1. It is suitable for medium and low pressure, medium and small flow rate, conveying fluid medium with high
2. viscosity and certain measurement requirements; its structural characteristics are that the power of the original machine and the
liquid transmission gear are in different pump chambers, and the overflow part is selected High-strength corrosion-resistant alloy
and metal graphite, the sealing method is The double-end mechanical seal has higher reliability and is suitable for long-term
continuous operation.
Explore More Products
- Product Details
- {{item.text}}
Quick Details
-
Warranty:
-
1year
-
Brand Name:
-
Runway
-
Model Number:
-
BT
-
Place of Origin:
-
Shandong, China
-
Horsepower:
-
0.75~2.0
-
Power Source:
-
Alternating current (ac)
-
Outlet Size:
-
DN15~DN25
-
Power:
-
0.55~1.5KW
-
Product name:
-
Gear pump
-
Shell material:
-
SUS304/316L/Tool steel
-
Delivery:
-
Express by sea or air
-
Use:
-
Medium viscosity small flow chemical fluid transportation solution
-
Applicable medium:
-
Medium viscosity chemical liquid
-
Operating temperature:
-
normal <200
-
Suitable viscosity:
-
<100000CPS
-
Solid content:
-
not allowed
-
Seal:
-
combination seal
-
Delivery accuracy:
-
±2%
Quick Details
-
Application:
-
Food and Beverage Industry, Washing and Cleaning, Water Treatment Solutions, Metering, PUR, plastic, rubber, polyester, etc
-
Pressure:
-
0.6~8.0
-
Voltage:
-
220V,380V,Custom
-
Warranty:
-
1year
-
Brand Name:
-
Runway
-
Model Number:
-
BT
-
Place of Origin:
-
Shandong, China
-
Horsepower:
-
0.75~2.0
-
Power Source:
-
Alternating current (ac)
-
Outlet Size:
-
DN15~DN25
-
Power:
-
0.55~1.5KW
-
Product name:
-
Gear pump
-
Shell material:
-
SUS304/316L/Tool steel
-
Delivery:
-
Express by sea or air
-
Use:
-
Medium viscosity small flow chemical fluid transportation solution
-
Applicable medium:
-
Medium viscosity chemical liquid
-
Operating temperature:
-
normal <200
-
Suitable viscosity:
-
<100000CPS
-
Solid content:
-
not allowed
-
Seal:
-
combination seal
-
Delivery accuracy:
-
±2%
Product Description
Product introduction
1. Good alignment: the motor and the metering pump are connected by a kneading drive, which eliminates the influence of the
centering error between the motor and the metering pump on the measurement accuracy.
2. High flow accuracy: under different
temperature, pressure and viscosity conditions, continuous and accurate flow can be operated.
temperature, pressure and viscosity conditions, continuous and accurate flow can be operated.
3. No pulsation: The unique gear
structure design makes the flow transmission without pulsation, eliminating unnecessary buffers and other accessories, making the
system simple and reducing costs.
structure design makes the flow transmission without pulsation, eliminating unnecessary buffers and other accessories, making the
system simple and reducing costs.
4.Convenient measurement: It is measured by the displacement per revolution
|
Model
|
Flow
|
Pressure
(MAX)bar
|
Speed range
|
Caliber
|
Voltage
|
Power
|
Adjustment method
|
|
BT0.6
|
0.6
|
5
|
1~80rpn
|
G3/8
|
AC220~380
|
0.55kw
|
Explosion-proof motors
|
|
BT1.2
|
1.2
|
5
|
1~80rpn
|
G3/8
|
AC220~380
|
0.55kw
|
|
|
BT2.4
|
2.4
|
5
|
1~80rpn
|
G3/8
|
AC220~380
|
0.55kw
|
|
|
BT3.2
|
3.2
|
5
|
1~80rpn
|
G3/8
|
AC220~380
|
0.55kw
|
|
|
BT6
|
6
|
5
|
1~80rpn
|
G1/2
|
AC220~380
|
0.55kw
|
|
|
BT9
|
9
|
5
|
1~80rpn
|
G1/2
|
AC220~380
|
0.55kw
|
|
|
BT12
|
12
|
5
|
1~80rpn
|
G1/2
|
AC220~380
|
0.75kw
|
|
|
BT15
|
15
|
5
|
1~80rpn
|
G1/2
|
AC220~380
|
1.1kw
|
|
|
BT20
|
20
|
5
|
1~80rpn
|
G1/2
|
AC220~380
|
1.1kw
|
|
|
BT25
|
25
|
5
|
1~80rpn
|
G1/2
|
AC220~380
|
1.5kw
|
|
|
BT30
|
30
|
5
|
1~80rpn
|
G1/2
|
AC220~380
|
1.5kw
|
|
|
BT35
|
35
|
5
|
1~80rpn
|
G1/2
|
AC220~380
|
1.5kw
|
|
Application&Testing
Our Company
Factory Show
Cooperation&Certification
Packaging&Shipping
Hot Product
FAQ
1.Q: Are you a manufacturer or a trading company?
A: We are a manufacturer specializing in the production of diaphragm metering pumps, rotor pumps and other types of pumps, as well as pump-related products. Our products have passed the test.
2.Q:Why choose us?
2.Q:Why choose us?
A:We have more than 7 years of experience in the pump product industry. High-quality products and competitive prices. We have professional business personnel and engineers to provide you with selection assistance and technical support.
3.Q: How to buy our pump?
3.Q: How to buy our pump?
A: Tell us the required pump flow, pressure, head, medium, pump body material, voltage, current frequency, motor type and medium temperature. If you have special requirements, please highlight.
4.Q: What is the minimum order quantity for your products?
4.Q: What is the minimum order quantity for your products?
A: Different models have different MOQs, please check with the salesperson.
5.Q: How long is your delivery time?
5.Q: How long is your delivery time?
A: The samples can be sent to you within 7-10 days. Bulk orders can be shipped to you within 10-15 days after the order is confirmed.
