 5.3G-5.8G high gain directional antenna |
| Part Number | SAA31232A |
| Dimension(mm) | 330mm *330mm*12mm |
| Connect Type | N-K |
| Cable Length(mm) | |
| Color | Black |
| Work Temp.(℃) | -40℃~+85℃ |
| Humidity | <75% |
| Electrical Specification | |
| Frequency Range(MHz) | 5300-5800 |
| Gain(dBi) | 25 |
| VSWR | <1.5 |
| Polarization | Linear |
| Input Impedance(Ω) | 50 |
| Max Input Power(w) | 10 |
| Mechanical Specification | |
| Name | 2port 2.3-3.6GHz panel antenna |
| Part Number | SAA31067A |
| Dimension(mm) | 150×150×17.6 |
| Connect Type | MHF |
| Cable Length(mm) | 1.13-150 |
| Color | Green |
| Work Temp.(℃) | -40℃~+85℃ |
| Humidity | <75% |
| Electrical Specification | ||
| Frequency Range(MHz) | 2300-2700 | 3400-3600 |
| Gain(dBi) | 8.7 | 9.7 |
| VSWR | <2 | <2 |
| Polarization | Vertical | |
| Input Impedance(Ω) | 50 | |
| Max Input Power(w) | 5 | |
| Mechanical Specification | |
| Name | 4port 0.7-2.7GHz panel antenna |
| Part Number | SAA31185A |
| Dimension(mm) | 175×147×16.8 |
| Connect Type | MHF |
| Cable Length(mm) | 1.13-220 |
| Color | Green |
| Work Temp.(℃) | -40℃~+85℃ |
| Humidity | <75% |
| Electrical Specification | ||
| Frequency Range(MHz) | 790-960 | 1710-2700 |
| Gain(dBi) | 2.6 | 4.8 |
| VSWR | <3 | <3 |
| Polarization | Vertical | |
| Input Impedance(Ω) | 50 | |
| Max Input Power(w) | 5 | |
| Mechanical Specification | |
| Name | 4 port 3.4-3.8GHz panel antenna |
| Part Number | SAA31113A |
| Dimension(mm) | 230×108×15.9 |
| Connect Type | MHF |
| Cable Length(mm) | 1.13-135 |
| Color | Green |
| Work Temp.(℃) | -40℃~+85℃ |
| Humidity | <75% |
| Electrical Specification | |
| Frequency Range(MHz) | 3400-3800 |
| Gain(dBi) | 10 |
| VSWR | <3 |
| Polarization | Vertical |
| Input Impedance(Ω) | 50 |
| Max Input Power(w) | 5 |
| Mechanical Specification | |
| Name | 9.0G-10.0G high gain directional antenna |
| Part Number | SAA31233A |
| Dimension(mm) | 200mm *200mm*12mm |
| Connect Type | N-K |
| Cable Length(mm) | |
| Color | Black |
| Work Temp.(℃) | -40℃~+85℃ |
| Humidity | <75% |
| Electrical Specification | |
| Frequency Range(MHz) | 9000-10000 |
| Gain(dBi) | 23 |
| VSWR | <2 |
| Polarization | Linear |
| Input Impedance(Ω) | 50 |
| Max Input Power(w) | 10 |
| Mechanical Specification | |
| Name | 9.0G-10.0G high gain directional antenna |
| Part Number | |
| Dimension(mm) | 200mm *385mm*14.2mm |
| Connect Type | N-K |
| Cable Length(mm) | |
| Color | Black |
| Work Temp.(℃) | -40℃~+85℃ |
| Humidity | <75% |
| Electrical Specification | |
| Frequency Range(MHz) | 9000-10000 |
| Gain(dBi) | 23 |
| VSWR | <2 |
| Polarization | Linear |
| Input Impedance(Ω) | 50 |
| Max Input Power(w) | 10 |
| Mechanical Specification | |
| Name | 2.3G-2.4G high gain directional antenna |
| Part Number | |
| Dimension(mm) | 340mm *φ200 |
| Connect Type | N-K |
| Cable Length(mm) | |
| Color | Black |
| Work Temp.(℃) | -40℃~+85℃ |
| Humidity | <75% |
Q: DO you offer OEM or ODM products?
A: yes, we do both
Q: Are you a manufacturing or trading company?
A: we’ve manufactured antennae with Professional Technology for 18+ years
Q: How can I get the sample to check your quality?
A: After price confirmation, you can request samples to check our product’s quality. If you just need a blank sample to check
the design and quality. We will provide you with a sample for free as long as you afford the express freight.
Q: What is your term of delivery?
A: We accept EXW, FOB Shenzhen, or FOB Guangzhou. You can choose the one which is the most convenient or cost-effective for you.
Q: What can I get the price?
A: We usually quote within 24 hours after we get your inquiry. If you are very urgent to get the price, please tell us in your
email so that we can regard your inquiry priority.
Q: What about the lead time for the mass production?
A: Honestly, it depends on the order quantity and the season you place the order.
Q: Can the connector be made with another type of connector?
A: yes, we can customize connectors for you, SMA serial, MCX, Fakra, TS9, CRC9, and so on.
