Quick Details
-
Model Number:
-
YROPV-250(NH1), YROPV-250(NH1)
-
Rated operational Voltage Ue:
-
DC12-1000V
-
Rated Insulation Voltage Ui:
-
DC12~1000V
-
Rated frequency:
-
50/60HZ
-
Mechanicallife:
-
1000 times
-
Electrical operating life:
-
200 times
Quick Details
-
Breaking Capacity:
-
50KA
-
Place of Origin:
-
Zhejiang, China, Zhejiang, China
-
Brand Name:
-
YRO, YRO
-
Model Number:
-
YROPV-250(NH1), YROPV-250(NH1)
-
Rated operational Voltage Ue:
-
DC12-1000V
-
Rated Insulation Voltage Ui:
-
DC12~1000V
-
Rated frequency:
-
50/60HZ
-
Mechanicallife:
-
1000 times
-
Electrical operating life:
-
200 times
Specification
|
Type
|
|
YROPV-160
|
YROPV-250
|
YROPV-400
|
YROPV-630
|
||||
|
With
fuse |
Rated operational Voltage Ue
|
AC400/690/DC12-1000V
|
|
|
|
||||
|
|
Rated operational currentle
|
160A
|
250A
|
400A
|
630A
|
||||
|
|
Rated Insulation Voltage Ui
|
AC690/DC12~1000V
|
|
|
|
||||
|
|
Agreed heating current lth
|
160A
|
250A
|
400A
|
630A
|
||||
|
|
Rated impulse withstand
Voltage Uimp |
12kV
|
|
|
|
||||
|
|
Rated limiting short-circuit
current lg |
AC 100kA
DC 50kA |
|
|
|
||||
|
|
Use Category
|
AC-23B(AC400)/AC-21B(AC690)
|
|
|
|
||||
|
With
isolating knife |
Electrical operating life
|
200 times
|
|
|
|
||||
|
|
Rated operational Voltage Ue
|
AC380/400/DC12-1000V
|
|
|
|
||||
|
|
Rated operational current le
|
160A
|
250A
|
400A
|
630A
|
||||
|
|
Rated Insulation Voltage Ui
|
690V/1000V
|
|
|
|
||||
|
|
Agreed heating current lth
|
160A
|
250A
|
400A
|
630A
|
||||
|
|
Rated impulse withstand
Voltage Uimp |
8KV
|
|
12KV
|
|
||||
|
|
Rated limiting short-circuit
current lcw |
8kA/1s
|
10kA/1s
|
15kA/1s
|
|
||||
|
|
Use Category
|
AC-21B
|
|
AC-23B
|
|
||||
|
|
Electrical operating life
|
200 times
|
|
|
|
||||
|
Common
parameters |
Rated frequency
|
50/60HZ
|
|
|
|
||||
|
|
Number of poles
|
3Pole
|
|
|
|
||||
|
FUSE
|
Fuse size
|
YROPV-160(NH00)
|
YROPV-250(NH1)
|
YROPV-400(NH2)
|
YROPV-630(NH3)
|
||||
|
|
Rated operational current le
|
160A
|
250A
|
400A
|
630A
|
||||
|
|
Power waste P
|
12W
|
18W/32W
|
28W/40W
|
40W/50W
|
||||
|
Mechanism
|
Mechanicallife
|
1000 times
|
|
800 times
|
|
||||
|
Degree of protection(positive)
|
|
On:IP20/Off:IP30
|
|
|
|
||||
