Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
ADEN
-
Weight (KG):
-
12 KG
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Item:
-
Wholesale cross flow air curtain factory
-
Specification:
-
900mm/1200mm/1500mm/1800mm/2000mm
-
Voltage:
-
110V/220V
-
Frequency:
-
50Hz/60Hz
-
lnstallation Height:
-
3.0~3.5M
-
Air Speed:
-
12m/s
Quick Details
-
Type:
-
Air Curtain
-
Mounting:
-
Wall / Window Mount
-
Airflow:
-
2320CMH, 2320CMH~5410CMH
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
ADEN
-
Weight (KG):
-
12 KG
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Item:
-
Wholesale cross flow air curtain factory
-
Specification:
-
900mm/1200mm/1500mm/1800mm/2000mm
-
Voltage:
-
110V/220V
-
Frequency:
-
50Hz/60Hz
-
lnstallation Height:
-
3.0~3.5M
-
Air Speed:
-
12m/s
Airteam makes your house “breathe”
Airteam ventilation system can ventilate a room on a timed, quantitative and efficient basis and improve the indoor air quality effectively relying on its peofessional and sophisticated design. It will provided you and your family with a home being able to“breath fresh air”, and will create a healthy and comforable living space to get rid of “Sick Building Syndrome”.
* All metal spraying with better fire prevention, corrosion resistance performance;
* New guide louver design is available so that the wind can be adjusted randomly to meet environment with different requirements for wind direction;
* Multiple control methods, such as manual switch, IR remote, magnet switch and door sensor, multiple control modes are available to satisfy different requirements at different places;
* Turbine impeller injection molded by ABS and glass fiber injection is characterized of high intensity and low noise;
* The unequal pitch and multi-blade rotor design is characterized of lower noise and smaller vibration;
* All pure copper wire motor at low temperature to ensure consistent running without failure;
* Professional air duct design can realize more silent effect and superior performance of the product;
* High-quality ball bearing to ensure motor running more smoothly and silent;
* Resettable thermal protection device will disconnect power when the product is at abnormal high temperature to avoid potential safety hazards to make the operation more safe;
* Start up at 100V ultra-low voltage which is more convenient in operation;
* Enclosure class IP44
* Insulation class E
* New guide louver design is available so that the wind can be adjusted randomly to meet environment with different requirements for wind direction;
* Multiple control methods, such as manual switch, IR remote, magnet switch and door sensor, multiple control modes are available to satisfy different requirements at different places;
* Turbine impeller injection molded by ABS and glass fiber injection is characterized of high intensity and low noise;
* The unequal pitch and multi-blade rotor design is characterized of lower noise and smaller vibration;
* All pure copper wire motor at low temperature to ensure consistent running without failure;
* Professional air duct design can realize more silent effect and superior performance of the product;
* High-quality ball bearing to ensure motor running more smoothly and silent;
* Resettable thermal protection device will disconnect power when the product is at abnormal high temperature to avoid potential safety hazards to make the operation more safe;
* Start up at 100V ultra-low voltage which is more convenient in operation;
* Enclosure class IP44
* Insulation class E
|
Model
|
Spec.
(mm)
|
Voltage
(V)
|
Freq.
(Hz)
|
Input
Power
(W)
|
Installation
Height
(m)
|
Air
Speed
(m/s)
|
Airflow
CMH CFM
|
Dimension
(mm) |
Net
Weight
(Kg)
|
|
FM3509C
|
900
|
120/220
|
50/60
|
132
|
3.0-3.5
|
12
|
2320 1366
|
900*175*207
|
11
|
|
FM3512C
|
1200
|
120/220
|
50/60
|
176
|
3.0-3.5
|
12
|
2720 1601
|
1200*175*207
|
13
|
|
FM3515C
|
1500
|
120/220
|
50/60
|
235
|
3.0-3.5
|
12
|
3030 1784
|
1500*175*207
|
15
|
|
FM3518C
|
1800
|
120/220
|
50/60
|
295
|
3.0-3.5
|
12
|
3890 2291
|
1800*175*207
|
17
|
|
FM3520C
|
2000
|
120/220
|
50/60
|
350
|
3.0-3.5
|
12
|
4700 2768
|
2000*175*207
|
22
|
|
FM3509C-1Y
|
900
|
120/220
|
50/60
|
132
|
3.0-3.5
|
12
|
2320 1366
|
900*175*207
|
11
|
|
FM3512C-1Y
|
1200
|
120/220
|
50/60
|
176
|
3.0-3.5
|
12
|
2720 1601
|
1200*175*207
|
13
|
|
FM3515C-1Y
|
1500
|
120/220
|
50/60
|
235
|
3.0-3.5
|
12
|
3030 1784
|
1500*175*207
|
15
|
|
FM3518C-1Y
|
1800
|
120/220
|
50/60
|
295
|
3.0-3.5
|
12
|
3890 2291
|
1800*175*207
|
17
|
|
FM3520C-1Y
|
2000
|
120/220
|
50/60
|
350
|
3.0-3.5
|
12
|
4700 2768
|
2000*175*207
|
22
|
Certificate
CE, CCC, RoHs, ISO9001
