Quick Details
-
Voltage:
-
380V/220v/110v(can be customized)
-
Dimension(L*W*H):
-
3210*1630*2290mm
-
Weight:
-
2480KG, 160-2600kg
-
Air capacity:
-
12m3/min
-
Product name:
-
screw compressor air
-
Exhaust pressure:
-
0.8Mpa
-
Exhaust volume:
-
12m³/min
-
Power:
-
7.5-250kw
-
Application:
-
for Water Well Drilling Rig
-
Usage:
-
8bar 10bar 13bar 16bar 18bar 20bar
-
Pressure:
-
Diesel Air Compressor
-
Keywords:
-
Diesel
-
Name:
-
diesel engine screw air compressor with wheels
Quick Details
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
Yugong/YG
-
Model Number:
-
SCY Series
-
Voltage:
-
380V/220v/110v(can be customized)
-
Dimension(L*W*H):
-
3210*1630*2290mm
-
Weight:
-
2480KG, 160-2600kg
-
Air capacity:
-
12m3/min
-
Product name:
-
screw compressor air
-
Exhaust pressure:
-
0.8Mpa
-
Exhaust volume:
-
12m³/min
-
Power:
-
7.5-250kw
-
Application:
-
for Water Well Drilling Rig
-
Usage:
-
8bar 10bar 13bar 16bar 18bar 20bar
-
Pressure:
-
Diesel Air Compressor
-
Keywords:
-
Diesel
-
Name:
-
diesel engine screw air compressor with wheels
Diesel Portable series Screw Air compressor for Optical cable laying, Mining, Consruction, Oil and gas exploration, water wells.
We also have various models for different type of applications. Will provide details based on type of application or the customer needs.
Description of advantage and application:
1.Easy to move (accept skid-mounted customization)
2.Large volume fuel tank to ensure 10 hours/day workload.
3.A wide range of pressure and capacity design, 57 models for customers to choose.
4.Butterfly inlet valve to achieve 0 ~ 100% continuous automatic flow control.
5.Double damping of the main engine and axle, the machine runs more smoothly.
6.Large area cooler design, rust-proof resin fan.
7.Choose the best matching power Diesel Engine to reduce overall operating load and increase service life.
Technical Parameters
| Yugong Machinery Hot Sale Series Diesel Portable Air Compressors | |||||
| Model | Machine | Diesel Engine | |||
| Free Air | Normal | Dimensions | Weight |
Rated Power |
|
| Delivery | Working Pressure | (Without Towbar) | |||
| M3/min | Bar(e) | L*W*H(mm) | kG | KW | |
| 110SCY-8 | 12 | 8 | 3210*1630*2290 | 2480 | 110 |
| 110SCY-10 | 12 | 10 | 3210*1630*2290 | 2480 | 110 |
| 110SCY-14.5 | 10 | 14.5 | 3210*1630*2290 | 2480 | 110 |
| 138SCY-14.5 | 13 | 14.5 | 3350*2060*2350 | 3000 | 140 |
| 139SCY-13 | 15 | 13 | 3650*1700*2040 | 3000 | 140 |
| 141SCY-13 | 15.5 | 13 | 3720*1970*2550 | 2510 | 140 |
| 168SCY-16 | 15.5 | 16 | 3720*1970*2550 | 3800 | 162 |
| 177SCY-17 | 16 | 17 | 3720*1970*2550 | 3760 | 179 |
| 177SCY-18 | 16 | 18 | 3720*1970*2550 | 3800 | 179 |
| 186SCY-18 | 17 | 18 | 3720*1970*2550 | 3650 | 191 |
| 195SCY-19 | 19 | 19 two stage | 3720*1970*2550 | 3830 | 194 |
| 198SCY-18 | 18 | 18 | 3720*1970*2550 | 3830 | 191 |
| 228SCY-21 | 22 | 20 two stage | 3720*1970*2550 | 3830 | 221 |
| 250SCY-17 | 22 | 17 | 3810*2000*2900 | 4800 | 250 |
| 260SCY-21 | 22 | 21 two stage | 3250*2100*2300 | 4550 | 330 |
Detailed Pictures:
Packaging and Shipping
Remark:
Free air delivery in accordance with ISO 1217:2009, Annex C: Absolute intake pressure 1 bar(a), cooling and air take
temperature 20 ℃.
Note: Skid-mounted type is available.
Our Company:
Social Responsibility:
Five-star Praise from Customers:
RFQ
Q1: Are you factory or trade company?
A1: We are factory.
Q2: Warranty terms of your machine?
A3: 18 months warranty for the machine,technical support according to your needs.
Q3: Will you provide some spare parts of the machines?
A4: Yes.
Q4: How long will you take to arrange production?
A5: Deliver standard goods within 30days, Other customized goods is TBD.
Q5: Can you accept OEM orders?
A6: Yes, with professional design team, OEM orders are highly welcome.
